GRAPHICS 1209s R9000972 R9000977 INSTALLATION MANUAL
BARCO PROJECTION SYSTEMS GRAPHICS 1209s R9000972 R9000977 INSTALLATION MANUAL Date : 040598 Rev. : 01 Art. No.
Due to constant research, the information in this manual is subject to change without notice. Produced by BARCO NV, May 1998. All rights reserved. Trademarks are the rights of their respective owners. BARCO nv/Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.
Table of contents TABLE OF CONTENTS ................................................................................................................................ I-1 SAFETY INSTRUCTIONS On safety ............................................................................................................................................. On installation ...................................................................................................................................... On servicing .......
Table of contents Connecting a Component Video source to Port 4/5 ............................................................................. 7-3 Connecting a RGB Analog source with Tri-level sync to Port 4/5 (option) ............................................ 7-4 Connecting a Component Video source with Tri-level sync to Port 4/5 (option) ................................... 7-4 Peripheral equipment .........................................................................................................
Safety Instructions 1 SAFETY INSTRUCTIONS Notice on Safety This equipment is built in accordance with the requirements of the international safety standards EN60950, UL 1950 and CSA C22.2 No.950, which are the safety standards of information technology equipment including electrical business equipment.
Safety Instructions WARNING FOR THE CUSTOMERS: THIS APPARATUS MUST BE GROUNDED (EARTHED) via the supplied 3 conductor AC power cable. (If the supplied power cable is not the correct one, consult your dealer.) A. Mains lead (Power cord) with CEE 7 plug: The wires of the mains lead are colored in accordance with the following code. Green and yellow: earth earth) Blue: neutral Brown: line (live) (safety B. Power cord with ANSI 73.
Unpacking and dimensions 2 UNPACKING AND PROJECTOR DIMENSIONS Unpacking To open the banding around the carton, pull out the clip as shown below : Take the projector out of its shipping carton and place it on a table. Save the original shipping carton and packing material, which will come in handy if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory.
Unpacking and dimensions Projector dimensions (in mm) W1 H5 L5 L6 L4 L3 L2 L1 H4 H3 H2 W2 H1 2-2 Dimensions mm inch L1 L2 L3 L4 L5 L6 W1 W2 H1 H2 H3 H4 H5 1174 1014 1000 735 110 265 782 665 355 315 219 101 121 46.2 39.9 39.37 28.9 4.33 10.43 30.8 26.2 13.9 12.4 8.62 3.98 4.
Installation guidelines 3 INSTALLATION GUIDELINES Installation guidelines Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to optimize the use of the projection system. Environment Do not install the projection system in a site near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, excessive dust or humidity.
Installation guidelines Where to install the projector ? To indicate a correct installation position it is necessary to know : ρ The distance from projector to ceiling in case of Ceiling mounted or the distance from projector to floor in case of Table mounted; r The distance from projector to screen. FHLOLQJ 3' % &' $ SURMHFWRU VFUHHQ To find the correct position for the projector, equipped with HD120 lenses, use the following formulas: Optinal lenses : HD180 for SW between 3m and 4.
Installation set-up 4 INSTALLATION SET-UP WARNING : Risk of electric shock ! Installation only by BARCO authorized service personeel Access to Controls Opening the top cover During the projector set-up and installation it is necessary to open the top cover. Follow the procedure as described below : Lock screws ⊇ Turn the locking screw with a screwdriver or coin counter clockwise; ⊄ Lift up and pivot the top cover. WARNING : The projector's top cover is not supported with locking hinge.
Installation set-up Scan Adaptation The scan switches must be placed in the correct position which corresponds to the desired scanning configuration. To change the scanning, it is necessary to remove the projector top cover and to open the protection plate. For opening the projector's top cover, see 'Access to controls'. WARNING ! TURN OFF PROJECTOR AND UNPLUG THE POWER CORD BEFORE CHANGING THE SCAN DIRECTION.
Installation set-up Horizontal Scan Switches Three switches are used, one for each CRT. When changing the horizontal scan, insure that all three switches are set in the same position. See positions of the switches (diagram on next page) for the corresponding projector configuration. To set the scan switches : − Toggle the 3 horizontal scan inversion switches to the correct positions.
Installation set-up ⊆ Highlight 'IDENTIFICATION' by pushing the control disk up or down and press the ENTER. SERVICE MODE IDENTIFICATION COPY A BLOCK DELETEABLOCK DELETEALLBLOCKS CHANGEPASSWORD CHANGE LANGUAGE RUN TIME DYNAMICASTIGMATISM MORE... Select with or then to return The projector will display the 'IDENTIFICATION SCREEN'. This screen gives the current information about the projector configuration in the line entitled 'Config'. GRAPHICS 1209s Proj. address : 001 Soft. Version : 6.
Projector set-up 5 PROJECTOR SET-UP The DIP switches on the controller board allow the SET-UP of the projector : − 8 DIP switches for the projector address setting. − 1 DIP switch for the power up mode setting. − 3 DIP switches for the baud rate for communication setting. − 1 DIP switch for the password mode setting. To gain access to the DIP switches : - Loosen the 3 screws on both sides (indicated on drawing below) of the frame. - Loosen the 3 screws on the rear side of the metal frame.
