Description DVI-C5 series extender system consists of a Transmitter and one or more Transceivers. The system can extend DVI-D signal over Cat 5/5e/5 cable. By taking advantage of low-cost Cat5/5e/6 FTP cable, the Cat5 DVI-D Extender can simplify installation and save cost. With its unlimited cascading capacity you can extend your digital video displays almost anywhere.
PAGE 3
System Devices and Functions Transmitter DVI-C5-S  Built-in EQ control to adjust the video quality  Built-in one RJ45 DVI Output  Built-in one HDMI input  Built-in one RJ45 port for system output which can be connected by Cat 5 / 5e / 6 cable and send signal to System Receiver Transceiver DVI-C5-R  Built-in EQ control to adjust the video quality  Built-in one RJ45 DVI Output  Built-in one RJ45 port for system output which can be connected by Cat 5 / 5e / 6 cable and send signal to System Receiver Co
PAGE 4
Cable and Accessories DVI to HDMI Cable (For Player) DVI to HDMI Cable (Included) Package Content DVI-C5 (Transmitter & Receiver Set)      DVI-D 1 Port Transmitter DVI-D 1 Port Reciever DVI to HDMI Cable 1.8m DC 5V 2A Adapter User Manual DVI-C5-R Receiver     DVI-D 1 Port Receiver DVI to HDMI Cable 1.8m DC 5V 2A Adapter User Manual www.avenview.
PAGE 5
Specifications Description Input Output Maximum Distance & Resolution DVI-C5-S DVI-C5-R 1 Port DVI-D Transmitter 1 Port DVI-D Transceiver HDMI (DVI – HDMI Connector) RJ45 x 1 DVI Female x 1 RJ45 x 1 With each cascading length: < 80m (275ft) @ 800x600 < 50m (175ft) @ 1024x768 < 40m (150ft) @ 1280x1024 Video Control Signal Type LED Power Consumption Dimensions EQ x 1 DVI-D Power and Activity DC 5V 650mA 68 x 42 x 19 www.avenview.
