TITAN5 Stainless steel 4 door frost free fridge/freezer s
USER MANUAL FOR YOUR BAUMATIC TITAN5 Stainless steel 4 door 607 litre frost free fridge/freezer NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.
Contents Environmental note Important safety information Specifications of your fridge freezer Description of the appliance 4 5–6 7-9 9 The fridge section Adjustable safety glass shelves Crisper drawers Full width pantry Fridge section door storage compartments General and bottle shelf height adjustment The dairy compartments The freezer section Using your Baumatic fridge freezer Before switching on During first use The control panel Switching on the appliance Setting the temperature in the fridge section
Environmental note Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled.
Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Advice Line. IMPORTANT: Any installation work must be carried out by a qualified electrician or competent person. Use of the appliance o Your appliance is only designed to be used in the home.
Child safety o Packaging material should be kept away from children. o Children should not be allowed to touch the controls or play with the appliance. General safety o Do not pull on the power supply cable to remove the plug from your mains supply socket. o Do not pull out or insert the plug with wet hands. o Do not attempt to use your appliance outdoors or any place where it is likely to come into contact with the elements.
Specifications of your fridge freezer Dimensions of your appliance o Height: 1771 mm o Width: 908 mm o Depth: 700 mm (excluding handles) Energy efficiency class o Energy class: A Cubic capacities o Gross capacity (fridge): o Gross capacity (freezer): o Net capacity (fridge): o Net capacity (freezer): 428 179 397 160 litres litres litres litres Specifications of the appliance o Freezer star rating: **** o Frost free fridge and freezer 7
o o o o o o o o o o o o o o o o o o o o o o o Adjustable thermostat Electronic control operation LED display Open door warning indicator Temperature rise warning indicator Fast cooling switch Fast freeze switch Fast freeze indicator light Multi airflow cooling system Water dispenser Automatic motor-driven ice maker 2 x freezer drawers Digital control panel 4 x adjustable safety glass shelves 2 x crisper drawers 2 x safety glass crisper covers 2 x bottle shelves 2 x general door shelves 2 x egg racks Wine r
Description of the appliance 9
The fridge section o We recommend that you leave storage space between food items, to allow for good air circulation. o The temperatures in the fresh food compartment are slightly warmer towards the top and cooler towards the base.
Adjustable safety glass shelves o The shelves may be placed in any of the guide slots within the interior of the appliance. They are protected from sliding out. o To remove a shelf: Take off all of the items that are stored on the shelf that you want to remove. Then whilst lifting the front of the shelf, pull it forwards to unhook it from the slots at the rear of the cabinet.
Crisper drawers The crisper drawers are designed to store fruit, vegetables or meat. The temperature inside of them can be adjusted to one that is suitable for the food items being stored. o To increase the humidity in the crisper drawer, turn the dial that is located on the right hand side of the crisper drawer. o When the dial is moved towards “Hi”, the humidity level is increased.
o For the storage of meat and fish, we would recommend that they are stored in a foil cover or a vinyl wrap. o Care should be taken when storing tropical fruit (bananas and pineapples etc) and tomatoes. As these types of items can easily deteriorate in a lower temperature. Full width pantry The temperature in the full width pantry can be adjusted, depending on the type of food that you are storing in it. o To control the temperature in the full width pantry, use the airregulator dial on the top of it.
o IMPORTANT: IT IS IMPORTANT THAT NONE OF THE SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE. General and bottle shelf height adjustment It is possible to adjust the height of the general shelves and bottle shelves in the doors. o Remove all items from the shelf that you want to adjust the height of. o Hold both sides of the shelf then lift it upwards and pull it towards you.
The freezer section The freezer section consists of an upper and lower drawer. o The lower freezer drawer is suitable for freezing and storing food that needs to be kept for longer periods of time. o The upper freezer drawer contains the ice maker tray on the left hand side. o The right hand side of the upper freezer drawer can be used to freeze food, to store ice or to store food that you use regularly. o IMPORTANT: DO NOT pull the drawers out with too much force, or overload them.
Using your Baumatic fridge freezer Before switching on o Make sure that it has been installed by a suitably qualified person, as per the information contained in Baumatic’s installation instructions. o After delivery, wait for eight hours before connecting the appliance to your mains supply. This means that any refrigerant gasses that may have been disturbed during the transportation process are allowed to settle.
