BMM204SS 20 Litre microwave oven e 1
User Manual for your Baumatic BMM204SS 20 Litre microwave oven NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
Contents Environmental note 4 Important safety information 5–9 Specifications Product and aperture dimensions Product specifications Electrical details Description of the appliance Control panel The turntable LED display 10 – 14 10 10 - 11 11 12 12 13 13 - 14 Using your microwave Setting the clock Before first use Cooking food Quick start Microwave power level chart Time setting chart Interrupting a cooking cycle Cancelling a cooking cycle Enquiry mode Defrost by time Defrost by weight Setting multipl
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Customer Care Department. General Information o This appliance is designed for domestic household use for heating food and beverages.
o IMPORTANT: The adjacent furniture or housing and all materials used in the installation must be able to withstand a minimum temperature of 85°C above the ambient temperature of the room it is located in, whilst in use. o Certain types of vinyl or laminate kitchen furniture are particularly prone to heat damage or discolouration at temperatures below the guidelines given above.
Warning and safety instructions o This appliance complies with all current European safety legislation. Baumatic do wish to emphasise that this compliance does not remove the fact that the appliance surfaces will become hot during use and retain heat after operation. o DO NOT place anything between the door and the door frame. o DO NOT store anything that is flammable inside of the microwave. When it is switched on, the items could catch fire.
o Do not heat cooking oil or liquid containing alcohol, as there is the chance of spontaneous combustion. o Do not boil eggs or similar foods in their shells, otherwise they may burst. It is possible to poach eggs in your microwave, providing you prick the yolks first. o Do not attempt to lift or move cooking appliances by using the oven door, as this may cause damage to the appliance or result in injury to the person lifting the appliance.
Declaration of conformity o CE: Appliance conforming to the European directives 89/336/EEC, 93/68/EEC, 73/23/EEC and subsequent revisions and “RoHS” directive 2002/95/CE.* o The manufacturer declares that the oven is built using certified materials and requires the appliance to be installed in accordance with the standards currently in force. This appliance must be used by a trained person for domestic purposes only.
Specifications Product dimensions (including frame kit) Height: 382 mm Width: 594 mm Depth: 330 mm Aperture dimensions Height: Width: Depth: 362 mm 560-570 mm 320 mm Product specifications o 5 power levels o 8 functions: o o o o Auto-reheat Vegetables Fish Meat Pasta Potato Pizza Soup Quick start LED full programmer with function display Pushbutton control operation Safety lock 10
o o o o Stainless steel exterior and cavity Mark resistant coating Capacity: 20 litres 800 W Microwave output: Electrical details Rated Voltage: Supply Connection: Max Rated Inputs: Mains Supply Lead: 230 Vac 50 Hz 13 A (double pole switched fused outlet with 3mm contact gap) 1.25 kW 3 x 0.75 mm² For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice.
Description of the appliance A) B) C) D) Control panel Turntable shaft Turntable ring assembly Glass tray E) F) G) Viewing window Door Safety interlock system A) B) C) D) E) F) G) H) I) J) K) LED display Defrost by time button Quick Start/Start button Microwave button Cancel/Stop button Door button Adjustment dial Auto Menu Auto Menu button Clock/Pre-set time button Defrost by weight button Control panel 12
The turntable o Never place the glass tray upside down. o The glass tray and turntable ring assembly MUST always be used during cooking. o All food and food containers must ALWAYS be placed on the glass tray during cooking. o If the glass tray or turntable ring assembly cracks or breaks, it must be replaced immediately. Genuine Baumatic parts can be obtained from the Baumatic Spares Department.
Indicates that a low power level is selected. Indicates that the time of day is shown on the display. Indicates that the safety lock is engaged. Indicates that the auto menu function has been selected. Indicates that grams are shown on the LED display. Indicates that millilitres are shown on the LED display. Using your microwave Setting the clock o When your appliance is connected to the power supply for the first time, the LED display (A) will show 0.00 and an audible signal will sound once.
o The oven cavity and outside of the appliance should be cleaned with warm soapy water, using either a sponge or soft cloth. No abrasive cleaners should be used. The appliance should be thoroughly dried afterwards. Cooking food o Once the clock has been set, your microwave is then ready to use. o Use the door button (F) to open the door of the microwave. o Check that the turntable shaft, turntable ring assembly and glass tray are correctly assembled in the cavity.
taken when removing items from the microwave. We would recommend that you use an oven glove. o After the food has been removed from the microwave, you should make sure that the door is closed. Quick start o If you want to cook on the highest power level setting for a period of time, then you can use the Quick Start/Start button (C). o Press the Quick Start/Start button (C) once and your microwave will operate on full power for 1 minute.
Cancelling a cooking cycle o If you wish to cancel a cooking cycle when it is in progress, you should press the Cancel/Stop button (E). o The microwave will stop heating immediately, give an audible signal and the LED display (A) will return to showing the time of day. o Use the door button (F) to open the door of the microwave. o IMPORTANT: The inside of the microwave and the food that you have been cooking may be extremely hot. So care should be taken when removing items from the microwave.
Defrost by weight o Press the defrost by weight button (K) and the LED display (A) will show “dEF1”. o Turn the adjustment dial (G) to select the weight of the food that you want to defrost. The letter “g” will appear on the LED display (A) to indicate grams. o The microwave will automatically calculate the defrost time, based on the weight that you have selected. o Press the Quick Start/Start button (C) and your microwave will start to defrost the food.
