BDF665W 60 cm Freestanding dishwasher
USER MANUAL FOR YOUR BAUMATIC BDF665W 60 cm Freestanding dishwasher NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
Contents Environmental note 4 Important safety information 5–7 Specifications Product dimensions Product specifications Energy efficiency details Electrical details Description of the appliance Control panel 8 - 10 8 8-9 9 9 9 10 Using your dishwasher Before first use Filling with dishwasher salt Setting the water softener level Filling with rinse aid Setting the rinse aid level Filling with dishwasher detergent Loading the upper basket Adjusting the upper basket Loading the lower basket The cutlery b
ENVIRONMENTAL NOTE Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled.
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Customer Care Department. General Safety o Repairs to your appliance must only be carried out by a Baumatic engineer or one of its authorised service agents.
o Care should be taken not to trap the power supply cable underneath the appliance whilst installing it. o No attempt should be made to alter or modify the specifications of this appliance. In daily use o This appliance is only designed to wash normal domestic washloads. If you use your dishwasher in any other way or it is incorrectly used, then Baumatic accepts no liability for any damage that might be caused and any guarantee will be void.
Child Safety o Your dishwasher should only be used by adults. You should not allow children in the area of the machine unsupervised. You should not let them touch the controls or play with the appliance. o It could be possible for a child or pet to gain access to the dishwasher if the door is left open. Therefore please check the inside of the appliance before setting it on a wash cycle. o Any packaging that is removed from the machine should be kept away from children.
Specifications Product dimensions Height: Width: Depth: 850 - 855 mm 600 mm 580 mm Product specifications o 12 Place settings o 7 functions: Normal Intensive Economy Glass Rapid 1 hour 3 in 1 o 4 Wash temperatures: 40°C, 50°C, 55°C, 60°C, 65°C o o o o o o o o o o o o Delay start LED display Residual drying Concealed heating element Self-cleaning stainless steel micro-filter Anti-leak device Anti-flood device Collapsible plate racks Adjustable feet Noise level: 49 dB 3 in 1 wash program Low water consu
Energy efficiency details A+ Energy efficiency class: Washing performance class: A Drying performance class: A Power consumption Off mode: Left on mode: 0.00 W 0.
Control panel 1) 2) 3) 4) Power button LED display (+ rinse aid and salt required indicator neons) Delay start button Program selection buttons Using your dishwasher Before first use o Install the appliance as per the installation instructions contained within this booklet. o Fill the water softener with 0.5 litres of tap water and then fill with specialist dishwasher salt. After this you should set the water softener level. o Fill the rinse aid dispenser and then set the rinse aid dosage.
o Turn the water softener anticlockwise and remove it. cap o Pour 0.5 litres of water into the water softener. IMPORTANT: It is only necessary to do this when you fill the container with salt for the first time. o Pour salt into the water softener, using the funnel that is supplied with the appliance. You should add approximately 1.2 kg of salt into the water softener. o It is perfectly normal for a small amount of water to come out of the water softener, whilst you are filling it with salt.
Setting the water softener level It is possible to regulate the amount of salt that the water softener will release during a wash cycle. The water softener should be set to a level that is appropriate for the hardness of your water (please refer to the table below). Water hardness Clarke degrees 0 – 10 °TH French degrees 0 – 14 10 – 28 14 – 39 28 – 56 39 – 80 56 - 75 80 - 107 Selector position No salt required Minus symbol Halfway position Plus symbol Grams of salt used per cycle 0 Appropriate no.
Filling with rinse aid The rinse aid is released during the final rinse and it helps to prevent water from forming droplets on your dishes. These droplets will lead to spots and streaks being left on items after the wash program has completed. o Your dishwasher is designed to utilise liquid rinse aid. o The rinse aid dispenser is located inside the drop down door, next to the detergent dispenser. o To access the rinse aid dispenser, you should turn the cap anticlockwise and it will pop out of the hole.
o Replace the cap and turn it clockwise until it locks into position. o You should refill the rinse aid dispenser when the rinse aid required indicator neon lights on the control panel. o IMPORTANT: If you are using 3 in 1 dishwasher tablets then you should still fill the rinse aid dispenser. Setting the rinse aid level The amount of rinse aid that the dishwasher requires also depends on the hardness of your water.
Filling with dishwasher detergent The detergent dispenser must be refilled at the start of each wash cycle (apart from the rinse wash program). o Open the lid that closes over the detergent dispenser and place the detergent inside of the dispenser. o The section marked A in the diagram is for the main wash cycle detergent. Only one detergent tablet should be placed in the dispenser at any one time. If you are using detergent powder or liquid, you should follow the detergent manufacturer’s recommendations.
Loading the upper basket The upper basket is most suited to washing delicate and light dishware, such as glasses, coffee & tea cups, saucers, plates, bowls and shallow pans (that are not heavily soiled). o You should position the dishes and cookware in such a way that they are not moved by the spray of water during the wash cycle. o Use the diagram above as a guide to the most appropriate way to load the upper basket.
