MAGIC TH2 MAGIC TH2 RM ISDN, POTS & VoIP Telephone Hybrids Hardware/Software Manual
.
MAGIC ISDN, TH2plus POTS & & VoIP Hardware/Software MAGIC TH2plus Telephone RM Hybrids Manual To get automatically informed about the latest software, please register on our homepage: http://www.avt-nbg.de Please click on Create an account under the Log In section. Now you need to enter your name/company, a user name and a valid email address. Please click on Register to receive your confirmation email which includes the link to activate your account.
A publication of: AVT Audio Video Technologies GmbH Nordostpark 12 D-90411 Nuernberg Telephone +49-911-5271-0 Telefax +49-911-5271-100 Printed in Germany, May.2013 © AVT Audio Video Technologies GmbH All rights reserved. Reproduction in whole or in parts is prohibited without previous written consent of Audio Video Technologies GmbH. Subject to change. Release date: (05.
.
C o n t e n t Content INTRODUCTION SAFETY 11 13 Introduction 13 General Safety Requirements Conventions 13 14 1 CONSTRUCTION 15 2 SYSTEM DESCRIPTION 2.1 Functionality 3 PUTTING THE SYSTEM INTO OPERATION 19 3.1 Mounting 3.2 Connection to the mains voltage 3.3 Earthing of the system 3.4 Operating elements on the front side 3.5 Operating modes of the system 17 17 19 19 20 20 21 3.5.1 POTS operating mode 21 3.5.2 ISDN operating mode 3.5.
C o n t e n t 4.2.4 Accepting a call 4.2.5 Two connections 31 4.3 31 Comfort functions 31 4.3.1 Redialling 31 4.3.2 Using the phone book 32 4.3.3 Working with Presets 4.3.4 Send DTMF tones 34 4.3.5 Lock lines 34 32 5 WINDOWS PC SOFTWARE 5.1 Hardware requirements 35 5.2 User Registration 35 5.3 Installing the Windows PC software 35 5.4 Software update from the internet 36 5.5 The MAGIC TH2plus main window 37 5.5.1 5.5.1.1 Operating elements 35 38 Menu button 38 5.5.1.
C o n t e n t 5.7.2.2.4 POTS Interface: PABX 65 5.7.2.2.5 POTS Interface: Outside Line 5.7.2.2.6 VoIP (LAN/SIP) 68 5.7.2.2.7 Audio Interface 70 5.7.2.2.8 5.7.2.3 LAN Interface 72 Quick Dials 74 5.7.2.4 Date and Time 75 5.7.2.5 Login 5.7.3 67 76 Submenu Presets 78 5.7.3.1 Manage Presets 78 5.7.3.2 Activation of a Preset 80 5.7.4 Submenu DTMF Settings (Option) 80 5.7.5 Submenu Local Settings 81 5.8 Menu Administration 83 5.8.1 Submenu Registration 83 5.8.
C o n t e n t A2.1.2 S0 interface A2.1.3 LAN interface 115 A2.2 114 PRETALK interfaces 116 A2.2.1 HANDSET 1 & 2 interfaces 116 A2.2.2 PHONE 1 & 2 interfaces 116 A2.3 Audio interfaces 117 A2.3.1 Analogue Audio interface 117 A2.3.2 Digital AES/EBU Audio interface 117 A2.4 Control Interface 119 A2.4.1 LAN interface 119 A2.4.2 Keypad 1,2 interface 119 A2.4.3 TTL/RELAY interface 119 A2.
I n t r o d u c t i o n INTRODUCTION The MAGIC TH2plus system allows the forwarding of telephone calls to analogue and digital Audio interfaces. The connection to the telephone network can be established either via two analogue POTS interfaces or an ISDN interface or optionally via a LAN interface for Voice-over-IP. To optimise the caller signal each caller line has implemented its own digital Echo Canceller (approx. up to 100 msec), AGC (Automatic Gain Control) and Expander.
I n t r o d u c t i o n Handset Delete Opts. ON AIR HOLD PRETALK Call Out...
S a f e t y SAFETY Introduction The unit described has been designed to the latest technical parameters and complies with all current national and international safety requirements. It operates on a high level of reliability because of long-term experience in development and constant and strict quality control in our company. In case of normal operation the unit is safe.
S a f e t y Conventions In this manual, the following conventions are used as text markers: Emphasis: Product names or important terms LCD Text: Labelling on the front display of the system PC Text: Labelling in the PC software TIP NOTE The symbol TIP labels information which facilitates the operation of the system in its daily use. The symbol NOTE labels general notes to observe. ATTENTION The symbol ATTENTION labels very important advice that is absolutely to observe.
C o n s t r u c t i o n 1 CONSTRUCTION The functions of the MAGIC TH2plus are implemented in a single unit. The system is designed for mounting in a half 19" rack (1 U). Optionally, a dual mounting kit is available (MAGIC TH2plus DUAL 19“ Mounting Kit ID: 802002) for installing two MAGIC TH2plus systems next to each other. FIG. 1 FRONT VIEW: MAGIC TH2PLUS TELEPHONE HYBRID MAGIC TH2plus RM has full 19“ design (1 U) with an integrated power supply and provides a coloured keypad. FIG.
C o n s t r u c t i o n PAGE 16
S y s t e m 2 SYSTEM D e s c r i p t i o n DESCRIPTION The functional elements of the system are pictured in Fig. 3. FIG. 3 2.1 FUNCTIONAL ELEMENTS OF MAGIC TH2PLUS Functionality The MAGIC TH2plus system incorporates two POTS interfaces, an ISDN interface and a LAN interface. The operating mode can be set with the help of the Windows PC Software or the front keypad and display. In each operating mode two independent telephone hybrids are available within one system (channel 1 and channel 2).
S y s t e m D e s c r i p t i o n nel). The inputs have separate digital Sample Rate Converters (SRC). For synchronisation with an external clock a clock input and a clock output are available. Two separate PRETALK interfaces are available in all three operating modes. Two Telephone Handsets or Headsets (Options: ID: 802003/802004) can be connected for Pretalk. In the POTS operating mode you can connect two standard POTS Telephones for dialling and Pretalk.
