Brief Introduction INTRODUCTION -- DIGITAL AUDIO PLAYER (DAP) – Si-120 Selecting fine audio equipment such as the unit you have just purchased is only the start of your musical enjoyment. Now it is time to consider how you can maximize the fun and excitement your equipment offers. This manual provides detailed operation instructions and features of the unit. Please read this manual carefully before using this product for the first time.
INSTALLING THE BATTERY Push open the battery compartment door. Insert the 1 x AAA Alkaline battery with the correct polarity as shown. Close the battery compartment door. - To avoid battery leakage or corrosion, remove the battery from the player if the player is not to be used for a long time. - Remove dead battery from the player immediately to avoid damaging the player. - When corrosion occurs, wipe the battery compartment immediately with a dry cloth and insert a new battery.
CONTROLS Key Functions 1. Press to turn the player ON. Press to play or pause music files. 2. Press to stop music files. Press and hold to turn the player OFF. 3. Press to access into the Repeat mode. Press and hold to access into the Equalizer mode. Press to record FM tuner or voice. 4. Press to access into the Main Menu. Press and hold to access into the Settings mode. 5. Slide to the left to lock all key functions. Slide to the right to unlock all key functions. 6.
Downloading and Transferring Files DRIVER INSTALLATION For Windows ME, 2000, XP or MAC OS 10.2.8 or higher: These versions of Windows will automatically detect your DAP after connecting with the USB cable and the computer. (Please make sure the DAP is turned ON) For Windows 98SE: Windows 98SE will not recognize the player until you have installed the driver using the included installation CD-ROM.
TRANSFERRING FILES 1. Connect the DAP to the computer by using the supplied USB cable. 2. The following will be displayed on the screen of your DAP player: 3. A “Removable Disk” will be added in “My Computer”. Open the “Removable Disk” folder: Locate the files you wish to copy from the computer to your DAP. Drag and drop MP3, WMA or WAV files on the computer into the “Removable Disk” folder. These files will now be copied into your DAP.
SAFELY REMOVE HARDWARE PROCEDURE 1. Double click the “Safely Remove Hardware” icon on the task bar: 2. From the “Safely Remove Hardware” window, select “USB Mass Storage Device” and click the “Stop” button. The “Stop a Hardware Device” window will pop up as shown: 3. Click “OK”. A “Safe to Remove Hardware” window will pop up. Now, it is safe to remove the USB Cable and your DAP player from the computer.
OPERATION LISTENING TO MUSIC After you have transferred MP3, WMA or WAV files from the computer to your DAP, you can start listening to music while you learn how to use the rest of the features. Insert the earphones into the earphone jack of the player; press the XII button to turn the player ON. USING THE MAIN MENU Press the mode button to access the MAIN MENU.
- Stop pressing the /EQ/2 button when your desired selection is displayed. Repeat Button /EQ/2 button repeatedly to select different repeat mode options. As each Press the mode is selected, the following icons will be displayed on the upper right hand of the screen on your player: Edits and plays one section repeatedly. Press and press /Navi /Navi again to end with point B once to start with point A . Play the first ten seconds of each file. Randomly play the files.
Creating a play list from the DAP - Enter into the Navigation menu. - Press the + - Press the - or the button to highlight a desired song or file. /EQ/2 button; a number icon (01, 02 etc.) will be displayed next to that song or file. - Press the /EQ/2 button to confirm the song or file selection; the number icon will disappear and the file or the song will be added to the play list. - Follow these steps with each file you would like to add to your play list.
NOTE: Each time auto scan is performed the previously preset channels will be overwritten by the new FM stations detected. Setting FM Stations Manually - If the “Preset” icon is displayed in the screen, press the - Press the the - button to clear it. button to increase the FM frequency. To fast forward scan, press and hold button. The unit will stop at each FM Station detected. Press the button to decrease the FM frequency. To fast rewind scan, press and hold the button.
- Press the XII - Press the button to pause and unpause recording. button to stop recording. Listening to the Encoded File - Enter into the Navigation mode to locate the newly encoded file. The file will be saved in the “LINEIN” Folder - You may change the file name of the file through your computer in order to match the artist and song title. RECORDING Use your DAP to record quick reminder memos or even lengthy business meetings or lectures.
