Outdoor Antenna Kit Model Number: HE21404 INSTRUCTION MANUAL After Sales Support - Help Desk Telephone: Internet: 1300 663 907 www.winplus.com.
Description goes here Outdoor Antenna Kit Warranty Details The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.
Contents Warranty 2 Contents 3 Welcome / Warnings 4 Product Features 5 Parts List / Technical Specifications / Installation Tips 6 Instructions 7 FAQ’S 12 Repair and Refurbished Goods or Parts Notice 15 After Sales Support - Help Desk Telephone: Internet: 1300 663 907 www.winplus.com.
Welcome Congratulations on choosing to buy a BAUHN® product. By doing so you now have the assurance and peace of mind that comes with purchasing a product made by one of the leading manufacturers. All products brought to you by BAUHN® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty. We hope you will enjoy using your purchase for many years to come.
Product Features Antenna Connection Antenna Elements Mounting Pole Mount Faceplate • Effective signal reception up to 95kms away from transmission tower, suitable for almost all metropolitan installations in Australia • Robust construction for peace of mind in bad weather.
Parts List • • • • • • • 1 x Outdoor Antenna 1 x 12m Antenna Cable 6 x Antenna Element Screws 4 x Masonry Anchors 2 x Mounting Bolts & Washers 4 x Wood Screws 2 x Wing Nuts & Washers • • • • • • 1 x Mount Faceplate 1 x Mounting Pole 6 x Antenna elements 1 x Manual 1 x Warranty Card 2 x Warranty Stickers Technical Specifications Frequency: Gain: VHF: Polarization: Impedance: Connector: Dimensions: VHF (174-230MHz), UHF (526-820MHz) Up to 5dBi, UHF: up to 7dBi Horizontal 75Ω F-Connector ~1244 x 945 x
Instructions Connect Antenna Elements The Bauhn Outdoor Antenna comes pre-installed with 26 antenna elements. There are an additional 6 elements that should be installed first for optimal reception. 1. 2. Attach the antenna elements to the main body by inserting each element, then securing with the small screws supplied in the pack. Following the diagram below, start with the largest antenna element at the end with the cable outlet, and work up the length of the antenna.
Mounting Antenna The Bauhn Outdoor Antenna Kit includes everything you need to mount your antenna on your home or other outdoor location. Included with the kit are masonry anchors and timber screws. Refer to the installation tips on p.6 for antenna installation advice. Consult a professional if you are unsure or unclear on any steps. 1. Select the location you wish to mount the antenna using the included faceplate.
B. Masonry Mounting: Included with the kit are 4 x 54mm x Ø7.5mm masonry anchors. a. b. c. d. e. Hold the faceplate against the masonary then mark the area with a pencil to note the location of the mounting holes. You will need to drill a hole into the masonry using a masonry drill bit, no deeper than 36mm. The hole must be able to fit in the Ø7.5mm masonry anchor but be no wider than 8mm to allow the anchor to take hold inside the hole. Place the faceplate against the masonry.
Tip: Confirm the correct mounting angle of the mount before tightening the mounting screws. Loosen the screws to adjust the angle of installation. The antenna should be mounted horizontally to achieve the best reception. 3. 4. 10 Check the mount is attached securely to your home before proceeding to attach the antenna. Remove the wing nuts on the mounting attachment located on the main body of the antenna. This will allow you to insert the mounting pole through the U-Bolt as shown.
5. Tighten the bolts to secure the antenna in place. Ensure you tighten the wing nuts at the same rate to balance the mounting attachment. Plugging in the Antenna Cable The Bauhn Outdoor Antenna Kit includes a 12m F-Type Coaxial Cable. This is a common antenna cable and is suitable for most houses and installation scenarios. Should you require a longer cable, contact your local electrical/ electronic supplier. 1. 2.
Frequently Asked Questions Question Answer I’m not receiving good reception - When installing, take note of the direction of your nearby antennas. You can get a good idea of the best direction to face your antenna by looking at those around you. - If you are replacing an already mounted antenna, take note of the height and direction of the old antenna to get a good idea of where to start.
Frequently Asked Questions Question Answer Can I install this antenna inside my roof? - This is not recommended. You would receive very bad reception as a result of interference. Which direction should the antenna face? - You should face your antenna towards the nearest broadcast location. The smallest elements should face the broadcast tower. My reception on my TV is fine, but it is fuzzy on a 2nd TV - This may be due to poor installation or a wiring fault.
Notes: 14 After Sales Support - Help Desk Telephone: Internet: 1300 663 907 www.winplus.com.
Description goes here Outdoor Antenna Kit The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.
