GRAPHICS 1208s R9000893 R9000896 INSTALLATION MANUAL
BARCO PROJECTION SYSTEMS GRAPHICS 1208s R9000893 R9000896 INSTALLATION MANUAL Date : 220197 Art. No.
Due to constant research, the information in this manual is subject to change without notice. Produced by BARCO NV, January 1997. All rights reserved. Trademarks are the rights of their respective owners.
Contents CHAPTER 1 SAFETY INSTRUCTIONS On safety ............................................................................................................................................... 1-1 On installation ........................................................................................................................................ 1-2 On servicing ...........................................................................................................................................
CHAPTER 6 AC POWER CONNECTION AC Power cord connection ..................................................................................................................... 6-1 Preparing your power cord ..................................................................................................................... 6-1 Mains lead with CEE7 plug ....................................................................................................................................................
Safety Instructions 1 SAFETY INSTRUCTIONS Notice on Safety This equipment is built in accordance with the requirements of the international safety standards EN60950, UL 1950 and CSA C22.2 No.950, which are the safety standards of information technology equipment including electrical business equipment.
Safety Instructions A. Mains lead (Power cord) with CEE 7 plug: qualified service personnel under the following conditions: The wires of the mains lead are colored in accordance with the following code. a. When the power cord or plug is damaged or frayed. b. If liquid has been spilled into the equipment. Green and yellow: Blue: Brown: earth (safety earth) neutral line (live) B. Power cord with ANSI 73.11 plug: The wires of the power cord are colored in accordance with the following code.
Unpacking and dimensions 2 UNPACKING AND PROJECTOR DIMENSIONS Unpacking To open the banding around the carton, pull out the clip as shown below : Take the projector out of its shipping carton and place it on a table. Save the original shipping carton and packing material, which will come in handy if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory.
Unpacking and dimensions Projector dimensions (in mm) 1101 2-2 5975857 BARCOGRAPHICS 1208s 220197
Installation guidelines 3 INSTALLATION GUIDELINES Installation guidelines Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to optimize the use of the projection system. Environment Which screen type? Do not install the projection system in a site near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, excessive dust or humidity.
Installation guidelines Where to install the projector ? ceiling PD B CD To indicate a correct installation position it is necessary to know : ❒ r A the distance from projector to ceiling in case of ceiling mounted; or the distance from projector to floor in case of Table mounted; projector the distance from projector to screen. screen To find this correct position for the BARCOGRAPHICS 1208s, equipped with HD8 lenses, use the following formulas: In metric : Front view PD[m] = 1.
Installation set-up 4 INSTALLATION SET-UP Access to Controls Opening the top cover During the projector set-up and the installation it is necessary to open the top cover. Follow the procedure as described below : Lock screws * turn both lock screw with a screwdriver or a coin counter clockwise; * lift up and pivot the top cover. WARNING : The projector's top cover is not supported with locking hinge. Open with care and support the cover with your hand.
Installation set-up Scan Adaptation The scan switches must be placed in the correct position which corresponds to the desired scanning configuration. To change the scanning, it is necessary to remove the projector top cover and to open the protection plate. For opening the projector's top cover, see 'Access to controls'. WARNING ! TURN OFF PROJECTOR AND UNPLUG THE POWER CORD BEFORE CHANGING THE SCAN DIRECTION.
Installation set-up Horizontal Scan Switches Three switches are used, one for each CRT. When changing the horizontal scan, insure that all three switches are set in the same position. See positions of the switches for the corresponding projector configuration. Horizontal deflection switches Vertical deflection switch B G R Vertical Scan Switch One switch for the three CRT's is used. See position of the switch for the corresponding projector configuration.
Projector set-up 5 PROJECTOR SET-UP The DIP switches on the controller unit allow the SETUP of the projector : ❒ r r r 8 DIP switches for setting the projector address 1 DIP switch for setting the power up mode 3 DIP switches for setting the baud rate for communication 1 DIP switch for setting the password mode To gain access to the DIP switches : * open the top cover, * loosen the 3 retaining screws on both sides of the metal protection plate, * loosen the 3 screws on the rear side of the metal frame
Projector set-up Setting the projector address The projector's address may be set to any value between 0 and 255. When the address is set, the projector can be controlled now by : ❒ RCU for addresses between 0 and 9; ❒ IBM PC (or compatible) or Apple MAC for addresses between 0 and 255. 0 Addressable with RCU Addressable with PC, MAC or workstation 9 255 Setting the address is a hardware SET-UP of your projector which must be done during installation.
Projector set-up Power-up mode The projector can start up in two different modes. The start up mode is determined by the position of DIP Switch No. 4 of another set of 8 DIP switches on the controller unit (one set of 8 switches are used for projector address setting). Position of the DIP Switch No.