P u t t i n g t h e s y s t e m i n t o o p e r a t i o n 3 PUTTING THE SYSTEM INTO OPERATION 3.1 Mounting With its dimensions (W × H × D) of 220 mm × 44,5 mm (1 U) × 220 mm the MAGIC TH2plus system can be either used as desktop device or mounted in a 19 inch rack. Corresponding 19“ mounting brackets are included in delivery. Optionally, a mounting kit (ID: 802002) is available to implement two MAGIC TH2plus next to each other 1.
P u t t i n g t h e s y s t e m i n t o o p e r a t i o n 3.3 Earthing of the system For EMC reasons an earthing via the earthing screw of the system must be carried out in either case. ATTENTION Earthing A lacking earthing can cause functional deficiencies within the unit. ! 3.4 Operating elements on the front side The system has an illuminated graphical display with a resolution of 160 x 32 Pixels and 21 operating buttons.
P u t t i n g 3.5 t h e s y s t e m i n t o o p e r a t i o n Operating modes of the system The following figures show the system in the different operating modes and their respective cablings. 3.5.1 POTS operating mode ATTENTION Earthing ! If the POTS interfaces are in operation, the system must be earthed via earthing screw for EMC reasons. If the earthing is not carried out, the Audio signal can be faulty on the caller’s side (humming).
P u t t i n g t h e s y s t e m i n t o o p e r a t i o n FIG.
P u t t i n g 3.5.2 t h e s y s t e m i n t o o p e r a t i o n ISDN operating mode In the ISDN operating mode, up to two handsets or headsets can be connected for PRETALK. The use of a POTS Telephone is not possible in this operating mode. FIG. 8 MINIMUM WIRING IN ISDN OPERATING MODE Analogue Audio 1/AES/EBU Input Analogue Audio 1/AES/EBU Output Power supply interface Option: Handset/ Headset ISDN interface The maximum wiring with all options is shown in Fig. 9.
P u t t i n g t h e s y s t e m i n t o o p e r a t i o n 3.5.3 LAN operating mode (VoIP option required) With the Software Option Extension for Voice over IP (ID: 430399) the system can be used as Voice-over-IP Telephone Hybrid for two callers using the LAN interface. Up to two handsets or headsets can be connected for PRETALK. The use of a POTS Telephone is not possible in this operating mode. FIG.
P u t t i n g 3.6 t h e s y s t e m i n t o o p e r a t i o n Applications Below you will find some example applications with MAGIC TH2plus. 3.6.1 MAGIC TH2plus with PC and Keypad control In the following drawing you can see MAGIC TH2plus controlled with a PC connected via LAN and the MAGIC TH2plus PC Software. A second workplace can access the system via a MAGIC TH2plus Keypad that is directly connected to the telephone hybrid. Both users have their own Pretalk lines.
P u t t i n g t h e s y s t e m i n t o 3.6.2 o p e r a t i o n MAGIC TH2plus with three PC workstations In the picture below MAGIC TH2plus is controlled via three PC workstations which are connected via LAN with the telephone hybrid. A caller line is automatically locked for the other users if one user works with that line. A caller in Hold status is available to all users. Each workplace has its own Pretalk line.
O p e r a t i o n 4 OPERATION VIA v i a D i s p l a y DISPLAY AND a n d K e y p a d KEYPAD In this chapter all significant settings to operate the MAGIC TH2plus system are explained. An overview of the menu structure can be found in the annex under CHAPTER A1. All configurations can also be set comfortably via the MAGIC TH2plus Software included in delivery. NOTE For details concerning most functions please see CHAPTER 5 of the software description. 4.
O p e r a t i o n v i a D i s p l a y a n d 4.1.3 K e y p a d Configuration of the LAN interface To configure the LAN interface follow the instructions below: – Press the Menu softkey. – Please mark the option System Settings via the cursor keys and press the Select softkey. – Use the cursor keys the Select softkey. and and to get to the option LAN settings and press – To enter or change the IP Address of the system, mark the option IP Address and press the Select softkey.
O p e r a t i o n 4.1.5 v i a D i s p l a y a n d K e y p a d Audio interface: Analogue or digital The MAGIC TH2plus has analogue as well as digital Audio interfaces which can be adjusted separately. The digital AES/EBU Audio input has an implemented Sample Rate Converter to adjust the digital Audio clock to the line clock. Additionally, clock inputs and outputs are available.
O p e r a t i o n v i a D i s p l a y a n d 4.2 K e y p a d Working with the MAGIC TH2plus In the following paragraphs basic functions like call out, dropping a connection, accepting a call etc. are described in detail. 4.2.1 Call out From the main menu just enter the phone number using the keys 0...9. After the first numeral the input field for the phone number is displayed automatically. Via the Delete softkey wrong entries can be corrected.
O p e r a t i o n 4.2.3 v i a D i s p l a y a n d K e y p a d Dropping a connection The connection can be dropped by pressing the telephone receiver button . If no other connection exists, the main menu is displayed after a few seconds. 4.2.4 Accepting a call If the MAGIC TH2plus receives a call, the status window automatically displays the Callin signal. The call is accepted directly via the telephone receiver button .
O p e r a t i o n v i a D i s p l a y 4.3.2 a n d K e y p a d Using the phone book The system incorporates a comfortable phone book function. The phone book can be reached from the main menu via the Names softkey. In the input field Search you can search for a certain subscriber. As soon as you enter a character, the phone book entries in demand are retrieved. Alternatively, you can select a subscriber from the list via the cursor keys and .
O p e r a t i o n v i a D i s p l a y a n d K e y p a d By the softkey OPTS (Options) the following functions which you can select via the softkey select are realized: – load: The selected Preset is loaded. – new: With the help of this function you can create a new Preset. All current Operation Settings are stored as basic and can be adjusted afterwards. – Save: The selected Preset is overwritten with the current Operation Settings.
O p e r a t i o n v i a D i s p l a y a n d 4.3.4 K e y p a d Send DTMF tones If the fee-based option DTMF is activated in your system (see CHAPTER 6), you have the possibility analyse DTMF tones via the PC software. The sending of DTMF tones is a standard feature. DTMF tones can be generated directly via the keypad of the system by pressing the numerical keys ’0’...’9’, ’ ’, or ’#’ during a connection.
