Coronis Fusion 6MP 69
* In dark reading room conditions (0 lux)
Height adjustment range 96 mm
Tilt -5° / +25°
Swivel -45° / +45°
Pivot NA
Mounting standard VESA (100 mm)
Screen protection Protective, non-reflective glass cover
Recommended modalities CT, MR, US, DR, CR, NM, Film
Certifications CE0120 (MDD 93/42/EEC class IIb product), Directive
2004/108/EC, IEC 60950-1:2005 2ND EDITION,
DEMKO - EN 60601-1:2006, VCCI, FCC class B, FDA
510(K), RoHS, KCC, IEC 60601-1:2005 3RD EDITION,
ANSI/AAMI ES 60601-1:2005, CAN/CSA-C22.2 No.
60601-1 (2008), CCC - GB9254-2008 + GB4943.1-2011
+ GB17625.1-2003, ICES-001 Level B
Supplied accessories Getting Started Guide
Quick-Installation Sheet
Video cables (2x DVI Dual Link, 2x DisplayPort)
Main cables (UK, European (CEBEC/KEMA), USA (UL/
CSA; adaptor plug NEMA 5-15P), Chinese (CCC))
USB 2.0 cable
External power supply
Optional accessories NA
QA software MediCal QAWeb
Unit per pallet NA
Pallet dimensions NA
Warranty 5 years
Operating temperature 0°C to 35°C (15°C to 30°C within specs)
Storage temperature -20°C to 60°C
Operating humidity 8% - 80% (non-condensing)
Storage humidity 5% - 93% (non-condensing)
Operating altitude 2000 m
