User`s guide

Example: Operating 3 systems at the same time

NOTE: To change the group/channel combination frequency of a receiver

and transmitter that are already ON, BOTH THE TRANSMITTER AND RE-

CEIVER MUST BE TURNED OFF.

System #1 System #2 System #3

Group Channel Group Channel Group Channel

Receiver 2 4 2 5 2 6

Transmitter 2 4 2 5 2 6

UHF FREQUENCY CHART

CHANNEL

GRP012345678

0 794.500 795.750 797.750 798.000 799.500 800.500 802.375 804.750 805.875

1 794.375 795.625 797.625 797.875 799.375 800.375 802.250 804.625 805.750

2 793.750 795.000 797.000 797.250 798.750 799.750 801.625 804.000 805.125

3 794.250 795.500 797.500 797.750 799.250 800.250 802.125 804.500 805.625

4 794.125 795.375 797.375 797.625 799.250 800.125 802.000 804.375 805.500

5 794.000 795.250 797.250 797.500 799.000 800.000 801.975 804.250 805.375

6 793.875 795.125 797.125 797.375 798.875 799.875 801.750 804.125 805.250

5. OUTPUT (#8) - switch to the appropriate position depending on whether the 500UDR

is plugged into the ‘LINE’ or ‘MIC’ input on the camera.

6. PHONE JACK (#11) - nominal 30 Ω headphone/earphone jack. Use either 3.5mm

mono or stereo (mono to both ears) connector. Earphones with an impedance

between 30 Ω and 300 Ω should provide adequate volume while headphones

with an 8 Ω impedance will most likely provide volume that is too low.

500UDR TROUBLESHOOTING

The single most important thing to ALWAYS check when trouble arrises are the batteries.

Make sure they are fresh and the POWER LED is glowing brightly.

SYMPTOM CAUSE

No POWER LED a. Receiver switch is set to “OFF”

b. External 12VDC power source is not connected or is mal-

functioning

c. Dead or very weak batteries

No ANT LED a. Transmitter battery dead

b. Transmitter not turned “ON”

c. Transmitter and receiver not both adjusted to the same

GROUP and CHANNEL

d. Receiver’s antenna’s are not installed

ANT LED is lit but NO audio a. Check that microphone is attached to transmitter, turned ON

and operating properly

b. OUTPUT switch is in the wrong position

c. OUTPUT connector cable is not installed or is defective

AF PEAK LED is always lit a. 500UDR is receiving a signal that is too strong. Move the

transmitter further away or reduce the transmitter’s output
