Appendices 43
Video Resolution 640 x 350 @ 85 Hz
640 x 480 @ 60 Hz
640 x 480 @ 72 Hz
640 x 480 @ 75 Hz
640 x 480 @ 85 Hz
720 x 400 @ 70 Hz
720 x 400 @ 85 Hz
800 x 600 @ 60 Hz
800 x 600 @ 72 Hz
800 x 600 @ 75 Hz
800 x 600 @ 85 Hz
1024 x 768 @ 60 Hz
1024 x 768 @ 70 Hz
1024 x 768 @ 75 Hz
1024 x 768 @ 85 Hz
1152 x 864 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60 Hz
Check www.avocent.com for the latest list of supported video
resolutions and refresh rates.
Video Standard DDC version 2B
Color Depth 24 Bit
Audio Standard PC99
Audio Performance
High Performance Line out:
44.1 kHz over stereo channels at a resolution of 16 bits
Microphone:
44.1 kHz over a single channel at a resolution of 16 bits
Medium Performance Line out:
8 kHz over stereo channels at a resolution of 16 bits
Microphone:
8 kHz over a single channel at a resolution of 16 bits
Target Sync Types
(Analog output only)
Separate horizontal and vertical
Safety and
EMC Approvals and
Markings
UL, FCC, cUL, CE
Table A.1: User Access Node Product Specifications (Continued)
