AXIS M1065-L Network Camera User Manual
AXIS M1065-L Network Camera Table of Contents System overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . How to access the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . How to access the product from a browser . . . . . . . . . . . . . . . . . . . . . . . . . . . About secure passwords . . . . . . . . . . . . . . . . . . . . . .
AXIS M1065-L Network Camera System overview System overview 3
AXIS M1065-L Network Camera Product overview Product overview 1 2 3 4 5 6 7 8 9 10 11 Focus lock ring Focus ring IR LED PIR sensor Speaker Status LED Control button Not used Network connector PoE SD card slot Power connector 4
AXIS M1065-L Network Camera How to access the product How to access the product AXIS IP Utility and AXIS Camera Management are recommended methods for finding Axis products on the network and assigning them IP addresses in Windows®. Both applications are free and can be downloaded from axis.
AXIS M1065-L Network Camera How to access the product The default root account has full privileges and should be reserved for administrative tasks. Always create a user account with limited privileges for daily use. This reduces the exposure of the administrative account. 1. Make sure to follow the instructions about secure passwords, see About secure passwords on page 5 . 2. Type a password and then retype it to confirm the spelling. 3. Click Create login. The password has now been configured.
AXIS M1065-L Network Camera Setup Setup About the product's built-in help You can access the built-in help through your product’s web page. The help provides more detailed information on the product’s features and their settings. Image quality How to change the camera focus 1 2 Focus lock ring Focus ring 1. Turn the focus lock ring counter clockwise to unlock the focus ring. 2. Turn the focus ring to adjust the focus. 3. Turn the focus lock ring clockwise to lock the position of the focus ring.
AXIS M1065-L Network Camera Setup Image without WDR. Image with WDR. Note If you use WDR, you may experience some WDR artifacts in the image. Find out more about WDR and how to use it at axis.com/web-articles/wdr About events The event pages allow you to configure your product to perform actions when different events occur. For example, the product can start a recording or send an email notification when motion is detected.
AXIS M1065-L Network Camera Setup How to record video when the camera detects motion This example explains how to set up the camera to start recording to the SD card five seconds before it detects motion and to stop one minute after. Make sure the AXIS Video Motion Detection application is running: 1. Go to Settings > Apps > AXIS Video Motion Detection. 2. Start the application if it is not already running. 3. Make sure you have set up the application according to your needs. Create an action rule: 4.
AXIS M1065-L Network Camera Setup About applications AXIS Camera Application Platform (ACAP) is an open platform that enables third parties to develop analytics and other applications for Axis products. To find out more about available applications, downloads, trials and licenses, go to axis.com/applications To find the user manuals for Axis applications, go to axis.com Note • Several applications can run at the same time but some applications might not be compatible with each other.
AXIS M1065-L Network Camera Troubleshooting Troubleshooting How to reset to factory default settings Important Reset to factory default should be used with caution. A reset to factory default resets all settings, including the IP address, to the factory default values. To reset the product to the factory default settings: 1. Disconnect power from the product. 2. Press and hold the control button while reconnecting power. See Product overview. 3.
AXIS M1065-L Network Camera Troubleshooting AXIS Camera Management can be used for multiple upgrades. Find out more at axis.com/products/axis-camera-management Technical issues, clues and solutions If you can’t find what you’re looking for here, try the troubleshooting section at axis.com/support Problems upgrading the firmware Firmware upgrade failure If the firmware upgrade fails, the product reloads the previous firmware. The most common reason is that the wrong firmware file has been uploaded.
AXIS M1065-L Network Camera Troubleshooting No multicast H.264 displayed in the client Check with your network administrator that the multicast addresses used by the Axis product are valid for your network. Check with your network administrator to see if there is a firewall preventing viewing. Poor rendering of H.264 images Ensure that your graphics card is using the latest driver. The latest drivers can usually be downloaded from the manufacturer’s website. Color saturation is different in H.
AXIS M1065-L Network Camera Troubleshooting • Heavy usage of event settings affects the product’s CPU load which in turn affects the frame rate. • Using HTTPS may reduce frame rate, in particular if streaming Motion JPEG. • Heavy network utilization due to poor infrastructure affects the bandwidth. • Viewing on poorly performing client computers lowers perceived performance and affects frame rate.
AXIS M1065-L Network Camera Specifications Specifications To find the latest version of the product’s datasheet, go to axis.com > [product] > Support & Documentation. LED indicators Note • The Status LED can be configured to flash while an event is active. Status LED Indication Unlit Connection and normal operation. Green Shows steady green for 10 seconds for normal operation after startup completed. Amber Steady during startup. Flashes during firmware upgrade or reset to factory default.
User Manual AXIS M1065-L Network Camera © Axis Communications AB, 2016 - 2017 Ver. M3.9 Date: June 2017 Part No.
