User guide
Table Of Contents
- Welcome!
- Table of contents
- What's in the box
- Parts, controls and connectors
- Display installation
- Daily operation
- Advanced operation
- OSD menu position
- OSD menu language
- OSD menu automatic close function
- Power status indicator light
- Key indicator lights
- Power lock function
- Keys sound
- Ethernet over USB
- DDC HID Device
- DPMS mode
- Hibernate
- Luminance target
- Color presets
- Color temperature
- Color coordinates
- Viewing modes
- Display functions
- Ambient Light Compensation (ALC)
- Reading rooms
- Continuous ALC
- Image scaling
- Image source selection modes
- Video input signals
- Video encoding modes
- Grayscale conversion modes
- EDID timings
- Display info
- Display status
- Cleaning your display
- Repackaging instructions
- Important information
10 Coronis Fusion 6MP
Rear view
+24 VDC power input +5 VDC, 0.5 A power output
DVI 2 video input DisplayPort 2 video input
Connector compartment
cover
Neck cover
DisplayPort 1 video input Display stand cover
DVI 1 video input Ethernet connector (see note
below)
USB upstream connector USB downstream connector
The Ethernet connection is used for maintenance purposes and
is not supported for user application.
6 8
7
1 2 3 4 5
9 10 11 12
1
2
3
4
5
6
7
8
9
10
11
12