W i n d o w s 5 WINDOWS PC P C S o f t w a r e SOFTWARE The configuration of the system can be carried out comfortably with the use of the Windows PC software included in delivery. 5.
W i n d o w s P C S o f t w a r e After the installation please start the software by clicking on the MAGIC TH2plus symbol. Connect the system via the LAN interface with your network. If you do not have a network you can also connect the unit to your PC directly via a socalled cross over network cable. How to configure the LAN interface is described below (see CHAPTER 5.7.1, Page 45).
W i n d o w s P C S o f t w a r e Operation via the Windows PC software In the following chapters, all functions of the PC software are described in detail. 5.5 The MAGIC TH2plus main window After starting the MAGIC TH2plus Software, the main window is displayed automatically (see Fig. 14). The connection status between PC and system is displayed in the upper right corner of the window: PC ONLINE: Connection is okay.
W i n d o w s P C S o f t w a r e FIG. 14 MAIN WINDOW OF THE MAGIC TH2PLUS SOFTWARE 5.5.1 Operating elements 5.5.1.1 Menu button Via the Menu button the configuration dialogue is opened so that you can configure the MAGIC TH2plus. 5.5.1.2 Global function keys: DROP ALL, LOCK ALL With the button DROP ALL you can drop all connection. With the button LOCK ALL you can lock all caller lines. The DROP Button will be displayed as purple LOCK button. To unlock the lines, press the button a second time.
W i n d o w s P C S o f t w a r e – Information If you want to enter or change the caller information, just click on the desired field and enter the new information. Additionally, the Male/Female/? button and the Positive/Negative/Neutral/? button are displayed next to the caller data fields. By clicking on the buttons you can change the setting.
W i n d o w s P C S o f t w a r e In contrast to this, when there is an outgoing call, the keys PRETALK, HOLD and ON AIR are displayed yellow and static whereas the key DROP is displayed yellow and blinking. Only the DROP button can be selected. 5.5.1.5 Status key: HD Voice If the fee-based HD Voice Upgrade (ID: 430465) has been activated and the system is used in the Voice-over-IP operating mode, this status key shows that the connection has been established with G.722 in 7-kHz quality. 5.5.1.
W i n d o w s 5.5.1.7 P C S o f t w a r e Telephone Book/Manual Dialing To open the Telephone Book you must click on the PRETALK, HOLD or ON AIR button of one of the caller lines when no connection is established. The Dialing window is opened. Via this window, you can dial out manually or use an existing telephone book entry. To dial out manually, use the numerical buttons and click on CALL.
W i n d o w s P C S o f t w a r e To delete the selected entry, click on Delete. To edit the selected entry, click on Edit. To create a new entry, click on the New button. The Edit Caller Entry is opened where you can enter the caller details. FIG. 18 EDIT CALLER ENTRY Now you can enter Name, First Name, Street, ZIP (Postal Code) and Town. For each caller you can save up to three numbers. The labels for the number types can be defined under Operation Settings → Database → Telephone Book.
W i n d o w s FIG. 19 P C S o f t w a r e LEVEL METER Additionally, the received level of the caller can be manually increased or decreased in the range of -16dB and +16dB separately for each caller line. FIG. 20 5.5.1.10 LEVEL CONTROL AGC on/off button For each caller line you can switch on an Automatic Gain Control. This can be selected in the configuration under System → Operation Settings → Signal Processing or you simply use the AGC button next to the level control of each caller line.
W i n d o w s P C S o f t w a r e 5.6 Menu File FIG. 22 5.6.1 MENU FILE Submenu System Settings Via the submenu System Settings you can import or export system settings. With the selection File → System Settings → Import you can import a complete system configuration (all settings made under System Settings: General, Line Interface, MSN, POTS interface: Outside Line, POTS Interface: PABX, VoIP, Audio Interface, LAN Interface and Quick Dials) from a data carrier. The file extension is always .TH2.
W i n d o w s 5.7 S o f t w a r e Menu Configuration FIG. 23 5.7.1 P C MENU CONFIGURATION Submenu Control Interface Preferably, the system is configured and operated via the LAN interface. Alternatively, you can also operate the system via the RS232 interface. LAN For controlling the system via the LAN interface please select Interface UDP. FIG. 24 → LAN PARAMETERS Under Parameter → Interface edit .
W i n d o w s P C S o f t w a r e Please enter the correct IP address of the system under IP Address and the correct Port under Port. TIP The currently allocated IP address of the system can be displayed by pressing the telephone button on the front keypad of the system twice if currently no Audio connection is established. RS232 If you want to use the RS232 interface, connect the serial RS232 interface via a 1:1 connecting cable with your PC. Please select now under Interface → RS232.
W i n d o w s FIG. 26 P C S o f t w a r e CONTROL INTERFACE LIST PARAMETER By the key Edit you can edit the currently selected entry. With Delete you can cancel the list entry. 5.7.2 Submenu System Via the submenu System the system can be configured comfortably. It is distinguished between System Settings, which do not have to be changed during the operation and the Operation Settings for the current application. 5.7.2.1 Operation Settings Operation Settings can be saved as Presets (see CHAPTER 5.
W i n d o w s P C S o f t w a r e – One Fader: Both ON AIR caller signals are available at one Audio output. You can define which Audio interfaces are used for the ON AIR line and the Pretalk lines. – Two Faders: The ON AIR caller signals are available at separate Audio outputs (ON AIR 1 and ON AIR 2). You can define which Audio interfaces are used for the ON AIR and Pretalk lines. – Shared: The system is operated exactly like the MAGIC TH2 i. e.
W i n d o w s P C S o f t w a r e • To allow Pretalk or/and ON AIR conferences, the options PRE TALK Conference or/and ON AIR Conference must be enabled. If you do not activate these options, only one caller is allowed to be in Pretalk or/and ON AIR at a time. As soon as a second caller is switched to Pretalk or ON AIR, the first caller is automatically switched to HOLD. • If you want to use only one caller line, you can select the option Use only 1 ISDN line/Use only 1 POTS line/Use only 1 VoIP line.