Projector set-up Password mode 0 With DIP Switch No.5 of the second set of 8 DIP switches on the controller unit, the projector adjustments can be protected with a password. When the password feature is enabled, the user has to enter a password before he can enter the adjustment mode (for more information about password setting and reprogramming the password, see Installation adjustment).
AC power connection 6 AC POWER CONNECTION AC Power (mains) cord connection Use the supplied cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the back of the projector. V NOM 120/230 Volt I MAX 7/5Amp FREQ 50/60Hz RS232 IN RS232 OUT RS232 OUT IR RS232 IN REMOTE This projector may be connected to an IT-power system.
AC power connection AC Power check Check the power voltage which is determined by the ART. NR. (Article number) included in the label pasted on the backside of the projector. Projectors with the ART. NR. R9000901 must be connected to a 230 VAC power source. Projectors with the ART. NR. R9000908 must be connected to a 120 VAC power source. If the indicated voltage is different from that of the wall outlet, call a qualified technician for power adaptation of the projector.
AC power connection Cover plate (side view) metal bottom plate inside projector cabinet Top view marked area Fuses Warning ! For continued protection against fire hazard : AC power Fuses Order Number ❒ Replace with the same type of fuse. 230 Vac T6.3A/250V (2x) R314145 ❒ Refer replacement to qualified service personnel.
AC power connection Starting up with a full white image When the projector is set to start up with a full white image, the "projector warm up" menu will be displayed for 30 seconds. Start up with "warm up period" If no action is taken, a white image will be displayed for 20 minutes. This white image will be shifted on the faceplate of the CRT to avoid a CRT burn-in. During this warm up period, it is possible to interrupt this white image projection by pressing the key.
Source connections 7 SOURCE CONNECTIONS Signal input connection The following signals can be connected to the projector through the inputs on the back panel of the projector : r r r r r r r PORT 1 (VIDEO) PORT 4/5 (RGB - HV) Composite Video PROJECTOR MODE PORT 6 REMOTE COMMUNICATION S-Video PORT 3 RGB Analog R G B POWER/MAINS GREEN : operational RED : stand-by Comp/H sync V sync OFF ON PORT 2 (S-VIDEO) OFF ON 75 ohm 75 ohm RGB with sync 357 3 Component Video 4 RGB with Tri-level
Source connections Connecting a S-Video (or Composite Video) source to Port 2 4 pin connector configurations: Separate Y-luma/C-chroma signals for higher quality playback of Super VHS signals can be connected to Port 2. The composite video can also be connected to this port. To select the S-video input : with the RCU or the local keypad : press the numeric button 2.
Source connections Procedure to remove the line termination resistors : ➊ Turn off the projector and unplug the projector power cord. ➋ Remove the top cover from the projector (see p.4-1). ➌ Take out the RGB Input Auto Sync Tracking Module from the main frame. ➍ Unsolder and remove the resistors. To take out the RGB Input Auto Sync Tracking Module, follow the same procedure as described in p.
Source connections Connecting a RGB Analog source with Trilevel sync to Port 4/5 (option) PORT 1 (VIDEO) PORT 4/5 (RGB - HV) Comp/H sync V sync PORT 6 REMOTE COMMUNICATION PORT 3 R RGB analog input terminals with Tri-level sync input or with Tri-level sync on green can be connected to the projector via Port 4/5. The projector detects automatically where the sync signal is located. This feature requires an optional Tri-Level Sync Module - Order Number R9828040.
Installation adjustment mode 8 INSTALLATION ADJUSTMENT MODE Access to Installation Adjustment Mode It will be necessary to perform several mechanical adjustments while in the Installation Adjustment Mode. Open and remove the projector's top cover in order to gain access to the adjustment points. ADJUSTMENT MODE Select a path from below: GUIDED RANDOM ACCESS INSTALLATION SERVICE IRIS To enter into the installation adjustment mode : ➊ Press ADJUST to start up the adjustment mode.
Installation adjustment mode Important : Access to adjustments The top cover of the projector should be removed in order to gain access to the adjustments. Please refer to p.4-1 for how to remove the top cover. Projector Distance On the screen, a drawing will be displayed together with parameters indicating a correct installation position.
Installation adjustment mode Raster Centering The raster must be centered on the CRT faceplate of each tube, therefore, it is necessary to look into the lenses. Caution : To avoid eye discomfort while performing these adjustments, reduce the contrast and gradually increase the brightness level until the raster becomes visible behind the image. Warning : In order to ensure maximum CRT longevity and to avoid CRT damage, do not shift the raster outside the phosphor area of the CRT.
Installation adjustment mode CRT Projection Angle Adjustment The projection angle of the red and blue CRT's is dependent on the desired size of the projected image. If the centers of green, blue and red do not coincide, the CRT projection angle must be adjusted. NOTE : never try to correct this misalignment with the shift correction or the static convergence controls. These controls may only be applied to correct small errors which cannot be corrected by the CRT angle adjustment.
