Appendix A Command List 223
Reference for the Business Policy Switch 2000 Command Line Interface
vlan create <1-4094> name <line> type macsa learning SVL
vlan create <1-4094> name <line> type port learning SVL
vlan create <1-4094> name <line> type protocol-ApltkEther2Snap learning SVL
vlan create <1-4094> name <line> type protocol-decEther2 learning SVL
vlan create <1-4094> name <line> type protocol-decOtherEther2 learning SVL
vlan create <1-4094> name <line> type protocol-ipEther2 learning SVL
vlan create <1-4094> name <line> type protocol-ipv6Ether2 learning SVL
vlan create <1-4094> name <line> type protocol-ipx802.2 learning SVL
vlan create <1-4094> name <line> type protocol-ipx802.3 learning SVL
vlan create <1-4094> name <line> type protocol-ipxEther2 learning SVL
vlan create <1-4094> name <line> type protocol-ipxSnap learning SVL
vlan create <1-4094> name <line> type protocol-Netbios learning SVL
vlan create <1-4094> name <line> type protocol-RarpEther2 learning SVL
vlan create <1-4094> name <line> type protocol-sna802.2 learning SVL
vlan create <1-4094> name <line> type protocol-snaEther2 learning SVL
vlan create <1-4094> name <line> type protocol-Userdef <4096-65534> learning SVL
vlan create <1-4094> name <line> type protocol-vinesEther2 learning SVL
vlan create <1-4094> name <line> type protocol-xnsEther2 learning SVL
page 160
vlan delete <1-4094> page 162
vlan igmp <1-4094> [snooping {enable|disable}] [proxy {enable|disable}]
[robust-value <value>] [query-interval <time>] [v1-members <portlist>]
[v2-members <portlist>]
page 171
vlan mac-address <1-4094> address <H.H.H> page 167
vlan members <1-4094> <portlist>
vlan members add <1-4094> <portlist>
vlan members remove <1-4094> <portlist>
page 166
vlan mgmt <1-4094> page 159
vlan name <1-4094> <line> page 163
vlan ports [<portlist>] [tagging {enable|disable}] [pvid <1-4094>]
[filter-tagged-frame {enable|disable}] [filter-untagged-frame {enable|disable}]
[filter-unregistered-frames {enable|disable}] [priority <0-7>] [name <line>]
page 165
web-server{enable|disable} page 75
Table 126 CLI command list (continued)
Command Page No.