W i n d o w s P C S o f t w a r e • If you want to assign a different name to the Audio line to be displayed in the PC Software, you can enter a new name under Custom Label. • To select the default settings for your selected operating mode, please click on Default Settings. For safety reasons you must confirm that you really want to select the default settings.
W i n d o w s 5.7.2.1.2 P C S o f t w a r e HOLD Signal The configuration of a HOLD signal can be done under Hold Signal. FIG. 31 RECORDED HOLD SIGNAL General settings • Under the setting HOLD signal source you can select the HOLD signal that you want to use. With the option ON AIR the signal which is transmitted via the AUDIO 1 interface is used as HOLD signal. If you select Recorded Hold Signal, the caller hears the Audio signal stored in the system. The signal is identical for both lines.
W i n d o w s P C S o f t w a r e 5.7.2.1.3 Signal Processing Under Signal Processing you can configure the AGC (Automatic Gain Control), the Echo Canceller as well as the Expander. FIG. 32 SIGNAL PROCESSING Line Settings • A separate Automatic Gain Control (AGC) can be switched on for both channels. ATTENTION An Automatic Gain Control is reasonable if you do not have the possibility for Pretalk during which the level can be adjusted. ! But: An AGC is no wizard.
W i n d o w s P C S o f t w a r e To activate the Expander select the desired line with your mouse. To switch off the Expander select Off. To switch it on select On. Via the button Set Expander on/off for all lines you can switch on respectively switch off the Expander for all lines. Automatic Gain Control Settings (AGC)/Expander The correct functioning of the AGC can be optimised via several parameters. • Threshold: The AGC does not start before the signal exceeds the threshold value set here.
W i n d o w s P C S o f t w a r e • To enable the use of a database, please select Database and enter the correct path under Database Path. Via Browse you can search for the correct folder. • The path of the System Database is usually entered automatically when the software is installed. By default, the file Screener.mdw is saved in the installation directory.
W i n d o w s 5.7.2.1.6 P C S o f t w a r e Relay / TTL The MAGIC TH2plus system incorporates four GPIO Pins (TTL) which can be programmed separately as input or output. Additionally, two Relays are available. The operating mode of a TTL Pin - Input or Output - is selected via the option Direction. The following specification accounts for all three configuration windows TTL1, TTL2, TTL3 and TTL4. TTL Pin as input FIG.
W i n d o w s P C S o f t w a r e – Set Audio Line: This function allows you to switch a caller to a pre-defined Audio Line. Under POTS/ISDN Line you must indicated which caller line you want to use (1 or 2). – Lock Audio Line (Level Trig.): With this function you can lock an Audio Line. Under POTS/ISDN Line you must indicated which caller line (1 or 2) is locked for the selected Audio line. This function is level triggered.
W i n d o w s P C S o f t w a r e TTL Pin as Output ATTENTION Please pay attention to the maximum switch current of 10 mA respectively the maximum switch voltage of 3.3V per TTL output. ! FIG. 38 TTL PIN AS OUTPUT If a TTL Pin is configured as Output, the event is signalised as change of voltage on the TTL Pin from 0V to+3.3V. Under Positive edge you can select one of the following Function Codes: – Fixed Low: The TTL Pin is set to 0V permanently. – Fixed High: The TTL Pin is set to +3.3V permanently.
W i n d o w s P C S o f t w a r e – ON AIR: If you select this function, it is signalled when a caller is switched to ON AIR. Under POTS/ISDN Line you select if you want to signal the ON AIR status of Line 1, Line 2 or both lines (Any). If you select Any, the signal is set on the TTL Pin as soon as one of the lines is switched to ON AIR. – PRETALK: If you select this function, it is signalled when a caller is switched to Pretalk.
W i n d o w s P C S o f t w a r e The functions for programming the relays are identical with the function codes for the TTL output.The following Function Codes are available: – Always open: The relay contacts are always open. – Always closed: The relay contacts are always closed. All further function codes are explained under TTL Pin as Output on Page 57.
W i n d o w s P C S o f t w a r e 5.7.2.2 System Settings 5.7.2.2.1 General FIG. 40 GENERAL Display Language • Currently English and German are available as display languages. Front Keypad • To activate the key tone, check the Enabled box. Display • The Display has a backlight. Under the setting Backlight you can switch it ON permanently. If you select the option Auto the backlight is turned off automatically 60 seconds after the last keystroke.
W i n d o w s P C S o f t w a r e PC control via RS232/Keypad 1 • If you want to operate the system with the PC via RS232 or you want to use a MAGIC TH2plus Keypad, you must set the data rate in accordance with the interface. There are five baud rates available: Keypad (9600 Baud, None), PC (19200 Baud, None), PC (38400 Baud, None), PC (57600, None) and PC (1152000, None). NOTE The MAGIC TH2plus Keypad supports only the baud rate 9600 Baud.
W i n d o w s P C S o f t w a r e FIG. 42 LINE INTERFACE - POTS General • Via the option Line Mode you can select the line interface. The following configurations are possible: – ISDN: The system is connected to the ISDN network. – POTS: The system is connected to analogue telephone lines. – VoIP: The system is connected to the IP network. NOTE ISDN The line mode VoIP can only be selected if the fee-based Extension for Voice over IP option (ID: 430399) is enabled in your system.
W i n d o w s P C S o f t w a r e Depending on your selection the menu items POTS Interface: PABX and/or POTS interface: Outside Line are displayed on the left side of the configuration window. In this way you can configure the settings for the POTS interfaces individually. This feature is especially helpful if you operate one POTS interface via a PABX and the other POTS interface is connected to an outside line.
W i n d o w s P C S o f t w a r e Line Level Output Offset • Under Attenuation you can adjust the Line Level Output Offset within the range of - 16 dB ...0 dB. The default setting is -6 dB. ISDN 5.7.2.2.3 MSN NOTE An MSN can only be set if the ISDN operating mode is selected (see CHAPTER 5.7.2.2.2, Page 61). If you have not selected ISDN as your operating mode, this menu item is not displayed. FIG. 43 MSN Normally, an MSN entry is not necessarily required.
