88 Chapter 2 General CLI commands
212160-B
The system resets and opens to the BPS2000 banner. Refer to “Accessing the
CLI” on page 35 to return to the CLI.
4 Validate that the ISVN on both the BPS 2000 and the BayStack are 2.
Displaying interfaces
You can view the status of all interfaces on the switch or stack, including
MultiLink Trunk membership, link status, autonegotiation, and speed.
show interfaces command
The show interfaces command displays the current configuration and status
of all interfaces. The syntax for the
show interfaces command is:
show interfaces [names] [<portlist>]
The show interfaces command is in the exec command mode.
Table 31 describes the parameters and variables for the
show interfaces
command.
Figure 19 displays a sample output of the
show interfaces names command.
Table 31 show interfaces command parameters and variables
Parameters and
variables
Description
names <portlist> Displays the interface names; enter specific ports if you want to
see only those.
