EDID timings
ABOUT EDID TIMINGS
Following EDID timings are available for your CORONIS FUSION 6MP display:
Your CORONIS FUSION 6MP display will automatically adjust the
connected video input signals and apply the correct timings
based on the preferred EDID timings. To manually configure
these EDID timings your display’s image source selection mode
should be set to allow this. Please refer to “Image source
selection modes” on page 43 to do this.
Resolution Allows to manually modify the resolution
of the image source video input signal.
Refresh Rate Allows to manually select the refresh rate
of the image source video input signal
depending on the maximum refresh rate of
the display controller connected to your
display.
Preferred Orientation Allows to change the orientation of the
image source video input signal to
landscape, portrait or to let the display
automatically assign the correct
orientation.
Color Depth Allows to change the color depth to 8 or to
10 bit.
