User Manual for your Baumatic BT06.8ME/BT08.8ME 60 cm Integrated hood NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
Contents Page Environmental note 4 IMPORTANT SAFETY INFORMATION 5–7 Specifications of your cooker hood BT06.8ME BT08.
ENVIRONMENTAL NOTE Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. CONFORMITY TO W.E.E.E.
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Customer Care Department. IMPORTANT: Any installation work must be carried out by a qualified electrician or competent person.
o The edges of the cooker hood are sharp – be mindful of this as you handle your appliance, especially during installation and cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTER! o If the room where the cooker hood is to be used contains a fuel burning appliance such as a central heating boiler then its flue must be of the sealed or balanced flue type. o If other types of flue or appliances are fitted, ensure that there is an adequate supply of air in the room.
o Remember that when in extraction mode, your cooker hood is removing air from your room. Ensure that proper ventilation measures are being observed. o Note that the cooker hood removes odours from your kitchen, not steam. o Warning - Always ensure that the cooker hood has been disconnected from the power supply before carrying out any work on the hood, including cleaning and replacing light bulbs.
Specifications of your cooker hood BT06.
BT08.
Using your Baumatic cooker hood Before first use IMPORTANT: THIS PROCESS MUST BE FOLLOWED BEFORE THE COOKER HOOD IS USED FOR THE FIRST TIME. o You should clean the appliance using a brand new cloth, with warm soapy water before using the appliance for the first time. You should then dry it thoroughly using a soft cloth. To use your cooker hood o Make sure that it has been installed by a suitably qualified person, as per the information contained in Baumatic’s installation instructions.
Speed control slider 0 = Off 1 = Low speed 2 = Medium speed 3 = High speed o The cooker hood can be operated by leaving the speed control slider on setting 1, 2 or 3 and closing the extractor door. This will automatically turn the motor off. o When the extractor door is opened again, the motor will resume at the last set speed. The same also applies for the light slider control. Turning the cooker hood off You can turn the cooker hood off in two ways.
Cleaning your Baumatic cooker hood IMPORTANT: BEFORE CLEANING, ALWAYS ENSURE THAT YOU HAVE SWITCHED YOUR COOKER HOOD OFF AT THE OMNI-POLAR SWITCH, SET AT THE WALL FROM THE CABLE. Cleaning o Clean the external parts of your cooker hood with mild liquid detergent and a new damp cloth. o Never use abrasive powder, corrosive solvents or brushes. o Never insert pointed objects into the motor’s protective grid.
Maintenance Removing and changing the grease filter o Locate the two catches at the base of the filter as shown in the diagram above (1). o Insert a finger into each catch and gently lift and pull the filter outwards (2). o Ensure the filter unclips from the hood, as shown in the diagram above (3), before you pull it away.
o Remove the metal wires which hold the synthetic filter in place. o Remove the synthetic filter and replace with a new clean one. o Reattach the metal wires in their original positions to secure the synthetic filter in place. o Refit the filter in the cooker hood.
Changing a light bulb IMPORTANT: BEFORE ATTEMPTING TO CHANGE A LIGHT BULB, YOU MUST ENSURE THAT YOU HAVE DISCONNECTED THE COOKER HOOD FROM YOUR MAINS SUPPLY. o You should use a suitable screwdriver to loosen the screws holding the panel into place. Once this is removed, you will have access to the bulb. o Prior to touching the light bulbs ensure that they have cooled down. o Unscrew the light bulb and insert a new olive shaped bulb with an E14 coupling 40W (max).
o Once the bulb has been replaced, refit the panel by screwing the screws back into place. Fitting the carbon filter If the appliance is going to be used in recirculation mode then it is necessary to a fit a carbon filter. This will help to absorb unpleasant odours caused by cooking. IMPORTANT: BEFORE ATTEMPTING TO FIT OR REMOVE THE CARBON FILTERS, YOU MUST ENSURE THAT YOU HAVE DISCONNECTED THE COOKER HOOD FROM YOUR MAINS SUPPLY.
o Ensure the filter unclips from the hood, as shown in the diagram on the previous page, before you pull it away. This will allow you access to the motor where the carbon filter should be fitted. o Hook the carbon filter which has two fixing pins (C) onto the motor (D). o Turn the carbon filter clockwise (F), until you feel it click into place. o Refit the filter, making sure it clips back into the hood correctly. o The carbon filters should be replaced every three months, or if they show signs of damage.
