50 Coronis Fusion 6MP
TO MANUALLY SET EDID TIMINGS:
1 Bring up the OSD main menu.
2 Navigate to the Configuration > Image Sources > (Left/Right)
Image Source menu.
3 Enter the EDID Timings submenu.
4 Select Resolution, Refresh Rate, Preferred Orientation or Color
Depth.
5 Select one of the available settings and confirm.
Display info
ABOUT DISPLAY INFO
Your display serial number, color type, native resolution, firmware
versions, etc. are available in a dedicated submenu of the OSD menu.
TO RETRIEVE INFO ABOUT YOUR DISPLAY:
1 Bring up the OSD main menu.
2 Navigate to the About this Display menu.
3 Enter the Display or Firmware submenu as desired.
Display status
ABOUT DISPLAY STATUS
The Status submenu of the OSD menu provides info on the current status
of your display (runtimes, temperatures, etc.), the status of the
connected image sources (video encoding mode, timings, etc.) and the
current calibration status of your display (display function, luminance,
ALC, etc.).
