220 Appendix A Command List
212160-B
spanning-tree [stp <1-8>] [forward-time <4-30>] [hello-time <1-10>] [max-age <6-40>]
[priority <0-65535>] [tagged-bpdu {enable|disable}] [tagged-bpdu-vid <1-4094>]
page 142
spanning-tree [port <portlist>] [stp <1-8>] [learning {disable|normal|fast}] [cost <1-65535>]
[priority <0-255>]
page 145
spanning-tree [stp <1-8>] remove-vlan <1-4094> page 144
spanning-tree stp <2-8> create page 139
spanning-tree stp <2-8> delete page 140
spanning-tree stp <2-8> disable page 141
spanning-tree stp <2-8> enable page 140
speed [port <portlist>] {10|100|1000|auto} page 104
stack bootp-mac-addr-type {base-unit|stack} page 77
stack oper-mode {bps2000|hybrid} page 54
telnet-access [enable|disable] [login-timeout <1-10>] [retry <1-100>] [inactive-timeout <0-60>]
[logging {none|access|failures|all}]
[source-ip <1-10> <XXX.XXX.XXX.XXX> [mask <XXX.XXX.XXX.XXX>]]
page 72
terminal {2400|4800|9600|19200|38400}|length <1-132>|width <1-132> page 59
tftp-server <XXX.XXX.XXX.XXX> page 80
vlan create <1-4094> type macsa
vlan create <1-4094> type port
vlan create <1-4094> type protocol-ApltkEther2Snap
vlan create <1-4094> type protocol-decEther2
vlan create <1-4094> type protocol-decOtherEther2
vlan create <1-4094> type protocol-ipEther2
vlan create <1-4094> type protocol-ipv6Ether2
vlan create <1-4094> type protocol-ipx802.2
vlan create <1-4094> type protocol-ipx802.3
vlan create <1-4094> type protocol-ipxEther2
vlan create <1-4094> type protocol-ipxSnap
vlan create <1-4094> type protocol-Netbios
vlan create <1-4094> type protocol-RarpEther2
vlan create <1-4094> type protocol-sna802.2
vlan create <1-4094> type protocol-snaEther2
vlan create <1-4094> type protocol-Userdef <4096-65534>
vlan create <1-4094> type protocol-vinesEther2
vlan create <1-4094> type protocol-xnsEther2
page 160
Table 126 CLI command list (continued)
Command Page No.
