32 Chapter 1 CLI Basics
212160-B
• If you logged into the CI menus with read-write access, you enter the CLI in
privExec mode and use the commands to move to the other command modes.
Port numbering
The BPS 2000 operates either in standalone mode or in stack mode. The BPS
2000 has 24 10/100 Mb/s ports on the front, as well as an uplink slot that allows
you to attach a media dependent adapter (MDA). The MDAs available for the
uplink can have up to 4 ports. Thus, you have a maximum of 28 ports on one BPS
2000.
In stack mode, the BPS 2000 operates either in Pure BPS 2000 Stack mode or in
Hybrid Stack mode. The Hybrid Stack mode is when you are working with a
combination of the BayStack 450 or 410 switches and BPS 2000 switches in one
stack. When you are working with a standalone BPS 2000, ensure that the
operational mode is set for Pure BPS 2000 Stack. (Refer to “show
stack-oper-mode command” on page 54 and “stack oper-mode command” on
page 54 for information on operational mode commands.)
The CLI uses the variable
<portlist> when a command specifies one or more
ports for the command. The format of the variable
<portlist> is different if
you are working with a standalone BPS 2000 or with a stack (either Pure BPS
2000 Stack or Hybrid Stack).
Port numbering in standalone mode
Ensure that the operational mode is set for the Pure BPS 2000 Stack mode when
you are working with a standalone BPS 2000.
In standalone mode, use the
<portlist> variable in the following formats:
B
Note: Beginning with software version 2.0, the variable portlist replaces
the use the variable portnum, or port-num, and all for ports. The CLI is
backward-compatible, so all commands in the previous release continue
to function properly.
