Appendices
Appendix A: Technical Specifications
During the course of this product’s lifetime, modifications might be made to its hardware or
firmware that could cause these specifications to change without notice.
Table A.1: User Access Node Product Specifications
Network
Ethernet Standard Ethernet II
IP Port Usage Port 16384 - Video
Port 16385 - Audio
Port 16386 - Keyboard\Mouse
Ports 4463, 4464, 4465 - Control
Extension Ports
Number 1
Connectors RJ-45
User Ports
Number
PS/2: 2; USB: 4; DVI-I video: 1; audio microphone: 1; audio line
out: 1; power jack: 1
Type PS/2, USB Type A, DVI-I video
Connectors
6-pin miniDIN, PS/2 keyboard and mouse; USB Type A, USB
keyboard and mouse; DVI-I, female; 3.5 mm stereo audio
jacks, line out and mic; 2.5 mm DC power jack.
Encryption
Type Authenticated SSL
Console Port
Number 1
Type
Three-wire Serial interface: RX, TX, GND via 16450-compatible
UART
Connectors 9-pin D-Shell (DB9)
