Chapter 2 General CLI commands 83
Reference for the Business Policy Switch 2000 Command Line Interface
Table 29 describes the parameters and variables for the download command.
The software download process automatically completes without user
intervention. The process erases the contents of flash memory and replaces it with
a new software image. Take care not to interrupt the download process until after
it runs to completion (the process can take up to 10 minutes, depending on
network conditions).
When the download process is complete, the switch automatically resets and the
new software image initiates a self-test. The system returns a message after
successfully downloading a new image. Figure 18 displays a sample output of the
download command.
Note: Beginning with software version 2.0, you can use the download
command without parameters. The system displays the most recently
used TFTP serve IP address and file name; if you still want to use these,
press
[Enter] You can also change these.
Table 29 download command parameters and variables
Parameters and
variables
Description
address <ip> Specifies the TFTP server you want to use.
Note: If this parameter is omitted, the system goes to the server
specified by the
tftp-server command.
<image-name>
Enter the name of the BPS 2000 software image you want to
download.
bs450-image
<image-name>
Enter the name of the BayStack 450 software image you want to
download.
diag <filename> Enter the name of the BPS 2000 diagnostics image you want to
download.
