IT1000-AB
1/4” Tie-Lok
®
Tool
Replace GripperFront Gripper
Replace AssemblyTension Block Assembly
Clean & Re-LubricateFront Gripper
Rotate Cut-off Blade
Clean & Re-LubricateTool Head
Clean & Re-LubricateFlip Cover
Clean & Re-LubricateTension Block AssemblyEvery 12,500
Maintenance
Action
Maintenance
Item
Clamps
Installed
ReplaceBlade, Blade pin, Knife
and Knife pin
Every 50,000
RotateCut-off Knife
Clean & Re-LubricateMechanical LinkageEvery 25,000
Preventative Maintenance Schedule
Tool Preventative Maintenance:
The tool has some wear components that must be checked and replaced on a certain
schedule. BAND-IT has developed a Preventative Maintenance (PM) schedule to help
facilitate these requirements. If tools are experiencing difficulties during function or there
audible air leaks coming from inside the handle, the tool should be returned to BAND-IT-
IDEX, Inc. for servicing.
BAND-IT recommends that the tool be sent in for general overhaul every 100,000 clamps
installed.