Setting a cooking time in advance o This function will allow you to set a time in the future that the microwave will switch on at. o IMPORTANT: You must make sure that the clock is set to the correct time before using this feature. o Press the microwave button (D) and then use the adjustment dial (G) to set the power level that you require. o Press the microwave button (D) again and then use the adjustment dial (G) to set the cooking time that you require.
Auto menu function o Your microwave has menus pre-programmed into it, where it will cook particular types of food on pre-set power levels and for preset periods of time. o Press the auto menu button (I) to access the auto menu function, the LED display (A) will show “A-1”. o Turn the adjustment dial (G) to select the food type that you want to cook. o Press the auto menu button (I) to confirm the food type. o Turn the adjustment dial (G) to select the weight of the food that you want to cook.
Safety lock o When the microwave is not heating, it is possible to switch on the safety lock. o Press and hold down the Cancel/Stop button (E) for 3 seconds. o The microwave will emit a long audible signal and the LED display (A) will display a padlock symbol. o Until the safety lock is switched off, all buttons on the microwave will be disabled. o To switch off the safety lock, press and hold down the Cancel/Stop button (E) for 3 seconds.
o You should not use ceramic or porcelain crockery, or porous earthenware inside of your microwave. These dishes could absorb moisture from the food whilst it is cooking, which could cause pressure to build up and shatter the dish. o If you are heating certain foods and any liquid, moisture will evaporate and condensation may occur. This does not indicate that the appliance is faulty and it can be particularly noticeable if the ambient temperature of the room is high.
Plastic Microwave-safe only. Follow the manufacturer’s instructions. It should be labelled as “microwave safe”. Some plastic containers soften as the food inside gets hot. “Boiling bags” and tightly closed plastic bags should be slit, pierced or vented, as described by the package. Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow the plastic wrap to touch the food. Thermometers Microwave-safe only. Meat and candy thermometers.
The appliance interior o You should wipe over the inside of the appliance with a soft cloth and warm water mixed with a little washing up liquid. o You should pay particular attention to the door seal and the surrounding area. o DO NOT use abrasive cleaners or sharp objects to clean the inside of the microwave. Turntable and turntable support o The glass tray and turntable ring assembly should be removed from the microwave for cleaning purposes after each use.
Installation The installation must be carried out by a suitably qualified person, in accordance with the current version of the following. o UK Regulations and Safety Standards or their European Norm Replacements. o Building Regulations (issued by the Department of the Environment). o Building Standards (issued by the Scottish Development Department). o IEE Wiring Regulations. o Electricity At Work Regulations. Electrical connection YOUR MICROWAVE IS INTENDED FOR FITTED AND PERMANENT INSTALLATION.
o The wiring in the mains lead is coloured as follows: Brown Blue Green and yellow Live Neutral Earth o As the colours of the wires in the appliance’s mains lead may not correspond with the coloured markings identifying the terminals in your spur box, please proceed as follows: The brown wire must be connected to the terminal marked “L” (live), or coloured red. The blue wire must be connected to the terminal marked “N” (neutral), or coloured black.
Aperture and ventilation requirements o The diagram above shows the aperture and ventilation requirements that you require to build the appliance into a housing unit. o Ensure that the rear panel of the furniture housing unit has been removed. o This oven may be installed without any additional ventilation cut outs being made in the housing unit. However the ventilation cut shown in the diagram MUST be present, otherwise the microwave oven may not function correctly.
Built under installation requirements IMPORTANT: NO OTHER METHODS OF BUILDING UNDER THE MICROWAVE ARE SANCTIONED BY BAUMATIC. o The rear wall of the housing unit MUST be removed to allow there to be the correct amount of ventilation. o The ventilation gaps below the support shelf and below the worktop MUST be adhered to. o An induction hob MUST NOT be fitted above the microwave.
o WARNING: Children should not be allowed near to the appliance unsupervised. Supplied installation components Installing the oven into a housing unit o Fit adjustment screw A into the adjustment screw-hole on the top of the microwave. Adjustment screw A should not be fully tightened at this stage.
o Place the microwave into the housing unit. o IMPORTANT: Do not push the microwave fully into the housing unit, as you still need to be able to access adjustment screw A at this stage of the installation. o Turn adjustment screw A, ensuring that there is a 1 mm gap between adjustment screw A and the underneath of the top surface of the housing unit. o Push the microwave fully into the housing unit. o IMPORTANT: Care should be taken to ensure that you do not trap or kink the power cord.
o Use the frame kit plastic cover and place it over screw-hole B. Troubleshooting o The microwave will not switch on. * Check that the appliance has been connected to the mains supply correctly. * Check that the fuse in the moulded plug has not blown. * Check that the fuses in your fuse box have not blown. * If fuses blow on a regular basis, then we would recommend that you consult with a qualified electrician. * Check that there has not been a power cut. o The microwave will not start cooking.
o The microwave does not switch off. * Isolate the microwave from your mains supply and then contact the Baumatic Customer Care Department. o The interior light bulb is not working. * Call the Baumatic Customer Care Department. The interior light bulb can only be replaced by a trained service technician. o My food is not cooking properly * Check that the power level and cooking time that you have set, is appropriate for the food that you are cooking.
IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact Baumatic Customer Care on telephone number (0118) 933 6911. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.
Baumatic Consumables o BC001 Degreaser for Dishwashers (200 g) o BC002 Descaler for Washing Machines and Dishwashers (200 g) o BC003 Ceramic Hob Cleaner (250 ml) o BC004 Oven Cleaner (250 ml) o BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.
