Safety Precautions Page 2 Purpose and function Page 3 Design and construction Page 3 Features Page 3 Rear panel view Page 4 Rear panel description Page 4 - 5 Control muting Page 5 - 6 Level controls Page 6 Outputs Page 7 Inputs Page 8 System installation Page 9 Making the connection Page 9 - 10 Troubleshooting Page 11 Care and cleaning Page 11 Specifications Page 12 Warranty page 13 Manual and Power cord Page 1
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. The lightning flash with arrowhead, within an equilateral triangle, is intended to alert the user of the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be sufficient magnitude to constitute a risk of electric shock to you.
The ST1400M series II is a compact, very efficient, single channel power amplifier. It is designed to be used in all types of audio or audio/video systems. The ST1400M series II utilizes high quality electronic circuitry to achieve an environment wherein a detailed, transparent, and highly musical sound can be realized.
1. AC fuse holder 2. AC Input receptacle 3. Speaker outputs 4. Balanced Input 1. AC fuse holder - 5. RCA input (unbalanced) 6. Level controls** 7. Amplifier control muting input/output Holds the AC Line fuse. This fuse is an 8 Amp / 250 Volt Slow Blow fuse. Replace with same type and value fuse only. 2. AC Input receptacle - For attaching the supplied AC power cord to the amplifier. 3. Speaker outputs - For connecting the speakers to the amplifier. Explained further on page 7. 4.
6. Level controls - Option available for the ST1400M series II amplifier. For adjusting the input level to the amplifier. Explained further on page 6. 7. Amplifier control muting input/output To provide remote switching of mute on/off of the amplifier. Explained further below. A control is provided on each ST1400M series II amplifier to allow remote switching of mute on/off.
If the control function is desired, each unit in the system must remain connected at all times and the control must be enabled. To enable the control function, the CTRL ENABLE button must be out for each controllable amplifier in the system. For more information on the amplifiers output status under various control conditions, refer to the table below.
Five way binding posts are provided. One pair for each channel. They are designed to accept a banana-type plug or spade lug connector (shown below) and are color coded for easy identification. The red (+) post should always be connected to the speakers (+) jack. The black (-) post should always be connected to the speakers (-) jack. Spade connector Banana jack Here is a typical amplifier setup: The ST1400M series II amplifier has two sets of binding posts on it. They are paralleled inside the amplifier.
Unbalanced - RCA type connectors accept line input from the preamplifier’s unbalanced output connectors. There are two input connectors, that may be used to connect the amplifier to the preamplifier. RCA cable connector - Operation - For unbalanced operation, ensure the balanced switch between the balanced inputs on the rear of the amplifier is in the ‘off’ (out) position. If the amplifier does not have balanced inputs then it is always in unbalanced mode.
There will most likely be a number of cables involved in the installation of your home entertainment system. Pre-planning is essential in order to maximize system efficiency. We recommend the following as a means of helping you reach that goal: Make a diagram of your proposed system by laying out the relative location of each component in the system. Then lay out the proposed cable runs between them. Number each cable and record its length on the diagram for future reference.
Connect the wires from your speakers to the appropriate output on the amplifier. It is absolutely essential that you observe correct polarity in these connections. Double check all connections. Plug the amplifier’s power cord into the AC power source. Turn the amplifier’s power switch ‘on’. The panel light should be illuminated. Leave the preamplifier turned off. Before proceeding to the next step turn the amplifier off and wait 30 seconds for the amplifier to discharge.
PROBLEM No sound (‘on’ LED not illuminated) POSSIBLE CAUSE 1. 2. 3. 4. No sound on some or all selected channels (‘on’ LED illuminated) 1. 2. 3. 4. POSSIBLE SOLUTION Power cord not plugged in. Power off at AC source. AC power inlet fuse blown or faulty. Control switch in the wrong position. 1. 2. 3. Speaker leads loose or faulty. Line stage to amp. cables loose. or faulty. Source to line stage cables loose or faulty. Line stage or source not correctly selected. 1. 4. 2. 3. 4.
Power rating: 8 ohms 4 ohms 150 watts @ 1 kHz 225 watts @ 1 kHz Frequency response 5 Hz - 45 kHz Input sensitivity 1.4 Volts THD (S+N) 0.09 % @ 1 kHz Input impedance 33.2 k ohms Damping factor 180 Current (peak to peak) 60 Amps Slew rate 14 V / )sec Dynamic headroom 1.5 dB S/N (A-weighted) 95 dB Voltage gain 28 Line voltage 120/220/240 VAC switchable Dimensions (O.A.) 17"(w) X 15.5"(d) X 5.75"(h) Weight 42 lbs Power consumption 260 watts max 2.
B&K Components Ltd., referred to herein as B&K, warrants your B&K equipment against all defects in material and workmanship for a period of five years from the date of purchase. This warranty applies only to the original purchaser and only to equipment in normal residential use and service.
B&K Components, Ltd. 2100 Old Union Road Buffalo, New York 14227 716-656-0023 www.bkcomp.