W i n d o w s FIG. 44 POTS 5.7.2.2.4 P C S o f t w a r e CALLED NUMBER LABELS POTS Interface: PABX If you operate the MAGIC TH2plus in the POTS mode and one of your POTS interfaces is connected to a PABX, you can adjust the settings for the POTS interface here. NOTE You must select PABX as Line Type under Line Interface to get this menu item displayed (see Page 62). FIG.
W i n d o w s P C S o f t w a r e POTS: PABX Under Country Setting you can select which country-specific POTS interface you use.. NOTE TIP This setting is important for the Audio quality. The impedance of the POTS interface may vary from country to country and the Echo Canceller of the system can only work correctly if the right Country Setting is selected. If your PABX has been manufactured in a different country, you should also try the origin country as Country Setting.
W i n d o w s POTS 5.7.2.2.5 P C S o f t w a r e POTS Interface: Outside Line If you operate the MAGIC TH2plus in the POTS mode and one of your POTS interfaces is connected to an outside line, you can adjust the settings for the POTS interface here. NOTE You must select PABX as Line Type under Outside Line to get this menu item displayed (see Page 62). FIG. 46 POTS INTERFACE: OUTSIDE LINE For configuration see POTS Interface: PABX (see CHAPTER 5.7.2.2.4, Page 65).
W i n d o w s VOIP P C S o f t w a r e 5.7.2.2.6 VoIP (LAN/SIP) If you operate MAGIC TH2plus in the VoIP mode (only with the fee-based option „Extension for VoIP“, Id. 430399, available), you need to configure the settings for the IP connection and the SIP Server under this menu item. FIG. 47 VOIP (LAN/SIP) In the upper part of the window the settings for the SIP Server can be configured.
W i n d o w s P C S o f t w a r e • Decoder Buffer Size: If the Decoder Buffer Mode is set to Fixed, you can select the buffer size within the range of 20 ... 2000 msec. ATTENTION If you experience packet loss, please try to set a larger buffer. ! • Encoder Packet Size: To optimise the total delay, the size of the encoder packets can be adjusted. The IP Overhead will be minimised when a larger packet size is selected.
W i n d o w s P C S o f t w a r e 5.7.2.2.7 Audio Interface MAGIC TH2plus supports analogue as well as digital AES/EBU Audio interfaces. If the digital Audio inputs are used, a Sample Rate Converter is available so that external adjustments are not required if there are different digital sources and drains. FIG. 48 AUDIO INTERFACE Mode • The operating mode analogue or digital can be set separately for the Audio Input and the Audio Output.
W i n d o w s P C S o f t w a r e Main Nominal Level of XLR Audio 1 and 2 • If you use the analogue input or the output, the corresponding slide control for adjusting the nominal Audio level of the ON AIR interface is displayed. The nominal level can be adjusted separately for the input (Level In) and the output (Level Out) in the range of -3 ... +9 dBu in 1 dB steps. Handset 1 and 2 • If you use a handset for Pretalk, you can adjust the settings for the level under Handset 1 and 2.
W i n d o w s P C S o f t w a r e 5.7.2.2.8 LAN Interface Under LAN Interface the configuration of the LAN Interface and the entry of the FIG. 49 LAN INTERFACE IP Address • To automatically get the correct LAN settings for your system, you can activate the option DHCP (Dynamic Host Configuration Protocol), if a DHCP Server is available. Alternatively, you can also adjust the settings manually. • Under IP Address you need to enter the IP address of your system.
W i n d o w s P C S o f t w a r e Control UDP Port Addresses • Under Control UDP Port Addresses you must enter the Port Addresses of the PCs that are connected to the MAGIC TH2plus. You can have access to the system simultaneously via maximum three PCs. NOTE You can only use more than one PC, if you have more than one MAGIC TH2plus PC Software Licence (fee-based, ID: 430396).
W i n d o w s P C S o f t w a r e 5.7.2.3 Quick Dials Up to 10 Quick Dial keys 0...9 can be programmed in the system. FIG. 50 QUICK DIALS • You can program either a Number or a Preset as Quick Dial. • If you want to program a Number, you must enter the telephone number and additionally select if you want to establish the connection on Line 1, Line 2 or on the First free line. Furthermore, you must select to which Audio line the called person is to be switched when he answers the call.
W i n d o w s 5.7.2.4 P C S o f t w a r e Date and Time • Under Date and Time you can program the system date and time. • Via the button Transmit PC Time you can synchronise the system time with the PC time. • The button Transmit User Defined Time allows you to set a different time. This function is helpful, if you want to use the system e.g in a different time zone. FIG. 51 DATE AND TIME. ATTENTION During a power breakdown the integrated system clock is buffered by an internal battery.
W i n d o w s P C S o f t w a r e 5.7.2.5 Login To protect the system from reconfigurations, two password levels with different user rights are available. ATTENTION The entered password is saved in the system. If you have forgotten your password, only the AVT Service can re-activate the system. ! • Under USER you assign the user Password. For safety reasons you must confirm the password under Confirm Password. • Under ADMINISTRATOR you assign the Administrator Password.
W i n d o w s P C S o f t w a r e – Configuration → Presets → „Configuration Name“ – Extras → System Monitor (2) Only User Password is configured: The password must always be entered. Afterwards all menus are available. Immediately available menu: – Extras → System Monitor (3) User Password and Administrator Password are configured: The password must always be entered. – User Password is entered: Under Configuration → Configuration → Login the USER password can now be changed.
W i n d o w s P C S o f t w a r e 5.7.3 Submenu Presets Via Presets you can edit, delete or load already existing Presets or create new ones. 5.7.3.1 Manage Presets Your created Presets can be managed via the menu Configuration → Presets → Manage Presets. FIG. 54 MANAGE PRESETS All already existing Presets are displayed in the list. • With the use of the New button you create a new Preset. The current configuration of the system is not changed by this function. First, select an meaningful name.
