USER MANUAL FOR YOUR BAUMATIC TITAN2 Stainless steel side by side 541 litre frost free fridge/freezer NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.
Contents Environmental note Important safety information Specifications of your fridge freezer Dimensions of the appliance Energy efficiency class Cubic capacities Specifications of your appliance Description of the appliance Description of the product features 4 5–6 7 7 7 7 7 8 9-10 Using your Baumatic fridge freezer Before switching on During first use Control panel Turning on the appliance Setting the thermostat in the freezer Setting the thermostat in the fridge Turning on the super freezer option Tur
Environmental note Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled.
Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Technical Department. IMPORTANT: Any installation work must be carried out by a qualified electrician or competent person. Use of the appliance o Your appliance is only designed to be used in the home.
Child safety o Packaging material should be kept away from children. o Children should not be allowed to touch the controls or play with the appliance. General safety o Do not pull on the power supply cable to remove the plug from your mains supply socket. o Do not pull out or insert the plug with wet hands. o Do not attempt to use your appliance outdoors or any place where it is likely to come into contact with the elements.
Specifications of your fridge freezer Congratulations on purchasing a Baumatic fridge freezer Dimensions of your appliance o Height: 1790 mm o Width: 900 mm o Depth: 730 mm Energy efficiency class o Energy class: A Cubic capacities o Gross capacity (fridge): o Gross capacity (freezer): o Net capacity (fridge): o Net capacity (freezer): 357 184 334 170 litres litres litres litres Specifications of the appliance o Frost free fridge and freezer o Multi airflow cooling system o Digital control panel o Ice ma
Description of the appliance Freezer section 1) 2) 3) 4) Door storage compartments Freezer shelves (x 4) Dried foods compartment Meat storage compartment Fridge section 5) 6) 7) 8) 9) 10) 12) Refrigerator shelves (x 4) Movable egg container Salad/vegetable drawer Fruit drawer Dairy compartment Door storage compartments Wine rack 8
Description of the product features Shelves o The shelves may be placed in any of the guide slots within the interior of the appliance. They are protected from sliding out. o To remove a shelf: Take off all of the items that are stored on the shelf that you want to remove. Then lift the front of the shelf and carefully pull it out of the grooves.
Salad/vegetable drawer o For storing salad and vegetables, the drawer is designed to keep the contents fresh for as long as possible. Fruit drawer o For storing fruits, the drawer is designed to keep the contents fresh for as long as possible. o Care should be taken when storing tropical fruit (bananas and pineapples etc) and tomatoes. As these types of items can easily deteriorate in a lower temperature. Dispenser o Will dispense chilled water, cubed ice or crushed ice.
Using your Baumatic fridge freezer Before switching on o Make sure that it has been installed by a suitably qualified person, as per the information contained in Baumatic’s installation instructions. o After delivery, wait for eight hours before connecting the appliance to your mains supply. This means that any refrigerant gasses that may have been disturbed during the transportation process are allowed to settle.
Control panel The control panel is located in the front of the freezer door, above the dispenser. This should always be displayed when the appliance is connected to the mains supply. It shows that the digital control system is operating the appliance. This should always be displayed when the appliance is connected to the mains supply. It shows that the deodorizer is operating correctly. This will light when the water filter needs to be replaced. This will light to show that the child lock is engaged.
Turning on the appliance o You switch on your appliance by connecting it to your mains supply. Setting the thermostat in the freezer o Press the FREEZER SET button to set the temperature in the freezer section. o The temperature that you have selected will show in the digital display next to the FREEZER SET button. o The temperature shown in the display will count through in the sequence shown below:- o We would recommend that the freezer section is set to a minimum temperature of -18°C.
o The temperature shown in the display will count through in the sequence shown below:- o We would recommend that the fridge section is set to a minimum temperature of 5°C. o When the desired temperature appears on the digital display, release the REFRIGERATOR SET button, after a few seconds the temperature will be selected. o On the maximum setting (2°C), the fridge section will work harder to maintain a lower temperature.
Turning on the super refrigerator option This setting should be used if you want to chill something quickly, it will ensure that a powerful supply of cold air enters the fridge compartment. o Press the SUPER REFRIGERATOR button to turn on the super refrigerator option. o The QUICK symbol will light to confirm that the super refrigerator option has been switched on. IMPORTANT: You should not run the appliance in super refrigerator mode for prolonged periods.
o Make sure that you arrange food in such a way that the door can close completely. Particular attention should be given to bottles that may protrude when placed on shelves inside the main section of the refrigerator. o Some organic solutions, such as the oils in lemon/orange peel and acid in butter, can cause damage to the plastic parts contained inside of the refrigerator.
