WATER METERS ‘M’ SERIES WATER METERS INSTALLATION, OPERATION AND MAINTENANCE GUIDE METAL ‘M’ SERIES WATER METER PLASTIC ‘M’ SERIES WATER METER NETAFIM USA 5470 E. Home Ave. Fresno, CA 93727 CS 888 638 2346 F 800 695 4753 www.netafimusa.
INTRODUCTION ‘M’ SERIES WATER METERS INDUSTRY’S SMALLEST WATER METERS Netafim USA’s ‘M’ Series Water Meters are used as sub-meters for residential or commercial applications and the industry’s smallest multi-jet water meter. The multi-jet principle assures an equally distributed load on the impeller minimizing wear and maintaining accuracy. These meters offer the best cost and performance, long-life flow measurement instruments.
INTRODUCTION ‘M’ SERIES WATER METERS INDUSTRY’S SMALLEST WATER METERS Netafim USA’s ‘M’ Series Water Meters are used as sub-meters for residential or commercial applications and the industry’s smallest multi-jet water meter. The multi-jet principle assures an equally distributed load on the impeller minimizing wear and maintaining accuracy. These meters offer the best cost and performance, long-life flow measurement instruments.
REGISTERS READING A REGISTER REED SWITCH REGISTER READING A REGISTER The Reed Switch Register is a dry contact or simple switch closure for communicating with control and monitoring equipment. Registers are interchangeable and easily replaced with common tools. They are removable even when the meter is operating. A leak indicator in the center of the dial registers the lowest flow through the meter. Flows are totalled in U.S. Gallons and each dial face indicates the multiplication factor.
REGISTERS READING A REGISTER REED SWITCH REGISTER READING A REGISTER The Reed Switch Register is a dry contact or simple switch closure for communicating with control and monitoring equipment. Registers are interchangeable and easily replaced with common tools. They are removable even when the meter is operating. A leak indicator in the center of the dial registers the lowest flow through the meter. Flows are totalled in U.S. Gallons and each dial face indicates the multiplication factor.
INSTALLATION MAINTENANCE INSTALLATION REQUIREMENTS MAINTENANCE REQUIREMENTS 1. 2. 3. 4. 1. Inlet side basket filter should be removed and cleaned every 90 days or as needed based on the water quality at the site (see Figure 5). 2. Inlet side basket filter must remain in place during normal operation in order to avoid debris entering and clogging the metering chamber. 3. Teflon tape should be used on pipe fittings and connections as needed to prevent leaks.
INSTALLATION MAINTENANCE INSTALLATION REQUIREMENTS MAINTENANCE REQUIREMENTS 1. 2. 3. 4. 1. Inlet side basket filter should be removed and cleaned every 90 days or as needed based on the water quality at the site (see Figure 5). 2. Inlet side basket filter must remain in place during normal operation in order to avoid debris entering and clogging the metering chamber. 3. Teflon tape should be used on pipe fittings and connections as needed to prevent leaks.
