Instruction manual
Table Of Contents
- Important Safety Instructions
- Precautions
- DECLARATION OF CONFORMITY
- We declare under our sole responsibility that this product, to which this declaration relates, is in conformity with the following standards:
- EN60065, EN55013, EN55020, EN61000-3-2 and EN61000-3-3.
- Following the provisions of Low Voltage Directive 2006/95/EC and EMC Directive 2004/108/EC, the EC regulation 1275/2008 and its frame work Directive 2009/125/EC for Energy-related Products (ErP).
- A NOTE ABOUT RECYCLING:
- This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with the local recycling regulations.
- When discarding the unit, comply with local rules or regulations. Batteries should never be thrown away or incinerated but disposed of in accordance with the local regulations concerning battery disposal.
- This product and the supplied accessories constitute the applicable product according to the WEEE directive.
- Precautions
- For U.S. models
- For Canadian Models
- 1 Front Panel
- 1 AC Inlet
- 2 Speaker Terminals
- Amplifier Section
- General
22
Specifications
Amplifier Section
Rated Output Power (FTC)
All Channels: 50 Watts /channel, 8 loads
THD (Total Harmonic Distortion) 0.1% (40Watt, 8 load)
Speaker Impedance (Z1 – Z4 L/R) 4 - 8
Input Sensitivity and Impedance
(S1 – S3 L/R) 0.72 V / 22K (Unbalanced)
Coax digital input level and Impedance 0.5V ± 0.05V / 75
Frequency Response 20Hz – 20 KHz / – 3dB (8)
Tone Control ±12dB, 100 Hz (Bass)
±12dB, 10 KHz (Treble)
Signal to Noise Ratio 100dB (IHA-A, 1V input / unbalanced)
Interface
IR Output Eight 3.5mm Jack: IR1 – IR6 and SUM IR1-IR6:
Current limited to 25mA
Expansion Bus One Dual RJ45 Socket: Axium Bus, Summed IR
Ethernet One Shielded RJ45 socket – 100Base T
RS232 One Isolated DB9 – 9600 Baud
USB One USB mini-B 5 pin
Controller Four RJ45 socket: PORT1 – PORT4
One 4 way terminal plug (0V, IR, 12V & Data)
Amp On & PG Control One 8 way terminal plug with Amp ON 1 – 4 and
Two Page preset contact closure inputs: PG1 & PG2.
General
Power Supply 110 – 240VAC 50/60 HZ
Power Consumption 320 W
Standby Power Consumption 4W
Dimensions 435 90 390 mm
Height including feet 105mm
Weight 7Kg
Specifications and features are subject to change without notice.