W i n d o w s FIG. 56 P C S o f t w a r e EDIT PRESET • By using the button Edit the currently selected Preset can be edited. The current configuration of the system is not changed with this function. • Via the button Delete the Preset selected from the list is deleted. For safety reasons you have to confirm your selection. FIG. 57 CONFIRMATION TO DELETE A PRESET • To activate a Preset selected from the list, press the Select button. For safety reasons you have to confirm your selection. FIG.
W i n d o w s P C S o f t w a r e • Likewise, it is possible to export Presets to a data carrier. The button Export saves the Preset selected from the list as .T2P file. By clicking on the button the file browser is opened and you can choose the location where the file is saved. • With Export All all Presets displayed in the list are saved in a directory of your choice. A separate data file with the file extension .T2P is generated for each Preset. TIP 5.7.3.
W i n d o w s 5.7.5 P C S o f t w a r e Submenu Local Settings Under Local Settings you can decide if you want to store the settings of your configuration only for the current user or globally for all users. Additionally, you can change the layout of the user interface. FIG.
W i n d o w s P C S o f t w a r e FIG. 64 LOCAL SETTINGS - SETTINGS LOCATION Settings location • To store your settings only for the current user, select the option Local settings only valid for current user. • To store the settings globally for all users, select the option Local settings valid for every user. • Alternatively, you can select the option Store settings in custom path to define a specific folder in which your settings are stored.
W i n d o w s 5.8 S o f t w a r e Menu Administration FIG. 65 5.8.1 P C MENU ADMINISTRATION Submenu Registration The serial number of the system as well as the enabled options are displayed under the submenu Registration. FIG.
W i n d o w s P C S o f t w a r e Features • Under Features the available and activated Software Options of the MAGIC TH2plus are displayed. The options listed here can be activated via a password. This password is assigned according to the Factory Number. If you bought an option supplementarily, please enter the password that you received from us under Enter software option password. FIG. 67 PASSWORD ENTRY TO ENABLE AN OPTION Subsequently, the system executes a warm start.
W i n d o w s 5.8.2 P C S o f t w a r e Submenu File System By selecting the submenu File System the file directory of the system (similar to the harddisk of a PC) is displayed. ATTENTION Please do not carry out any actions under File System unless our support asked you to. ! FIG. 68 SUBMENU FILE SYSTEM Via the button Delete File the currently selected file is deleted from the system. ATTENTION Do not delete a file unless our service told you to delete the file.
W i n d o w s P C S o f t w a r e 5.8.3 Submenu System Panel The System Panel is only for service purposes. Please enter only commands in the prompt, if our Support requests it from you. FIG.
W i n d o w s 5.8.4 P C S o f t w a r e Submenu Firmware Download The required firmware for the MAGIC TH2plus system is always included in the PC software: Via the Firmware Download you can comfortably download the firmware on your system. By using the Browse button you select the firmware file. It is always located in the same directory in which you installed the MAGIC TH2plus application. The standard installation directory is: C:\Program Files\MAGIC TH2plus The file name of the firmware is „th2plus.
W i n d o w s P C S o f t w a r e 5.8.5 Submenu Factory Settings By using the submenu Factory Settings the system can be reset to the initial state. For safety reasons you have to confirm your selection. FIG.
W i n d o w s 5.9 S o f t w a r e Menu Extras FIG. 72 5.9.1 P C MENU EXTRAS Submenu System Monitor Via the menu System Monitor you receive information about the system status. FIG. 73 SUBMENU SYSTEM MONITOR Error Counter • Under System alarms all potential system alarms are displayed. A red LED signalises a currently existing alarm. The error counter shows how often the alarm occurred after the unit has been connected to power.
W i n d o w s P C S o f t w a r e – FLASH EPROM: The communication with the permanent memory is faulty. Configurations cannot be saved or read anymore. – Ethernet MAC: The initialization of the ethernet module has failed. – Overheated: The system sets this alarm if the system temperature is higher than 57°C. Disconnect the unit from electricity or cool down the ambient temperature. – MAIN EEPROM: The communication with the permanent memory is faulty. Configurations cannot be saved or read anymore.
W i n d o w s P C S o f t w a r e – STUN state • The IP address of the Control PC connected to the system is shown under Connected PCs.
W i n d o w s P C S o f t w a r e 5.10 Menu About MAGIC TH2plus In the About MAGIC TH2plus dialogue you find the version of the PC software (PC Version) and the Firmware Version. Besides, you can find our contact details there. FIG.
O p t i o n : 6 OPTION: DTMF TONE D T M F T o n e A n a l y s e r ANALYSER With the fee-based option DTMF 1 Tone Analyser Plug-In you have the possibility to analyse DTMF tones. The sending of DTMF tones is a standard feature and included in the delivery scope. 6.1 DTMF system functions 6.1.1 DTMF call initiation via the Audio inputs You can also initiate a call using DTMF tones via the Audio inputs of the system.
O p t i o n : D T M F T o n e A n a l y s e r 6.2 DTMF PC Software functions To configure the DTMF function via PC, select the submenu Configuration → DTMF Settings. FIG. 76 6.2.1 DTMF SETTINGS DTMF Modes To activate the PC DTMF function, select Standard, Game Show or Event Mode under Mode and press OK. Subsequently, the DTMF buttons are displayed in the main window. FIG.
O p t i o n : D T M F T o n e A n a l y s e r to give the right answer. A re-pressing of a key on the telephones of the partners is ignored by the system. A new analysis is not carried out before the button RESET DTMF is used and the display has been reset. FIG. 78 (3) FIG. 79 DTMF GAME SHOW MODE Event Mode: This Mode should be selected if you want the callers to signal you an event, e.g. you have two reporters in line commenting different sport matches.
O p t i o n : PAGE 96 D T M F T o n e A n a l y s e r
O p t i o n : 7 OPTION: MAGIC M A G I C TH2PLUS T H 2 p l u s K e y p a d KEYPAD The optional MAGIC TH2plus Keypad enables users, who do not use a PC to operate the hybrid and who do not want to use the front display, to operate the system in an easy and comfortable way. You can connect up to two MAGIC TH2plus Keypads to the MAGIC TH2plus. NOTE To use the keypad with the MAGIC TH2plus, you must set the parameters for the RS232 interface to 9600 Baud, no parity.