The control panel The control panel is located at the top of the fridge freezer, behind the doors to the fridge section. A= B= C= D= E= F= G= H= Express freeze button Freezer temperature adjustment buttons Freezer temperature display Fridge temperature display Fridge temperature adjustment buttons Express chill button Water filter reset button Water filter change neon Switching on the appliance o You switch on your appliance by connecting it to your mains supply.
o The fridge temperature display will show the temperature being currently achieved in the fridge section. o If there is a power cut, then the fridge freezer will remember the temperature settings that had been previously set. Setting the temperature in the freezer section It is possible to set a temperature between -13°C and -19°C in the freezer section. o Use the freezer temperature adjustment buttons to set the temperature that you require in the freezer section.
Express chill mode This setting should be used if you want to chill something quickly, it will ensure that a powerful supply of cold air enters the fridge section. o Press the express chill button and the indicator neon will illuminate. This confirms that express chill mode has been activated. o Express chill mode will continue to run until the desired temperature has been reached. o Once the desired temperature has been reached, express chill mode will switch itself off automatically.
o It is possible to switch off express freeze mode after 3 hours. To do this, press the express freeze button again. o The indicator neon will go out, confirming that the appliance is no longer in express freeze mode. The water filter change neon o If the water filter change neon comes on, then this means that the water filter needs to be changed. o Please refer to the “Changing the water filter” section on pages 33 - 34. o Once the water filter has been changed, press the water filter reset button.
o Make sure that you arrange food in such a way that the door can close completely. Particular attention should be given to bottles that may protrude when placed on shelves inside the main section of the refrigerator. o Some organic solutions, such as the oils in lemon/orange peel and acid in butter, can cause damage to the plastic parts contained inside of the refrigerator.
The **** freezer section The freezer section is suitable for storing and freezing food. o The freezer section temperature must have already reached -18 degrees centigrade (or lower) before you attempt to store food that is already frozen or freezing fresh food. o The freezer compartment is only able to freeze a certain quantity of fresh food at one time. The maximum amount of fresh food (in kilograms) that can be frozen in a 24 hour period is 10 kg.
o After 24 hours you should check that the fresh food is satisfactorily frozen. Tips on freezing o Freezer bags, polythene wraps, aluminium foil (extra thick) and special cans for frozen foods are suitable packaging for storing frozen goods in. o Tape, rubber bands or plastic clips are suitable for sealing bags and wrappings. o Before sealing a suitable bag, you should compress the air out of it, as this will help the food to freeze more easily. o Flat packages freeze more easily.
o Take care that your frozen food packages do not start to thaw before you place them in your freezer. This will shorten the length of time that you can safely store the food for. Defrosting frozen food o Partially thawed or defrosted foods should be used as soon as possible. o Cold air preserves the food but it does not destroy the micro organisms which rapidly activate themselves after defrosting and make foods perishable.
The dispenser control panel The dispenser control panel is situated on the front of the left hand fridge section door. I= J= K= L= Digital display Hour button Minute button Safety lock button The safety lock When the safety lock is activated, the cold water dispenser is locked and you cannot adjust the time of day. o Press and hold the safety lock button until an audible signal sounds. The indicator neon will switch on to indicate that the safety lock is active.
Setting the time of day The digital display will show the time of day (in 12 hour clock format). o Check that the safety lock is not active; otherwise it is not possible to adjust the time of day. o To set the time of day, press and hold the hour and minute button until an audible signal sounds and the digital display flashes. o Use the hour button to adjust the hour digit shown on the digital display. o Use the minute button to adjust the minute digit shown on the digital display.
Door left open alarm o If any door is left open for more than 60 seconds, an audible alarm will sound. o This audible alarm will sound at 30 second intervals to make you aware that one of the doors has been left open. o When you hear the audible alarm, you should immediately check that all of the doors are shut properly. The ice maker The ice maker and ice maker tray is located in the upper freezer drawer.
o When the ice maker is dispensing ice into the upper freezer drawer, circular dashes will appear on the digital display of the dispenser control panel. IMPORTANT: You should not attempt to open the upper freezer drawer whilst the ice maker is dispensing ice. Ice maker advice and maintenance o When opening the upper freezer drawer, you should take care not too open it with too much force or too quickly. Otherwise you may cause ice cubes to drop into the lower freezer drawer.
