216 Appendix A Command List
212160-B
no port-mirroring page 153
no radius-server page 133
no rate-limit [port <portlist>] page 113
no set logging page 97
no shutdown [port <portlist>] page 101
no snmp server [authentication-trap|community [ro|rw] contact|host [<host-ip>
<community-string>] [location|name]
page 92
no snmp trap link-status [port <portlist>] page 93
no spanning-tree [port <portlist>] [stp <1-8>] page 147
no telnet-access [source-ip [<1-10>]] page 73
no tftp-server page 80
no vlan <1-4094>
no vlan mac-address <1-4094> address <H.H.H.>
page 163
page 168
no web-server page 75
ping <XXX.XXX.XXX.XXX> page 60
port-mirroring mode disable
port-mirroring mode Xrx monitor-port <portlist> mirror-port X <portlist>
port-mirroring mode XrxOrXtx monitor-port <portlist> mirror-port X <portlist>
mirror-port-Y <portlist>
port-mirroring mode XrxOrYtx monitor-port <portlist> mirror-port X <portlist>
mirror-port-Y <portlist>
port-mirroring mode XrxYtx monitor-port <portlist> mirror-port X <portlist>
mirror-port-Y <portlist>
port-mirroring mode XrxYtxOrYrxXtx monitor-port <portlist> mirror-port X <portlist>
mirror-port-Y <portlist>
port-mirroring mode Asrc monitor-port <portlist> mirror-MAC-A <macaddr>
port-mirroring mode Adst monitor-port <portlist> mirror-MAC-A <macaddr>
port-mirroring mode AsrcOrAdst monitor-port <portlist> mirror-MAC-A <macaddr>
port-mirroring mode AsrcBdst monitor-port <portlist> mirror-MAC-A <macaddr> mirror-MAC-B
<macaddr>
port-mirroring mode AsrcBdstOrBsrcAdst monitor-port <portlist> mirror-MAC-A <macaddr>
mirror-MAC-B <macaddr>
page 151
qos action <actid> name <actname>
qos action <actid> drop-action {enable|disable}
qos action <actid> update-dscsp <dscp>
qos action <actid> update-1p {<ieee1p>|default|use-egress-map}
qos action <actid> set-drop-prec {loss-sensitive|not-loss-sensitive|default|use-egress-map}
page 204
Table 126 CLI command list (continued)
Command Page No.