O p t i o n : M A G I C T H 2 p l u s K e y p a d Please connect the 9-pole SUB-D connector of the MAGIC TH2plus Hybrid Keypad with the RS232 interface (see CHAPTER A2.4, Page 119) of the MAGIC TH2plus System. Since the MAGIC TH2plus Hybrid Keypad requires its own power supply, please plug in the external power supply included in delivery and connect the 6-pole Mini-DIN socket of the external power supply with the 6-pole Mini-DIN connector of the MAGIC TH2plus Hybrid Keypad.
O p t i o n : M A G I C T H 2 p l u s K e y p a d – If there is a connection error, the ISDN provides various alarm messages. Please see the following table for their meanings. The LCD display shows the relevant B channel first followed by the alarm message. TAB. 2 ISDN ALARM MESSAGES Alarm message Description Unass. number The number is not recognised by the ISDN. Please check your entry No route No route. When this message appears the ISDN is normally overloaded. Please dial again.
O p t i o n : M A G I C T H 2 p l u s 7.2 K e y p a d Keypad Functions Below you will find the keypad functions listed in table form. TAB. 3 KEYPAD FUNCTIONS Function key Description After pressing the key the last cypher of an entry is deleted. C Partly, this key is used to terminate an operation. By pressing this key you can delete the entire entry. AC 9 0 * # QD QD 0/5 4/9 Via the keys 0...9 it is possible to enter a phone number.
O p t i o n : TAB. 3 M A G I C T H 2 p l u s K e y p a d KEYPAD FUNCTIONS Function key PRETALK HYBRID 1/2 Description The caller on the respective channel is set in the PRETALK mode. The PRETALK can be carried out via the handset or in the analogue POTS operating mode via a standard telephone. If a caller on the other channel is already in PRETALK, he is set automatically in HOLD mode. HOLD HYBRID 1/2 The caller is set in the HOLD mode.
O p t i o n : PAGE 102 M A G I C T H 2 p l u s K e y p a d
M e n u A1 MENU S t r u c t u r e STRUCTURE On the following pages you will find the complete menu structure if you select English as your menu language. From the main menu you reach the phone book directly via the softkey Names. If you use the softkey Menu you go to the configuration of the system.
M e n u S t r u c t u r e A1.
M e n u S t r u c t u r e P A G E 10 5
M e n u S t r u c t u r e A1.
M e n u S t r u c t u r e See next page P A G E 10 7
M e n u PAGE 108 S t r u c t u r e
M e n u A1.
M e n u S t r u c t u r e A1.
M e n u A1.
M e n u S t r u c t u r e A1.
I n t e r f a c e s A2 INTERFACES The interfaces of the systems are pictured in Fig. 81. FIG. 81 REAR VIEW OF THE MAGIC TH2PLUS TELEPHONE HYBRID FIG. 82 REAR VIEW OF THE MAGIC TH2PLUS RM TELEPHONE HYBRID All interfaces are described below.
I n t e r f a c e s A2.1 POTS, ISDN and LAN interfaces A2.1.1 POTS 1 & 2 interfaces These interfaces are used to connect the system to analogue telephone lines. 1 TAB.
I n t e r f a c e s A2.1.3 LAN interface Via this interface you can control the system via a PC. If the fee-based software option Extension for Voice over IP (ID: 430399) is enabled, you can connect your system to a LAN network for VoIP. 1 8 TAB.
I n t e r f a c e s A2.2 PRETALK interfaces A2.2.1 HANDSET 1 & 2 interfaces To these interfaces you can connect a telephone handset/headset for the PRETALK. ATTENTION Pin assignment not standardised Please note that the Pin assignment of the telephone receivers is not standardised. Additionally, it is important to consider the correct polarity of the Phantom Power. ! MAGIC TH2plus Telephone Handsets and MAGIC TH2plus Telephone Headsets are optionally available. 1 4 TAB.
I n t e r f a c e s A2.3 Audio interfaces The system incorporates analogue and digital AES/EBU Audio interfaces. The interfaces can be configured via the front display and keypad or via the PC software. A2.3.1 TAB. 9 Push 2 Analogue Audio interface 1 3 PIN ASSIGNMENT: ANALOGUE INPUT (AUDIO 1/2 IN) Socket: XLR Pin Signal Electrical characteristics 1 Analogue GND Incoming level: adjustable -3 .... +9 dBu 2 AUDIO IN a Impedance: > 25 kΩ 3 AUDIO IN b Head room: 6 dB TAB. 10 2 1 3 A2.3.
I n t e r f a c e s TAB. 13 Push 2 1 3 PIN ASSIGNMENT: CLOCK INPUT (CLK IN) Socket: XLR Pin Signal Electrical characteristics 1 Analogue GND TTL 2 CLOCK IN 3 not used TAB.
I n t e r f a c e s A2.4 Control Interface A2.4.1 LAN interface Please see A2.1.3, Page 115. A2.4.2 Keypad 1,2 interface To this interface you can connect an external MAGIC TH2plus Keypad to control the system. If you want to connect two Keypads simultaneously, you need an adapter cable. Alternatively, if you don’t want to use the LAN interface to connect a PC to MAGIC TH2plus, you can also use the RS232 interface.
I n t e r f a c e s A2.5 Power supply interface The power supply is connected via an external power supply adapter. TAB. 17 3 1 2 PAGE 120 PIN ASSIGNMENT: POWER SUPPLY Socket: KYCO KPJ-S3 Pin Signal Electrical characteristics 1 GND Voltage: +12V 2 +12V Power: max.
T e c h n i c a l A3 TECHNICAL DATA MAGIC D a t a TH2PLUS CODING ALGORITHMS – G.711 A-Law 3,1-kHz (Telephone algorithm) – G.722 (optional with HD Voice Upgrade in VoIP mode) LINE INTERFACES: – ISDN – 1 x S0 I.430 RJ45 – Protocol DSS-1, NI-1, Japanese ISDN – POTS – 2 x POTS RJ12 – LAN – 1 x LAN RJ45 PRETALK INTERFACES – Handset/Headset interface – 2 x HANDSET RJ10 – Telephone interface – 2 x PHONE RJ12 CONTROL INTERFACES – LAN RJ45 – RS232 V.
