Technical Specifications

ELECTRA
RESIN DOUBLE Cat. No.
SLIPPER TUB RTDSN64-OF
Features:
►Poly-resin blend is the same color throughout
►1” thick at rim
►Exterior has easy care matte finish
►No faucet holes
►Has overflow slot with built-in drain channel
►White drain included
►Tub is thoroughly inspected before shipment
Tub Colors:
WH White
Gallon Capacity : 75 to overflow
Shipping Weight: 534 lbs.
Empty Weight: 309 lbs.
Filled Weight: 935 lbs.
L: 64”
W: 32 1/4”
H: 25 1/4”
Water depth: 14-7/8” to overflow
P 847•244•1234 www.barclayproducts.com
10/18/2013
Dimensions of fixture are nominal and specifications subject to change without notice.
The following is recommended for
RTDSN soaking tubs:
•Faucets: part #4602, #4022, or #4025
•Use with Freestanding Bath Supplies:
part #4502-PL
•Freestanding tub fillers: part #7901 or #7913
Overflow Connection
