68 Coronis Fusion 6MP
Response time (Tr + Tf) 18 ms
Scanning frequency (H; V) 30-150 kHz; 15-80 Hz
Housing color Black/Silver
Video input signals DVI-D Dual Link (2x), DisplayPort (2x)
Video inout terminals NA
USB ports 1 upstream (endpoint), 3 downstream
USB standard 2.0
Power requirements
(nominal)
100-240V
Power consumption
(nominal)
125W
Power save mode Yes
Power management DVI-DMPM, DP-DMPM
Dot clock 280 MHz
OSD languages English, German, French, Dutch, Spanish, Italian,
Portugese, Polish, Russian, Swedish, Chinese
(simplified), Japanese, Korean, Arabic
Dimensions with stand (W
x H x D)
Portrait: NA
Landscape: 731 x 580~676 x 265 mm
Dimensions w/o stand (W
x H x D)
Portrait: NA
Landscape: 731 x 485 x 141 mm
Dimensions packaged (W x
H x D)
869 x 764 x 400 mm
Net weight with stand 26.5 kg
Net weight w/o stand 20 kg
Net weight packaged with
stand
36.5 kg
Net weight packaged w/o
stand
NA
