Configuring QoS policies
You configure QoS policies using the CLI.
qos policy command
The qos policy command creates or deletes a QoS policy. The syntax for the
qos policy command is:
qos policy <polid> {create [name <polname>]
if-group <ifgroup> filter-set-type {ip|l2}
{filter-set <setid>|filter-set-name <setname>}
{{in-profile-action <actid>|in-profile-action-name
<actname>}|
{{meter <metid>|meter-name <metname>}
{in-profile-action <actid>|in-profile-action-name <actname>}
{out-profile-action <actid>|out-profile-action-name
<actname>}}}
[shaper <shapeid>|shaper-name <shapename>]
[shaper-group <shapegroup>]
[track-statistics {enable|disable}]order <order>|
delete|enable|disable}
The qos policy command is in the config command mode.
Table 124 describes the parameters and variables for the
qos policy command.
Table 124 qos policy command parameters and variables
Parameters and variables Description
<polid> Enter an integer to specify the QoS policy; range is 1 to 65535.
create Creates the QoS policy.
name <polname> Assigns a name to the QoS policy with the designated policy ID. Enter the
name for the policy; maximum is 16 alphanumeric characters.
if-group <ifgroup> Enter the interface group name to which this policy applies.
filter-set-type {ip|l2} Enter the type of filter set associated with this policy:
• ip—specifies IP filter set
• l2—specifies Layer 2 filter set