Installation IMPORTANT: Before installation and usage read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found behind the grease filter.
o The brown wire must be connected to the terminal marked “L” (live), or coloured red. Before beginning installation o Check that the product purchased is of a suitable size for the chosen installation area. In addition check whether there is an electrical socket available that will be accessible once the hood is mounted. If the product is going to be used in extraction mode, then there should also be space to connect a ducting hose to the outside.
o Select a flat surface for assembling the cooker hood. Cover that surface with a protective covering and place all cooker hood parts and fittings on it. o Do not tile, grout or silicone this appliance to the wall or cabinetry. This appliance is designed to be surface mounted only. Installing your cooker hood IMPORTANT: YOU WILL HAVE TO DECIDE BEFORE INSTALLING YOUR COOKER HOOD WHETHER TO USE IT IN EXTRACTION MODE OR RECIRCULATION MODE.
o Remove the filter by locating the two catches at the base of the filter as shown in the diagram on the previous page (1). o Insert a finger into each catch and gently lift and pull the filter outwards (2). o Ensure the filter unclips from the hood, as shown in the diagram above (3) before you pull it away. o Install the cooker hood between two cupboards. o Drill and insert the screws onto the side boards of the cupboards (the holes should be no larger than 2 mm).
o Hang the cooker hood onto the screws between the two cupboards. o Push the fan-shaped door frames to the end (fully closed), in order to ensure the outer edges of the door frames are parallel to the outer edge of the adjacent cupboards (not the doors). o Mark the positions where the lower screws are to be fixed. o Drill the upper hole and fix the screws, ensuring that all four screws are secured tightly. o Connect the air outlet board and the air outlet tube.
Fitting the décor door o The décor door should be no less than 16 mm thick, 385 – 700 mm high and weigh no more than 7 kg. o Pull out the movable fan-shaped door frames, which are located in two curved plastic slides on each side of the cooker hood. They are prevented from being pulled out too far by plastic limit clips. o Taking care not to drop the frame, pull gently on the plastic limit clips (1) while opening the door frame (2).
o Place the décor door on a protective surface to avoid damage. Mark the installation position of the door frame and the size of the fixed screws to ensure you do not drill too deeply and damage the décor door. o If the upper edge of the door is not as high as the upper edge of the cupboards then you should adjust the size accordingly. o Mark the positions of the screws on the door and ensure the size is as accurate as 569+1 mm.
o Install the adjusting plate, in order to cover the gap between the wall and the bottom of the cooker hood, by screwing it into place. Connecting to external ducting Recirculation: Ducted out: o To use the appliance in extraction mode it is necessary to install external ducting. o Select a position that is suitable for the location of the cooker hood and will be accessible once the cooker hood is installed. Cut out a circle measuring 130 mm in diameter.
o Fit a suitable ducting terminal (not supplied) to the wall and connect a 125 mm ducting hose (not supplied) to the terminal. Genuine spare parts can be obtained by contacting the Baumatic Spares Department. o Connect the other end of the ducting hose to the top of the cooker hood. o The maximum distance between the cooker hood and your discharge outlet should be 3 metres with one 90° bend. For each additional 90° bend, the maximum distance is reduced by 1 metre.
The electrical connection must correspond to the electrical requirement noted on the rating plate, which is placed inside the cooker hood. The appliance should now be connected to the electrical supply. See page 18 – 19 for detailed information on the electrical connection. Refit the grease filter(s) and then switch on the mains supply to the appliance. Check that the appliance is operating correctly by selecting each speed and switching the light bulbs on and off.
o Turn off the hob and then wait for the safety cut-out device to reset. o IMPORTANT: If you have installed your cooker hood too low, the safety cut-out device will frequently trip. Your cooker hood may become damaged if the safety cut-out device is tripped frequently. IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Baumatic Service Department on telephone number (0118) 933 6911.
