Spec Sheet

WASHINGTON 650 Cat. No.
PEDESTAL 3-41X
LAVATORY
Interior Dimensions:
Basin Interior: 16” x 12”
BasinDepth: 7 1/2”
Back of basin to center of faucet: 2 1/2”
Back of basin to center of drain: 7 3/4”
Mount bolts height: 32”
Mount holes cc: 7 7/8”
Faucet and spout holes: 1 1/8”(4”)
1 3/8”(8”)
W: 25 5/8”
D: 19 7/8”
H: 32 3/4”
Flange: 1 5/8”
Column: 26-7/8”L x 10-1/2”W x 7-1/2”D
P 847•244•1234 www.barclayproducts.com
Meets or exceeds the following
specifications: ASME A112.19.2
2008 and CSA B45.1-08 for ceramic
plumbing fixtures.
9/6/13
Dimensions of fixture are nominal and may vary within the range of tolerances established by ASMEI Standard A112.19.2-2008. Dimensions and
specifications subject to change without notice.
Features:
►Made of Vitreous China
►Available for 4” CC or 8” Widespread
►Can Be Installed Using Toggle or Molly
Bolts (not included)
*For ease of installation order one of the following
1. Hangers (pair) $ 4.75
2. Bracket (one) $11.50
Colors:
WH White
Faucet not included