Dispenser and ice maker warnings o To prevent a bad odour then you should regularly remove the ice from the ice cube storage case. o If you have not dispensed ice for a period of time, then clear all of the ice out of the ice cube storage case and let the appliance produce fresh ice. o DO NOT USE ICE THAT HAS BEEN STORED IN THE ICE STORAGE CASE FOR A LONG PERIOD OF TIME. o IMPORTANT: If you find that the ice is discoloured, DO NOT use the ice. o o o o Remove all of the ice in the ice cube storage case.
o Clean the door gasket with warm water or a neutral detergent that leaves no residue. A tight-sealing door gasket is critical to the efficiency of your appliance. Usage: o Do not open the door repeatedly or more frequently than you have to. o Do not set the thermostat too low. A change of just one degree can effect the energy consumption by 5%. Use a thermometer to check the temperature. o The freezer compartment should operate at -15 to -18 degrees Celsius.
Cleaning and maintenance WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO CLEAN IT. o Do not clean the appliance by pouring water onto it or spraying water over it. o The refrigerator and freezer sections should be cleaned periodically, using a solution of bicarbonate of soda and lukewarm water. o Clean the accessories separately with soap and water. Do not clean them in a dishwasher. o Do not use abrasive products, detergents or soaps.
The defrost drain hole o Defrosting occurs automatically in the refrigerator section during operation. The defrost water is collected by the evaporating tray and evaporates automatically. o The drain hole should be cleaned periodically with the drain hole cleaner. This will prevent water from collecting in the bottom of the refrigerator, instead of flowing down the defrost drainage channel and drain hole. o IMPORTANT: Please note that the drain hole cleaner should not be left in position permanently.
Replacing the light bulb WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO REPLACE THE LIGHT BULB. Fridge section The light bulbs can be found behind the light covers at the top of the fridge section (below the control panel). o Release the two tabs at the back of the cover and then remove it. o Turn the light bulb anti clockwise, then remove it and fit a new bulb. o The replacement bulb should be type E14 and should not have a greater rating than 25 W.
Freezer section o The light bulb can be found in the middle of upper freezer compartment (in the area where the upper freezer drawer slides into). o Remove the upper freezer drawer (as described on page 40) o Remove the screw in the light cover. o Lift the light cover slightly and remove it from the appliance. o Turn the light bulb anti clockwise, then remove it and fit a new bulb. o The replacement bulb should be type E14 and should not have a greater rating than 25 W.
Changing the water filter When the water filter change neon comes on, then it is necessary to change the filter cartridge and follow the process outlined below. o If the water dispenser and/or ice maker are used daily, then it will be necessary to change the water filter approximately every six months. o If the water dispenser and/or ice maker are used more infrequently, then the water filter can be replaced annually.
o Unclip the filter handle from the cartridge. o Remove the protective heat seal from the new filter cartridge and then clip the filter handle onto it. o Insert the new filter cartridge into the filter housing. IMPORTANT: The filter handle must be in the vertical position. o Gently turn the filter handle clockwise until it locks. The filter handle should now be horizontal, as shown in the line drawing above.
o Run the water dispenser for 3 – 5 minutes, at 1 minute intervals, to flush out the water tank. o Reset the water filter change neon (as described on page 19). o IMPORTANT: After installing a new water filter, discard all ice that is produced in the 24 hour period following the replacement. o The fridge water dispenser and the ice cube maker MUST NOT be used without the water filter. o Replacement water filters are available from the Baumatic Spares Department.
o The wiring in the mains lead is coloured as follows: Brown Blue Green and yellow Live Neutral Earth o As the colours of the wires in the appliance’s mains lead may not correspond with the coloured markings identifying the terminals in your spur box, please proceed as follows: The brown wire must be connected to the terminal marked “L” (live), or coloured red. The blue wire must be connected to the terminal marked “N” (neutral), or coloured black.
o You should check whether there is an electrical socket available, which will be accessible after your appliance is installed. o Place the appliance flatly and firmly on a solid base. The appliance is fitted with adjustable feet on the front side, which can be used to level the appliance. o The rear side of the appliance is fitted with wheels which facilitate the positioning of the appliance into its final location.
o If you are locating the fridge freezer close to a corner, you must ensure that you leave sufficient space to allow for the doors to open and drawers to be removed (refer to the line drawing above). o The appliance should be at least 100 mm away from any electric or gas cookers and 300 mm away from any coal or oil stove. If this is not possible, then ensure that suitable insulation is used.