The freezer compartment The freezer compartment is suitable for storing and freezing food. o The freezer compartment temperature must have already reached -18 degrees centigrade (or lower) before you attempt to store food that is already frozen or freezing fresh food. o The freezer compartment is only able to freeze a certain quantity of fresh food at one time. The maximum amount of fresh food (in kilograms) that can be frozen in a 24 hour period is listed on the rating plate.
Tips on freezing o Freezer bags, polythene wraps, aluminium foil (extra thick) and special cans for frozen foods are suitable packaging for storing frozen goods in. o Tape, rubber bands or plastic clips are suitable for sealing bags and wrappings. o Before sealing a suitable bag, you should compress the air out of it, as this will help the food to freeze more easily. o Flat packages freeze more easily. o If you are freezing liquid, then do not fill the container to the brim.
The dispenser When your fridge/freezer is first connected to your mains supply, it will automatically select chilled water mode and the water symbol will light. Before first use You should not attempt to dispense ice for 24 hours after the appliance is first connected to your mains supply. o Once the fridge and freezer sections have cooled sufficiently place a cup against the PUSH pad in the dispenser and pour out a couple of glasses of water.
o Place a cup against the pad in the dispenser and push it, after a few seconds it will dispense water, cubed ice or crushed ice. What comes out of the dispenser will depend on what option you selected before pushing the pad. o You should place the glass directly underneath the water/ice chute and not rest it on the base of the dispenser. Otherwise water/ice can spill or splash.
Dispenser and ice maker warnings o Avoid using fragile cups or crystal glasses if you are dispensing cubed or crushed ice, as damage could be caused to them. o To prevent a bad odour then you should regularly remove the ice from the ice cube storage case. o If you have not dispensed ice for a period of time, then clear all of the ice out of the ice cube storage case and let the appliance produce fresh ice. o DO NOT USE ICE THAT HAS BEEN STORED IN THE ICE CUBE STORAGE CASE FOR A LONG TIME.
Removing and replacing the ice cube storage case o Pull the storage case forwards to remove it from the freezer. o To put the storage case back into position, locate it into the side grooves of the cabinet and push it back into place. o If the storage case does not fully slide back into position, remove it from the freezer again. Rotate the coil inside of the case a quarter of a turn and then slide the storage case back into place.
Cleaning and maintenance WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO CLEAN IT. o Do not clean the appliance by pouring water onto it or spraying water over it. o The refrigerator and freezer compartment should be cleaned periodically, using a solution of bicarbonate of soda and lukewarm water. o Clean the accessories separately with soap and water. Do not clean them in a dishwasher. o Do not use abrasive products, detergents or soaps.
Fridge and freezer door compartments 1) To remove a fridge or freezer door compartment, hold both ends and pull upwards. Fridge and freezer shelves 1) Open the appliance doors fully. 2) To remove a shelf, pull them forwards. Salad/Vegetable and fruit drawers 1) To remove a drawer, lift up a little and pull forward. 1) Use a cloth that has been wetted with water and mild (neutral) detergent and wipe over the interior parts of the appliance.
Dispenser shelf 1) Take out the spillage grill and use a cloth to remove water from and clean this area. DO NOT USE ANY FORM OF ASOLINE (PETROL) OR BENZENE (BENZOL) THINNERS ON ANY AREA OF THE APPLIANCE. AS THESE CHEMICALS CAN DAMAGE THE SURFACES. Defrosting the freezer compartment Your appliance is frost free, so you should not need to manually defrost the freezer section.
o IMPORTANT: You should place some old towels on the flooring that is immediately in front of the appliance. In case any defrost water comes out of the freezer section and onto the floor. o Once all the ice that has built up has melted, then the inside of the freezer compartment should be dried thoroughly. Failure to do this will result in immediate ice build when the appliance is turned back on. o With dry hands, reconnect your appliance to your mains supply.
3) 4) Change the present light bulb with a new one. The replacement bulb should not have a greater rating than 15 W. Push the cover back into position and fully tighten the screws that hold it in place. Freezer section The light bulbs can be found behind the light cover that is below the top shelf. 4) 1) Remove the screws that hold the light cover in place. 2) Hold the bottom of the cover and pull it forward to remove it. 3) Change the present light bulb with a new one.
Installation IMPORTANT: Before installation and usage read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found on the front left edge of the inside of the refrigerator.
Positioning o It is advisable that your appliance is only installed in a location where the ambient temperature of the room, corresponds with the climate classification that is stated on the rating plate of your appliance. Your appliance may not function correctly if the ambient temperature falls outside of the following ranges.
