Dimensions Guide

71” CAST IRON Cat. No.
DOUBLE CTDSN
SLIPPER TUB
Features:
►Inside finish is white enamel
►Cast Iron lion feet available in 6 finishes or
unfinished
►Tub exterior is white
►No faucet holes
►Non-skid strips
►Feet are attached and leveled before shipment
►Tub is thoroughly inspected before shipment
Gallon Capacity : 43 1/2
Shipping Weight: 544 lbs.
Empty Weight: 364 lbs.
Filled Weight: 728 lbs
L: 71”
W: 30 1/2”
H: 30” (from floor to top of tub)
22” (from floor to lowest tub rim)
18 1/2” (from bottom of tub to top
center of tub)
26 3/4” (from bottom of tub to top
of tub
Water depth: 14 1/4” to OF
Toe to Toe Measurements:
35” Front to back
20-1/2” Side to side
P 847•244•1234 www.barclayproducts.com
Meets or exceeds the following
specifications: A112-19-1M 1994.
10/16/2014
Dimensions of fixture are nominal and may vary within the range of tolerances established by ANSI Standard A112.19.2. Dimensions and
specifications subject to change without notice.
Foot Finishes:
BP Polished Brass
SN Brushed Nickel
CP Polished Chrome
WH White
PN Polished Nickel
ORB Oil-rubbed Bronze
The following is recommended for
CTDSN tubs without faucet holes:
•Faucets: part #4602
•Rigid, freestanding supplies: part #4502
•Leg tub drain: part #5599
Custom Colors Available (inside of tub is always white enamel):
Painted bathtubs are considered “special order” and are not returnable
$160 Bisque or Black $250 Designer Color