Projector set-up Setting the projector address The projector's address may be set to any value between 0 and 255. When the address is set, the projector can be controlled now by : ρ the RCU for addresses between 0 and 9. ρ a IBM PC (or compatible) or Apple MAC for addresses between 0 and 255. 0 Addressable with RCU Addressable with PC, MAC or workstation 9 255 Setting the address is a hardware SET-UP of your projector which must be done during installation.
Projector set-up Power-up mode The projector can start up in two different modes. The start up mode is determined by the position of DIP Switch No. 4 of another set of 8 DIP switches on the controller board (one set of 8 switches are used for projector address setting). Position of the DIP Switch No. 4 (power up mode) : 1 2 3 4 5 6 7 8 Power-up mode ON : operational mode. OFF : stand-by mode (Factory preset).
Projector set-up Password mode With DIP Switch No.5 of the second set of 8 DIP switches on the controller board, the projector adjustments can be protected with a password. When the password feature is enabled, the user has to enter a password before he can enter the adjustment mode (For more information about password setting and reprogramming the password, see Installation adjustment).
AC power connection 6 AC POWER CONNECTION AC Power (mains) cord connection Use the supplied cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the back of the projector. V NOM 120/230 Volt I MAX 7/5Amp FREQ 50/60Hz 1 , 6 5 56 ,1 7 82 65 56 287 5, ,5 (7 2 0(5 5(027( This projector may be connected to an IT-power system. The ITpower system is a power distribution system having no direct connection to earth.
AC power connection AC Power check Check the power voltage which is determined by the Art. No. on the indentification label pasted on the backside of the projector. Projectors with the Art. No. R9000972 must be connected to a 230 VAC power source. Projectors with the Art. No. R9000977 must be connected to a 120 VAC power source. When the power voltage is different from that of the wall outlet, proceed to AC Input power voltage adaptation of the projector.
AC power connection Fuses Warning ! For continued protection against fire hazard : AC power Fuses Order Number − Replace with the same type of fuse. 230 Vac T6.3A/250V (2x) R314145 − Refer replacement to qualified service personnel. 120 Vac T10A/250V (2x) R314154 Switching on the projector The projector is switched ON and OFF using the power (mains) switch ON/OFF.
AC power connection If a key, other than EXIT, is pressed, a text box with the following text will be displayed : "Please use to leave this procedure." Start up without "Warm up period" If EXIT is pressed, the warm up period will be skipped and the projector is immediately ready for use. Warning : Skipping this warm up procedure can reduce the initial picture quality of the projected image.
Source connections 7 SOURCE CONNECTIONS Signal input connection The following signals can be connected to the projector through the inputs on the back panel of the projector : * Composite Video * S-Video * RGB * Component Video * RGB with Tri-level sync * Component video with Tri-level sync Port No 1 2 3257 3257 5*% +9 352-(&725 02'( 32: (5 0$ ,1 6 9,'(2 *5((1 RSHUDWLRQDO &RPS + V\QF 3257 5(027( &20081,&$7,21 9 V\QF 5(' VWDQG E\ 3257 3257 6 9,'(2 2)) 5 Projec
Source connections Connecting a S-Video (or Composite Video) source to Port 2 Separate Y-luma/C-chroma signals for higher quality playback of Super VHS signals can be connected to Port 2 . A composite video signal can also be connected to this port.
Source connections Procedure to remove the line termination resistors : 1 Turn off the projector and unplug the projector power cord. 2 Remove the top cover from the projector. 3 Remove the RGB Input Auto Sync Tracking Module from the main frame. 4 Unsolder and remove the resistors.
Source connections 3257 3257 5*% +9 Connecting a RGB Analog source with Trilevel sync to Port 4/5 (option) 352-(&725 02'( 32:(5 0$,16 9,'(2 *5((1 RSHUDWLRQDO &RPS + V\QF 3257 5(027( &20081,&$7,21 9 V\QF 5(' VWDQG E\ 3257 3257 6 9,'(2 2)) 5 * % 2)) 21 21 RKP RKP RGB analog input terminals with Tri-level sync input or with Tri-level sync on green can be connected to the projector via Port 4/5. The projector detects automatically where the sync signal is located.
Installation adjustment mode 8 INSTALLATION ADJUSTMENT MODE Access to Installation Adjustment Mode It will be necessary to perform several mechanical adjustments while in the Installation Adjustment Mode. It will be required to open and remove the projector's top cover in order to gain access to the adjustment points. ADJUSTMENT MODE Select a path from below: GUIDED RANDOM ACCESS INSTALLATION SERVICE IRIS To enter into the installation adjustment mode : 1 Press ADJUST to start up the adjustment mode.
Installation adjustment mode Important : Access to adjustments The top cover of the projector should be removed in order to gain access to the adjustments. Projector Distance On the screen, a drawing will be displayed together with parameters indicating a correct installation position. FHLOLQJ 3' To change the screen width : $ 1 Push the control disk to the left or to the right to highlight the item SW in the "Projector Distance 1" menu and then press TEXT.