Installation preparation IMPORTANT: A minimum of two people should complete all of the installation steps given in this manual. o Check that the appliance will easily pass through all doorways en route to its final position. o Appliance dimensions: 1790 mm(h) x 900 mm(w) x 730 mm(d). (including door handles). o If your appliance will not fit through a doorway, then it is possible to remove the fridge and freezer doors.
3) Turn the top hinge fastener anti-clockwise 3-4 times and then disconnect the harness wires. 4) IMPORTANT: One person should support the door before attempting this next step. Lift up the front of the hinge and remove it from the appliance. 5) Whilst still supporting the door, slowly lift it upwards to disengage it from the lower hinge. Once the door has been lifted clear of the lower hinge, pull it away from the main chassis of the freezer section.
Removing the fridge door 1) Unscrew the top hinge cover using a screwdriver. Insert a thin screwdriver into the side groove of the cover to remove it. 2) Turn the top hinge fastener anti-clockwise 3-4 times and then disconnect the harness wires. 3) IMPORTANT: One person should support the door before attempting this next step. Lift up the front of the hinge and remove it from the appliance. 4) Whilst still supporting the door, slowly lift it upwards to disengage it from the lower hinge.
Replacing the freezer door 1) Firstly insert the water tube into the hole in the bottom hinge and then insert the bottom of the freezer door into the bottom hinge too. Make sure that the hinge pin has been inserted into the hole in the bottom of the freezer door. 2) Insert the back of the top hinge in the groove on the top of the cabinet. Close the door fully against the cabinet, and then make sure that the top hinge pin is fitted securely into the hole on top of the freezer door.
5) Push down the left hand collar of the coupling and then insert the water tube as far as it will go into the coupling. When it is securely in position, release the left hand collar. Replacing the fridge door 1) Insert the bottom of the fridge door into the bottom hinge, making sure that the hinge pin has been inserted into the hole in the bottom of the fridge door. 2) Insert the back of the top hinge in the groove on the top of the cabinet.
4) Place the top hinge cover back into position and using a screwdriver, fully tighten it to the top of the cabinet. The water inlet hose and water filter o The water pressure should be 2 bar or higher to allow the icemaker to operate correctly. o Care should be taken to make sure that the water inlet does not come into contact with any hot surfaces. o The water filter only filters the water; it does not eliminate bacteria or microbes.
o On the position that you have marked, cut the inlet hose off vertically. o Connect the inlet hose to either side of the water filter. 3) Place the appliance side end of the inlet hose into a container that you can run water into. o Fully open the water tap that the inlet hose is connected to. If water does not come out, then check that you have fully opened the water tap. o Leave the tap open until clear water is flowing out of the appliance side end of the inlet hose.
4) Screw and fasten the filter holder to the left or right hand side of the rear of the appliance. o If the filter holder does not attach very well, then remove the paper that covers a sticky pad on the rear of the filter holder and then screw it into position again. o Clip the water filter into the filter holder. 5) Remove the cover at the bottom rear of the appliance. o Insert the fastening ring into the water inlet, you must ensure that you follow the direction of the nut.
o When you are confident that there are no bends in the water inlet or no leaks, replace the rear cover. You should make sure that the water inlet sits between the groove of the refrigerator back and the compressor cover. 6) Fasten the water inlet in an appropriate position using the fastener provided. IMPORTANT- You must make sure that the water inlet does not get bent or squeezed by being fastened.
Levelling the appliance and adjusting the doors The appliance must be situated on a level and even floor; otherwise the doors may not hang properly or seal correctly. The front of the appliance should be a little higher than the rear of the fridge freezer. This will allow for easy closing of the doors. However if you raise the front of the appliance too high, then you may find it difficult to open the doors.
Replacing the water filter o IMPORTANT: Before commencing this process, please disconnect your appliance from the mains and turn off the water tap. o Remove the water filter from the filter holder and then disconnect the inlet hose from either end of it. o Connect the inlet hose back to either end of the new filter, and then insert the filter back into the filter holder. o Turn back on the water tap and with dry hands reconnect the appliance to the mains.
My fridge freezer is noisy o The refrigerant gas that circulates the pipework of the appliance may make a slight noise, even if the compressor is not running. o If the noise worsens or the appliance gets louder than normal; check that it is levelled off correctly, that nothing is touching the rear of the fridge freezer and that nothing placed inside the appliance is rattling. o The defrosting water caused by the frost free process can make a noise.
Baumatic Ltd. Conditions of guarantee Dear Customer, Your new Baumatic appliance comes complete with a free 12 month guarantee covering both parts and labour costs resulting from defective materials or workmanship. Baumatic also gives you the opportunity to automatically extend the guarantee period for a further 12 months at no extra cost, giving an initial guarantee period of 24 months. The extended guarantee period applies to England, Scotland, Wales and Northern Ireland only.