Attaching the handles Refrigerator door handle o Put the handle connector into the right holes on the refrigerator door using a screwdriver (1). o Place the refrigerator door handle onto the handle holder and keep the hole of the handle holder and handle connector to the right position of the vertical direction (2). o Insert the connecting bolt of the handle into the two holes of the handle holder with the help of a six angle screwdriver (3). o Fix the cover of the top bolts (4).
o Insert the connecting bolt of the handle into the two holes of the handle holder with the help of a six angle screwdriver (3). Removing the right hand door o Using a suitable screwdriver, remove the top hinge screws and then remove the hinge. o IMPORTANT: When removing the hinge and separating it from the door, make sure that the door is supported to stop it falling forward. o Lift the right hand door off of the lower hinge and place it to one side.
o On the rear of the appliance, remove the water pipe cover and then pull the upper securing clip off the water connector. o Push down on the top of the connector to release the water pipe and then remove it. o From the top of the left hand door, pull out the water pipe until it is clear of the main body of the fridge. o Using a suitable screwdriver, remove the top hinge screws and then remove the hinge.
Removing the upper freezer drawer o Open the upper freezer drawer as far as possible. o Remove the ice maker tray and divider. o Pull the rear of the inner compartment of the drawer slightly upwards, to enable the front section to be released from the drawer. o Hold and pull the front section of the inner compartment of the drawer upwards, to remove it from the drawer. o Undo the retaining screws that hold the upper freezer drawer to the telescopic runners.
o Open the lower freezer drawer as far as possible. o Pull the rear of the inner compartment of the drawer slightly upwards, to enable the front section to be released from the drawer. o Hold and pull the front section of the inner compartment of the drawer upwards, to remove it from the drawer. o After you have located the fridge freezer in its final position, the lower freezer drawer should be refitted, following the above process in reverse.
Levelling the doors If the height of the doors is uneven, spacer rings are supplied which can be inserted to raise the level of the doors. o Lift the door that you want to raise upwards from the lower hinge. o Using a suitable pair of pliers, insert a spacer ring between the door and hinge. o Up to 3 spacer rings can be inserted per door, as required. Water supply connection o IMPORTANT: Care should be taken to make sure that the water pipe does not come into contact with any hot surfaces.
o Cut the water pipe to a length that is suitable for your specific installation. The water pipe length should be less than 5 metres; otherwise the dispensing of ice and water will be affected because of insufficient water pressure. o The water pressure should be between 207 – 827 kPa (21 – 123 psi) for the correct operation of the water dispenser and ice maker. o IMPORTANT: You should take care not to bend the water pipe too much.
o Run the water dispenser for 3 – 5 minutes, at 1 minute intervals, to flush out the water tank. Using the ice maker for the first time o After the appliance is connected to your electric supply and starts to cool. When the temperature reaches -15°C, the ice maker will begin to produce ice. o IMPORTANT: Discard all ice that is produced in the 24 hour period after the ice starts to dispense.
IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Customer Care Department on telephone number (0118) 933 6911. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.
Baumatic Consumables o BC001 Degreaser for Dishwashers (200 g) o BC002 Descaler for Washing Machines and Dishwashers (200 g) o BC003 Ceramic Hob Cleaner (250 ml) o BC004 Oven Cleaner (250 ml) o BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.
Technical Data Manufacturer Model Number Product Category Energy Efficiency Class (1) Annual Energy Consumption (2) Storage Volume of Fridge Compartment Storage Volume of Freezer Compartment Star Rating Frost Free Compartments Temperature Rise Time Freezing Capacity Climate Class (3) Noise Level Installation Type BAUMATIC LTD TITAN5 7 – Refrigerator-Freezer A 573 kWh 397 litres 160 litres 4 Fridge and Freezer 6.
United Kingdom Baumatic Ltd., Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Sales Telephone (0118) 933 6900 Sales Fax (0118) 931 0035 Customer Care Telephone (0118) 933 6911 Customer Care Fax (0118) 986 9124 Spares Telephone (01235) 437244 Advice Line Telephone (0118) 933 6933 E-mail: sales@baumatic.co.uk customercare@baumatic.co.uk spares@baumatic.co.uk technical@baumatic.co.uk Website: www.baumatic.co.uk Czech Republic Baumatic CR spol s.r.o.