Lower position o If the upper wheels are placed in the guide supports, then the basket is in the lower position. o For accommodating additional tumblers, cups and mugs. You can also place small, espresso sized cups on top of the side racks. You should take care to ensure that there is enough clearance between the top of the cups placed on top of the side racks and the underneath of the dishwasher interior.
Loading the lower basket The lower basket is most suited to washing larger and more heavily soiled items, such as saucepans, saucepan lids and serving dishes. You can also load bowls and a variety of plates into the lower basket. o Saucepans and serving bowls must always be placed with their bases upwards. o Deep saucepans should be slanted, to allow water to run off.
The cutlery basket Cutlery should be placed inside of the cutlery basket. The cutlery basket should then be placed in the appropriate position in the lower basket. o For the best washing performance, cutlery should be placed through the slots in the top of the cutlery basket. IMPORTANT: Do not allow items of cutlery to fall through the bottom of the cutlery basket, as this may cause damage to the spray arm and/or the cutlery.
Loading dishes and cutlery Household cloths, sponges or any other object that may absorb water SHOULD NOT be washed in a dishwasher. o Remove leftovers and soften the remnants of burnt food in pans, prior to loading dishes in the appliance. o Once the dishwasher has been loaded, check that the spray arms can move freely. If the spray arm comes into contact with any item, then you should rearrange the wash load.
The following items are NOT suitable for washing inside a dishwasher:o Cutlery with a handle of mother-of-pearl, wood, horn or china. o Plastic items that are not resistant to heat. o Cutlery that consists of glued parts that are not resistant to heat. o Cutlery items or crockery that are bonded. o Copper or pewter items. o Lead crystal glass. o Wooden platters. o Synthetic fibre items.
Program table o The ECONOMY program is suitable for cleaning a typical load of dirty dishes and is the most efficient in terms of its combined energy and water consumption. Program 3 in 1 Intensive Normal Economy* 1 Hour Glass Program information For normally soiled loads, such as pots, plates, glasses and lightly soiled pans. Standard daily cycle when using 3 in 1 tablets.
Rapid A shorter wash for lightly soiled loads that do not need drying. Drying Wash (40°C) Rinse Rinse (40°C) 20 grams (main wash) 30 minutes 11.0 0.50 * Economy is the testing program for EN 50242. ** The wash program times that are quoted are intended as a guide only. Please note that factors external to the machine, e.g. the temperature of your water supply, your water pressure etc. can affect the time it takes for the wash program to complete.
o If you open the door whilst the machine is on a wash cycle, then you should open the door slightly. o The spray arms will stop turning after a few seconds. You can then open the door fully. o When you close the dishwasher door, after approximately 10 seconds the wash program will continue. Changing the wash program o Press and hold down the program selection button of the wash program that was in progress for 3 seconds, to cancel the wash program.
Setting a delay start It is possible to delay the start of the wash program for a maximum of 24 hours. o Check whether the appliance needs rinse aid or salt adding to it. o Pull out the top and bottom baskets, then load them in accordance with the loading instructions. o Push the top and bottom baskets fully back into position. o Add detergent o Close the door firmly, so that you hear the door lock click shut. o Switch the appliance on by using the ON/OFF button, the power on indicator will light.
The 3 in 1 wash program Make sure that the water softener has been filled with salt and that the water softener has been set to its lowest setting. Make sure that the rinse aid dispenser has been set to an appropriate level. THIS WASH PROGRAM MUST BE SELECTED IF YOU ARE USING 3 IN 1 DETERGENT. IF YOU USE ANY OTHER WASH PROGRAM WITH 3 IN 1 TABLETS, THEN YOU MAY GET POOR WASH RESULTS. o Hang the 3 in 1 tablet container on the underneath of the upper basket, in the position shown on the diagram.
Rinse aid and salt required indicator neons o The rinse aid and salt required indicator neons on the control panel will let you know when the appliance needs rinse aid or salt adding to it. neon indicates that you need to add rinse aid to the o The appliance. You should follow the procedure outlined on page 13 14. o The neon indicates that you need to add dishwasher salt to the appliance. You should follow the procedure outlined on page 11 – 12.
o Use the shorter and lower temperature cycles for everything but the dirtiest dishes. Shorter cycles use less energy and work just as well. Modern detergents also work just as well at lower temperatures. Cleaning and maintenance IMPORTANT: The appliance should be disconnected from your mains supply before commencing any cleaning process. The filter system Your appliance is fitted with three levels of filtering; these are located in the base of the dishwasher for ease of access.
Cleaning the filters For best performance and results, the entire filter assembly should be thoroughly cleaned regularly (ideally after each wash cycle). 1. Turn the coarse filter anticlockwise and then lift it upwards. Rinse out this section under a tap to remove any food debris that remains in it. 2. Pull out the main filter and rinse this under the tap to remove any food debris that is trapped in it. 3. Pull out the fine filter and rinse this under the tap to remove any food debris that is trapped in it.
Cleaning the spray arms The spray arms should be cleaned regularly, to prevent hard water deposits from clogging the spray arm jets and bearings. o IMPORTANT: Remove the lower basket before attempting to remove the lower spray arm. o Gently pull upwards to remove the lower spray arm. o To remove the upper spray arm, unscrew the nut clockwise and take out the washer that sits on top of the spray arms. o Wash the spray arms in warm, soapy water and use a soft brush to clean the jets.