Installation adjustment mode Raster Centering The raster must be centered on the CRT faceplate of each tube, therefore, it is necessary to look into the lenses. RASTER CENTERING Caution : To avoid eye discomfort while performing these adjustments, reduce the contrast and gradually increase the brightness level until the raster becomes visible behind the image. Warning : In order to ensure maximum CRT longevity and to avoid CRT damage, do not shift the raster outside the phosphor area of the CRT.
Installation adjustment mode CRT Projection Angle Adjustment The projection angle of the red and blue CRT's is dependent on the desired size of the projected image. If the centers of green, blue and red do not coincide, the CRT projection angle must be adjusted. NOTE : Never try to correct this misalignment with the shift correction or the static convergence controls. These controls may only be applied to correct small errors which cannot be corrected by the CRT angle adjustment.
Installation adjustment mode Loosen bolts D, E and F to pivot the blue CRT until the center of the Blue image and the center of the Green image coincide. When the angle of the blue CRT is corrected, tighten the four bolts. Press ENTER to continue with the diagonal focusing menu. Press EXIT to return to the CRT projection angle adjustment.
Installation adjustment mode Scheimpflug Adjustment (Diagonal image focusing) With the diagonal image focusing corrections, it is possible to obtain uniform focus for the total projected image. DIAGONAL IMAGE FOCUSING These corrections must be repeated for each colour. The Diagonal image focusing is repeated 3 times, first for green, then for red and then for blue. 1. TURN THE SCREW MARKED ;; TO FOCUS THE IMAGE DIAGONALLY from LEFT (bottom) TO RIGHT (top). 2.
Installation adjustment mode + + + + Repeat the same procedure for the red and blue image using the corresponding screws. To optimize the image focusing, repeat the optical lens focusing. When the scheimpflug corrections are correctly adjusted, secure this position by fastening the security screws on both sides of each lens. LENS CORNER FOCUSING Warning : When the security screws are tightened, it is not possible to change the scheimpflug correction.
Installation adjustment mode 8-8 5975638 BARCOGRAPHICS 1209s 040598
Appendix A: BARCO ceiling mount support A BARCO CEILING MOUNT SUPPORT This appendix gives only an overview of the contents of the installation guidelines and some overview drawings. The installation guidelines for the BARCO ceiling mounting support can be ordered from BARCO. The order number: R5975693. Contents of the installation guidelines Overview drawing of the total system &(17(5 XSSHU VXSSRUW 1. Mounting instructions for the upper support to the ceiling a.
Appendix A: BARCO ceiling mount support Projector-position corrections * Water-level adjustment D * Projector axis adjustment C A-2 5975638 BARCOGRAPHICS 1209s 040598
Appendix B: G2 adjustment B G2 ADJUSTMENT Once the on-screen menu "G2 ADJUSTMENT" is displayed, proceed as follows : * $'-8670(17 Use the potentiometers on the G2-ADJ. module to set the screen grid voltage for Red, Green and Blue. Adjust until the LED on the corresponding output amplifier is turned off. to return 1 * Remove the top cover from the projector. * A green LED is mounted on each of these amplifiers. When selecting the G2 adjustment menu, these green LEDs must be out.
Appendix B: G2 adjustment B-2 597638 BARCOGRAPHICS 1209s 040598
Gamma corrections C GAMMA CORRECTIONS When entering the gamma corrections, a warning will be displayed : "RISK OF INCORRECT ADJUSTMENT OF THE PROJECTOR. THE GAMMA CORRECTIONS ARE FACTORY ADJUSTED USING AN ACTAS COLOR ANALYSER ! THEREFORE, ONLY QUALIFIED INSTALLATION OR SERVICE PERSONNEL SHOULD PERFORM THESE ADJUSTMENTS ! " If you are qualified, press the key to continue.
Gamma Corrections To carry out the Red and Blue Midlights Correction : 1 Push the control disk up or down to highlight the item R & B MIDLIGHTS in the menu and then press ENTER. If EXIT is pressed, the projector will return to the Service menu. 2 After ENTER is pressed, a text box with message "Adjust with arrow key" will be displayed on the screen.
Form Approved Bureau Budget No. 45-R0338 MATERIAL SAFETY DATA SHEET MANUFACTURER'S NAME AND FSCM (Federal Supply Code for Manufacturer's) BARCO N.V. EMERGENCY PHONE NO.
SECTION V HEALT HAZARD DATA TRESHOLD LIMIT VALUE EFFECTS OF OVEREXPOSURE EMERGENCY AND FIRST AID PROCEDURES STABILITY SECTION VI REACTIVITY DATA 100ppm CONDITIONS TO AVOID UNSTABLE STABLE X INCOMPATABILITY (Materials to avoid) HAZARDOUS DECOMPOSITION PRODUCTS HAZARDOUS POLYMERIZATION MAY OCCUR X CONDITIONS TO AVOID WILL NOT OCCUR SECTION IX SPECIAL PRECAUTIONS SECTION VIII - SPECIAL PROTECTION INFORMATION SECTION VII SPILL OR LEAK PROCEDURES STEPS TO BE TAKEN IN CASE MATERIAL IS RELEASED