Installation adjustment mode Loosen bolts E, F, G and H to pivot the blue CRT until the center of the Blue image and the center of the Green image coincide. When the angle of the blue CRT is corrected, tighten the four bolts. Press ENTER to continue with the diagonal focusing menu. Press EXIT to return to the CRT projection angle adjustment.
Installation adjustment mode Scheimpflug Adjustment (Diagonal image focusing) With the diagonal image focusing corrections, it is possible to obtain uniform focus for the total projected image. DIAGONAL IMAGE FOCUSING These corrections must be repeated for each colour. The Diagonal image focusing is repeated 3 times, first for green, then for red and then for blue. 01 1. TURN THE SCREW MARKED xx TO FOCUS THE IMAGE DIAGONALLY from LEFT (bottom) TO RIGHT (top). 00 2.
Messages, warnings and failure codes 9 MESSAGES, WARNINGS AND FAILURE CODES SOURCE 01 Fh= 15.6 kHz Fv= 050 Hz SOURCE 01 Fh= 15.6 kHz Fv= 050 Hz enter password xxxx When selecting a new source, information about this source will be displayed on the screen. Source number, horizontal and vertical frequencies of the displayed source. WARNING : source not available WARNING : Announcement of the selected source.
Messages, warnings and failure codes WARNING : Projector will switch to 'stand-by' when the RCVDS is no longer available. FAILURE RCVDS communication error WARNING : invalid frequency input The entered frequency or applied frequency of the source is out of the projector's range. FAILURE RWI communication error Hardware failure. Call a qualified service technician. WARNING : default settings loaded in the E2PROM Adjustment settings are lost.
Appendix A: BARCO ceiling mount support A BARCO CEILING MOUNT SUPPORT This appendix gives only an overview of the contents of the installation guidelines and some overview drawings. The installation guidelines for the BARCO ceiling mounting support can be ordered from BARCO. The order number: R5975693. Contents of the installation guidelines Overview drawing of the total system 1. Mounting instructions for the upper support to the ceiling CENTER(upper support) a.
Appendix A: BARCO ceiling mount support Projector-position corrections ❒ Water-level adjustment D ❒ Projector axis adjustment C A-2 5975857 BARCOGRAPHICS 1208s 220197
Appendix B: G2 adjustment B G2 ADJUSTMENT Once the on-screen menu "G2 ADJUSTMENT" is displayed, proceed as follows : G2 ADJUSTMENT Use the potentiometers on the G2-ADJ. module to set the screen grid voltage for Red, Green and Blue. Adjust until the LED on the corresponding output amplifier is turned off. to return 891 1 ❒ remove the top cover from the projector (see p.4-1) and open the front metal protection cover by turning out the 3 retaining screws on both sides.
Gamma corrections C GAMMA CORRECTIONS When entering the gamma corrections, a warning will be displayed : "RISK OF INCORRECT ADJUSTMENT OF THE PROJECTOR. THE GAMMA CORRECTIONS ARE FACTORY ADJUSTED USING AN ACTAS COLOUR ANALYSER ! THEREFORE, ONLY QUALIFIED INSTALLATION OR SERVICE PERSONNEL SHOULD PERFORM THESE ADJUSTMENTS ! " If you are qualified, press the key to continue.
Gamma Corrections To carry out the Red and Blue Midlights Correction : ➊ Push the control stick forward or backward to highlight the item R & B MIDLIGHTS in the menu and then press ENTER. If EXIT is pressed, the projector will return to the Service menu. ➋ After ENTER is pressed, a text box with message "Adjust with arrow key" will be displayed on the screen.
Form Approved Bureau Budget No. 45-R0338 MATERIAL SAFETY DATA SHEET MANUFACTURER'S NAME AND FSCM (Federal Supply Code for Manufacturer's) BARCO N.V. EMERGENCY PHONE NO.
SECTION V HEALT HAZARD DATA TRESHOLD LIMIT VALUE EFFECTS OF OVEREXPOSURE EMERGENCY AND FIRST AID PROCEDURES STABILITY SECTION VI REACTIVITY DATA 100ppm CONDITIONS TO AVOID UNSTABLE STABLE X INCOMPATABILITY (Materials to avoid) HAZARDOUS DECOMPOSITION PRODUCTS HAZARDOUS POLYMERIZATION MAY OCCUR X CONDITIONS TO AVOID WILL NOT OCCUR SECTION IX SPECIAL PRECAUTIONS SECTION VIII - SPECIAL PROTECTION INFORMATION SECTION VII SPILL OR LEAK PROCEDURES STEPS TO BE TAKEN IN CASE MATERIAL IS RELEASED