Cleaning the door o To clean the edge around the outside of the door, you should use a soft, damp cloth only. o To prevent water from penetrating the door lock or electrical components, DO NOT use a spray cleaner of any kind. o DO NOT use any abrasive cleaner or scouring pads on the inner or outer surfaces, as they may cause damage to them.
Error code failure system If your appliance senses that it is not operating correctly, then an error code may appear in the display window. The following error codes can possibly be remedied by the customer and the steps outlined below should be followed. BEFORE COMPLETING ANY MAINTAINEANCE ON THE APPLIANCE, IT SHOULD BE DISCONNECTED FROM YOUR MAINS POWER SUPPLY. E1 o Longer than expected fill time or drain time. Check the water pressure of your mains water supply.
IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact Baumatic Customer Care on telephone number (0118) 933 6911. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.
General troubleshooting PROBLEM Dishwasher doesn’t run POSSIBLE CAUSES Fuse blown or the circuit breaker has tripped Power supply is not switched on WHAT TO DO Replace the fuse or reset the circuit breaker. Remove any other appliances that are sharing the same circuit with the dishwasher. Make sure that the dishwasher is turned on and that the door is closed securely. Make sure that the power cord is fully plugged into the wall socket.
Dishes and pans are not clean Improper program Select a more intense wash program. Improper loading Make sure that the spray arms and the detergent dispenser are not being impeded by large dishes. Spots and filming on glasses and pans Extremely hard water Low inlet temperature Improper loading Improper detergent Incorrect salt/rinse aid levels Steam A normal phenomenon You may get a small amount of steam coming through the vent by the door latch, during drying and water draining.
Installation IMPORTANT: THIS INSTALLATION MUST BE COMPLETED BY A SUITABLY QUALIFIED PERSON. BAUMATIC ONLY SANCTION THE INSTALLATION GIVEN IN THIS INSTRUCTION MANUAL. YOU SHOULD DISPOSE OF ALL PACKAGING IN AN ENVIRONMENTALLY FRIENDLY MANNER. Positioning and levelling the appliance o Remove all dishwasher.
o Place the dishwasher on a solid and level floor surface. o DO NOT PLACE THE DISHWASHER ON A CARPET. o Loosen the adjustable feet that are positioned on the base of the appliance. o Adjust each of the four feet until the appliance is level. IMPORTANT: When the dishwasher is positioned in the location where it will be used. Make sure that all four feet are resting firmly on the floor, by pressing down on each corner and checking that the appliance stands still.
o Ensure that the underneath of the worktop is clean before sticking the strip to it. o Separate the backing paper away from the strip. o Stick the condensation strip to the underneath of the worktop. o IMPORTANT: Failure to attach the condensation strip could result in damage to your worktop. Connecting to the mains water supply IMPORTANT: Do not connect the appliance to your mains water supply using an old or an existing water inlet hose.
Water outlet o The above line drawing shows three different ways in which you can position the drain hose. o Secure the drain hose, so that it cannot move whilst the dishwasher is in use. o Place the end of the drain hose on your drain pipe. Push it a short way down into your drain pipe. o IMPORTANT: Do not insert the drain hose too deeply into the water pipe, as this may cause siphoning. o NEVER EXTEND THE DRAINAGE HOSE FROM ITS ORIGINAL LENGTH.
Power supply o IMPORTANT: The electrical socket must still be accessible once the appliance is installed. o Consult the rating plate, located on the right hand side of the drop down door BEFORE making the electrical connections. Ensure that the voltage reaching the plug is the same as that on the rating plate. o DO NOT REMOVE THE RATING INFORMATION ON IT IS IMPORTANT. PLATE AS THE o The moulded plug that is supplied with the appliance must be placed into an earthed and insulated socket.
o IMPORTANT: We do not recommend that this appliance is connected to an extension lead. Before first use You should check the following before using the appliance for the first time:That That That That That That That salt. o That o o o o o o o the dishwasher is level and fixed in position. the water tap is fully open. there are no leaks at either end of the drain or inlet hoses. the inlet and outlet hose are fully tightened. the inlet and outlet hoses are not kinked. the power is switched on.
Baumatic Consumables o BC001 Degreaser for Dishwashers (200 g) o BC002 Descaler for Washing Machines and Dishwashers (200 g) o BC003 Ceramic Hob Cleaner (250 ml) o BC004 Oven Cleaner (250 ml) o BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.
Technical Data Manufacturer Model Number Standard Place Settings Energy Efficiency Class (1) Annual Energy Consumption (2) Energy Consumption of the Standard Cleaning Cycle Power Consumption of Off Mode Power Consumption of Left-On Mode Annual Water Consumption (3) Drying Efficiency Class (4) Standard Cleaning Cycle (5) Program Duration of the Standard Cleaning Cycle Noise Level Installation Type BAUMATIC LTD BDF665W 12 A+ 291 kWh 1.02 kWh 0.0 W 0.
