Install Instructions

G92 Series BASOTROL Automatic Pilot Gas Valve Installation Instructions 3
BASOTROL
Magnetic Operator
Conduit
Connector
Power
Source
Thermostat
Reset Button
BASO Power Unit
Shutoff
Valve
Thermocouple
Lead
Pilot Burner
Gas Line
Figure 2: Typical Installation for Internal Pilot Gas Flow
BASOTROL
Magnetic Operator
Power
Supply
Thermostat
Conduit
Connector
Pilot Burner
Gas Line
Thermocouple Lead
Shutoff
Valve
BASO
Power Unit
Rotor Pilot Valve
(Optional)
Reset
Button
Figure 3: Typical Installation Showing Internal and Rotor B Valve
BASOTROL
Magnetic Operator
Conduit
Connector
Power
Source
Thermostat
Reset Button
BASO Power Unit
Shutoff
Valve
B Valve
Thermocouple
Lead
Pilot Burner
Gas Line
Figure 4: Typical Installation for External Pilot Gas Flow