CUSTOMIZING THE PLAYER USING THE SETTING MENU The Setting Menu provides the options to change the player settings. Press and hold the Press the mode or the button to display the SETTING menu on the screen. button to select one of the following setting options: Play List, Equalizer, Menu Language, ID3 Language, Scroll Speed, Play Timer, Brightness, Screensaver, Voice B/R, Line in B/R, MIC VAD, CD Sync, Play Speed, Resume, Autoplay, Sleep, Auto Power Off, Load Default, Format, FM Band, or About me.
Equalizer Setting Press the Press the or the /Navi button to choose from the preset EQ modes or User Defined EQ. button to confirm the Sound mode. Menu Language Setting Press the Press the or the /Navi button to select one of the languages for the user interface. XII button to confirm the language selection. ID3 Language Setting: Press the Press the or the /Navi button to select one of the languages for the file names. button to confirm the language selection.
Brightness Setting Press the or the button to adjust the Display brightness level. Press XII button to confirm the brightness level. Screensaver Setting Press the Press the or the /Navi button to select the time before the screensaver is activated. button to confirm the timer selection. NOTE: The battery life will be longest on the 10 sec setting. Voice B/R Setting Press the or the button to select one of the options for the four voice recording bit rates.
CD Sync Setting Press the or the button to select the CD Sync timer. Choose the number of seconds of silence required for the Line In Encoding function to separate different tracks. Press /Navi button to confirm the selection. Play Speed Setting Press the Press or the /Navi button to select the speed of the file playback. button to confirm the selection. Resume Setting Press the or the button to select between Resume On andf Resume Off.
Press /Navi button to confirm the selection. Auto Power Off Setting Press or the button to select an amount of time before the unit will shut off while in standby mode. Press /Navi button to confirm the selection. Load Default Setting Press Press or the /Navi to select Yes in order to restore the units original settings. button to confirm the selection. Format Setting Press Press or the /Navi to select between Normal or Quick format. button to confirm the selection.
Additional Information PRECAUTIONS Copyright Making copies of MP3 tracks or files without permission is a violation of the international copyright laws. Safety Vibration experienced during walking or exercising will not affect the player. However, dropping the player or dropping a heavy object on the player may result in damage or sound distortion. Avoid spilling any liquid onto or into the player.
FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
CE Warning: The exclamation point within the triangle is a warning sign alerting the user of important instructions accompanying the product. This unit must not be exposed to moisture or rain. Ensure all connections are properly made before operating the unit. This unit should be positioned so that it is properly ventilated. Avoid placing it, for example, close to curtains, on the carpet or in a built-in installation such as a bookcase.
TROUBLE SHOOTING Should any problem persist after you have checked these symptoms, consult your dealer or contact the support site at www.signstyles.com Symptom Possible Reason Actions No Power Check whether the battery is exhausted. No Sound Check whether the earphones jack is From detached from the unit. Earphones Check whether the volume is set Replace the battery. Re-insert the earphones. Increase the volume. to minimum. Check whether the battery is exhausted. Replace the battery.
Technical Specifications Category Item Specification Audio Frequency Range 20Hz - 20KHz Headphone Output 20mW, 16ohm (Max.Vol) S/N Ratio 90dB (MP3) MP3 MPEG 1/2/2.5 Layer 3 WMA Windows Media Audio WAV ADPCM encoding Bit Rate 8kbps - 320kbps Tag Info ID3 Tag FM Frequency Range 87.5MHz - 108 MHz Antenna Headphone/Earphone Cord Antenna Dimension 68.5 x 25.7 x 16.3mm Weight Approximately 38 grams Battery 1 x AAA Alkaline battery SCREEN Full Graphic OLED Display USB USB 1.
UPGRADE FIRMWARE PROCEDURE Occasionally, a new software (firmware) may be released for this unit enhancing its functionality. For more information, please go to the web site at (www.signstyles.com) for downloading procedure and downloading the latest firmware. CARE AND MAINTENANCE Your Digital Audio Player is a precise electronic device, and should not be subjected to rough handling or exposed to extreme temperatures or moisture.
