User's Manual

AXIS Q6035 PTZ Dome Network Camera
Video and Audio
Audio Settings
The audio functionality for each video stream is enabled under Video & Audio > Video Stream > Audio.
Note
A multi-connector cable (available from Axis;
Multi-Connector Cable (sold separately) ) is required when connecting external
audio equipment to the Axis product.
Audio Modes
The Axis product supports the following audio modes:
Full duplex - Simultaneous two-way audio allowing the Axis product to transmit and receive audio a t the same time. There is no
echo cancellation; if feedback loops appear, try moving the microphone or the speaker.
Half-duplex - Audio can be transmitted to and from the Axis product but only in one direction at a time. To transmit audio using the
Live View pag e, use the Talk and Listen buttons, see
AMC Audio Controls, on page 10 .
Simplex — speaker only - Audio is transmitted from a client to the Axis product and can be played by a speaker connected
to the product. To transmit audio using the Live View page, the Talk and Microphone buttons must both be active, see
AMC
Audio Controls, on page 10
.
Simplex — microphone only - Audio captured by the product microphone is transmitted from the Axis product to one or more clients.
To set the audio mode, go to Video & Audio > Audio Settings and select the desired mode from the Audio mode drop-down list.
Audio Input
An external microphone or a line source can be connected to the product’s Audio-in connector. Config u re the audio input settings
under Video & Audio > Audio Settings.
Note
A multi-connector cable (available from Axis;
Multi-Connector Cable (sold separately) ) is required when connecting external
audio equipment to the Axis product.
Source - Select Microphone for an external microphone or Line for a Line in d
evice, e.g. an audio mixer for multiple microphones or
a microphone with a built-in amplifier.
Microphone power - The Enable microphone power option provides DC power for an external microphone. Microphone power
should only be used with microphones that have no battery. This setting should not be enabled when using a dynamic or battery
powered microphone. Microp hone power will
not harm the microphone; if you are uncertain, try switching it off and on. To use a
professional microphone requiring 48V phantom po wer, you need an external power supply and a balanced-unbalanced converter
(audio transformer) in between.
Input gain - Control the volume (dB Full Scale) of the audio inp ut. If the sound is too low, choose a higher dB, to amplify the
sound. If the sound is too high, choose a lower dB. The Level bar gives a visual representation of the audio signa l le v el in dB
relative to the full-scale i nput level.
•Green—thesignalisat
a good level.
• Yellow — the signa
l is becoming distorted.
•Red—thesi
gnal is distorted.
Encoding - Select digital audio encoding format.
• AAC requires a license for both encoding and decoding. AAC is the least complicated and most widely used codec.
If a
chieving the best possible audio quality is a priority, AAC is the recommended codec to use. An AAC license
is included in the Axis product.
• G711
