FRAMED PIVOT DOOR INSTALLATION INSTRUCTIONS QCI5001 Rev 0 Page 1 Certified 06/21/2016
MAINTENANCE: Two primary materials are used to manufacture your new bath enclosure: tempered glass and anodized aluminum. To assure a long lasting finish on the enclosure, wipe it down with a towel after each use. Never use a scouring agent to clean the aluminum. For occasional, more concentrated cleaning efforts, we find that Lysol Bathroom Cleaner works extremely well. Be sure that any over spray falling on the aluminum frame is rinsed thoroughly and dried.
PARTS LIST A. 1 Curb J. 3 #8 x 2” Truss Head Screws T. 2 #6 x 1 1/4” Round Head B. C. D. E. F. G. H. 1 1 2 3 2 1 6 K. L. M. N. P. R. S. 2 1 2 1 3 1 1 V. W. X. Y. 1 1 2 1 Jamb Wiper Vinyl Pivot Jamb Pivot Brackets #6 x 3/8” Truss Head Screws #8 x 1/8” Allen Set Screws Allen Wrench (5/64”) Plastic Wall Anchors #10 x 7/16” Sq.
1 The Framed Pivot Shower Door is completely reversible and may be installed pivot-right or pivot-left. Using the diagram, determine the correct position for your installation. For maximum waterproofing, the pivot jamb should always be opposite the shower head. These instructions depict a pivot left installation. CAUTION: For safety, the door must always open outward. 2 Note: This enclosure may be installed without using the sloped curb [A] provided.
4 Slide the jamb wiper vinyl [B] into the pivot jamb [C]. A small amount of soapy water will help installation. Cut the jamb wiper vinyl 7/8” shorter than the pivot jamb to allow room for the pivot brackets [D]. Fit one of the pivot brackets into the bottom of the pivot jamb. Lock it in place with a #6 x 3/8” truss head screw [E] and a #8-32 x 1/8” set screw [F] (a 5/64” Allen wrench [G] is provided).
7 Insert a nylon pivot bushing [M] into the bottom pivot bracket [D]. Slip the second pivot bushing over the top pivot pin on the door panel. Position the door by inserting the bottom pivot pin into the bottom pivot bracket. Hold the door vertical and slide the top pivot bracket into the pivot bushing. Secure the top pivot bracket with a #6 x 3/8” truss head screw [E] and a #8-32 x 1/8” Allen set screw [F]. 8 Your Pivot Door is equipped with a magnetic catch. Attach the strike jamb [N] to the door.
10 Clean the bottom door rail and the drip rail thoroughly with rubbing alcohol to ensure proper adhesion. Unroll the double stick tape [Y] and carefully apply it to the back of the drip rail (do not peel the tape backing yet). Insert the tapered drip vinyl [W] into the drip rail. Position the drip rail flush with the bottom and pivot side of the door panel [L], then raise the strike side until the bottom edge of the drip vinyl is parallel to the curb [A]. Mark the location of each end of the drip rail.
