Chapter 1 CLI Basics 47
Reference for the Business Policy Switch 2000 Command Line Interface
Figure 5 displays sample output from the show sys-info command.
Figure 5 show sys-info command output
To change the system contact, name, or location, refer to the snmp-server
command in Chapter 2.
show cpu-utilization command
The show cpu-utilization command displays the percentage of the CPU
utilized from system boot-up and in the last 10 seconds, 1 minute, 10, minutes, 60
minutes, and 24 hours. The syntax for the
show cpu-utilization command
is:
show cpu-utilization
The show cpu-utilization command is in the privExec command mode.
The
show cpu-utilization command has no parameters or variables.
Figure 6 displays sample output from the
show cpu-utilization command.
BPS2000#show sys-info
Operation Mode: Switch
MAC Address: 01-6C-0F-8C-01-2E
Reset Count: 16
Last Reset Type: Power Cycle
Power Status: Primary Power
Local MDA Type: None
sysDescr: Business Policy Switch 2000
HW:AB3 FW:1.1.0.1 SW:v2.0.0.01 ISVN:2
sysObjectID: 1.3.6.1.4.1.45.3.40.1
sysUpTime: 6 days, 11:14:22
sysServices: 3
sysContact: Jane Doe
sysName: Engineering
sysLocation: sylvan6-2
