01 to 10). DMC card numbering in Expansion Cabinets/Chassis
continues sequentially in the range 11 to 20.
The following table illustrates Device ID numbering for a small
system.
Table 4
Device ID numbering for a small system
Cabinet/Chassis Card slot <board id> Device ID
1 1 01#xxx
2 2 02#xxx
…… …
9 9 09#xxx
Main Cabinet
or Main Chassis
+ Chassis Expander
10 10 10#xxx
1 11 11#xxx
2 12 12#xxx
…… …
9 19 19#xxx
Expansion Cabinet or
Expansion Chassis 1
+ Expander
10 20 20#xxx
— For a large system, such as CS1000E, <board-id> falls in the range
of 01 to 32, and is calculated with the formula:
<board-id> = 16 * <shelf_number> + <card_slot_number> + 1
The following table illustrates Device ID numbering for a large
system.
Table 5
Device ID numbering for a large system
Shelf Card slot <board id> Device ID
0 0 1 01#xxx
0 1 2 02#xxx
…… … …
0 14 15 15#xxx
0 15 16 16#xxx
1 0 17 17#xxx
1 1 18 18#xxx
…… … …
1 14 31 31#xxx
1 15 32 32#xxx
The following table shows examples of valid device IDs.