T e c h n i c a l D a t a AUDIO INTERFACES Analogue Audio 1/2: – Electronically balanced input XLR female – Electronically balanced input XLR male – Nominal level -3 ... +9 dBu (can be programmed) – Head room 0 ... 15 dBr (can be programmed) – Impedance Input: Output: > 25 kΩ 50 Ω – Frequency response 50 Hz ...
T e c h n i c a l D a t a – Echo Canceller per channel (100 msec echo cancelling time) – Expander per channel, configurable DISPLAY - graphical resolution 160 x 32 Pixel - illuminated (can be switched off) POWER SUPPLY VIA EXTERNAL ADAPTER Direct Voltage (DC) – + 12 V Power Consumption – max. 15 W DIMENSIONS HxWxD – 44 x 220 x 220 mm WEIGHT – ca.
T e c h n i c a l D a t a A4 TECHNICAL DATA MAGIC TH2PLUS KEYPAD A4.1 Keypad Matrix: 8x6 (32 keys 4 quad keys, 4 double keys, 24 single keys) FIG. 83 CONNECTING CABLE MAGIC SYSTEM - KEYPAD to power supply adapter (1) (2) (3) to MAGIC TH2plus Telephone Hybrid to Keypad Protocol: 9600 Baud no parity Connection to external power supply adapter (1): 6-pol. Mini-DIN connector Assignment: 6 5 3 4 1 Pin 3: Pin 4: 2 GND (Ground) +5V Connection to MAGIC TH2plus (2): 9-pol.
T e c h n i c a l D a t a Connection to keypad (3): 8-pol. MINI DIN connector Assignment: Pin 2: Pin 3: Pin 4: Pin 5: A4.2 clock +5V Data GND (Ground) LCD Display 2 x 20 characters illuminated A4.3 Power supply: 5V, max. 500 mA Connection: 6-pol.
G e n e r a l A5 GENERAL A5.1 Order numbers MAGIC TH2plus Telephone Hybrid 802000 Accessories MAGIC TH2plus Hybrid Keypad 802001 MAGIC TH2plus DUAL 19“ Mounting Kit 802002 MAGIC TH2plus Telephone Handset with Handset Rest 802003 MAGIC TH2plus Telephone Headset 802004 POTS Telephone with Display 1 490101 GSM Adapter 1 490135 Portable Case 490152 Software Options Extension for Voice over IP 430399 MAGIC TH2plus Software Licence (one is included in delivery, 3 max.
G e n e r a l A5.2 Scope of delivery – MAGIC TH2plus Telephone Hybrid – CD Windows PC Software – External Power Supply Adapter Input: 100 - 240V/24W, 50 - 60 Hz Output: 12V – Self adhesive feet – 19’’ Mounting brackets – Manual – 1 x S0 cable – 2 x POTS telephone cable A5.3 Declaration of conformity The declaration of conformity you will find at the end of this manual.
S e r v i c e I n f o r m a t i o n A6 SERVICE INFORMATION A6.1 Software Updates On our homepage you can download software updates for free. Go to http://www.avt-nbg.de and select Download - Software. A6.2 Support You can contact our Support Hotline during the normal office hours between 09.00h - 17.00h (GMT+1) under the following telephone number: +49 911 5271 160 or via E-Mail under support@avt-nbg.
I n d e x INDEX Symbols # 34 * 34 .
I n d e x D Database 40, 54 Database Path 54 Date/Time 32 Declaration of Conformity 127, 135 Decoder Buffer Mode 68 Decoder Buffer Size 69 Default Settings 50, 53 Default Value 53 Delay 68, 69 Delete 30, 31, 33, 79 Delete Entry 32 Delivery 127 DHCP 45 Dialing window 41 Digital 29, 70 Dimensions 123 Direction 55 Disable Lock Function 62 Disable lock function 38 Disconnect 57 Display 17, 18, 60, 117 Display called number on incoming call 64 Display Contrast DAC 90 Display illumination 27 Disturbance 69 Downl
I n d e x HOLD signal source 51 Homepage 35, 128 Hook Flash Duration 66 Hotline 128 Humidity 123 Humming 21 I I.
I n d e x O Off 52, 53 On 52, 53, 60 ON AIR 17, 30, 39, 51, 58 ON AIR Access 49 ON AIR Conference 49 One Fader 48 Only one channel 49 Operating Mode 21, 47 Operation 13 Operation settings 103 Options 83 Order numbers 126 Outgoing call 40 Output 55, 57 Output level 122 Outside Line 62 P PABX 62, 64 Packet loss 69 Packet size 69 Password 76, 84, 103 Pause between repetition 51 PBX 63 PC (1152000, None) 61 PC (19200 Baud, None) 61 PC (38400 Baud) 61 PC (38400 Baud, None) 61 PC (57600, None) 61 PC control via
I n d e x Signal Processor 17 Signal to Noise Ratio 122 SIP Server 68 Skip prefix number on incoming call 63 Slow 53 Softkey 20 Software 27 Software Download 36 Software Options 84 Software Updates 128 Special Characters 78 Speed 53 Standard 94 Standby 19 Start 51, 87 Status information 103 Status Window 30 Stop 51 Storage 13 STUN Server 68 Subject Number 83 Subnet Mask 72 Subnetz 72 Support 86, 128 Switch current 57 Switch voltage 57 synchronous 70 System alarm 89, 90 System Database 54 System Monitor 77,
I n d e x P A GE 1 3 4
-Konformität DECLARATION OF CONFORMITY Name des Anbieters: Supplier’s name: AVT Audio Video Technologies GmbH Anschrift des Anbieters: Supplier’s address Nordostpark 12 D-90411 Nürnberg erklärt, daß das Produkt declares, that the product Produktname(n): Product name(s): MAGIC TH2plus Telefonhybrid 802000 MAGIC TH2plus RM Telefonhybrid 802005 MAGIC TH2plus Telephone Hybrid 802000 MAGIC TH2plus RM Telephone Hybrid802005 mit den Vorschriften folgender Europäischer Richtlinien übereinstimmt: conforms to
