Installation Guide

ANGLE WALL MOUNT INSTALLATION.
INSTALLATION AVEC FIXATION
MURALE À ANGLE.
1. Mark screws
position.
Marquer la
position des vis.
2. Add wall anchors.
Ajouter des
ancrages muraux.
3. Fit the bracket to
the angle wall
mounting plate.
Mettre le support
sur la xation
murale à angle.
4. Screw the bracket.
Visser le support.
5. Make the
connections.
Faire les
connections.
6. Install the
doorbell onto
the bracket.
Installer la
sonette sur le
support.
Please visit www.bazzsmarthome.com or www.bazzsmarthome.ca to
download detailed installation instructions.
SVP visitez www.bazzsmarthome.com ou www.bazzsmarthome.ca
pour télécharger les instructions d’installation détaillées.
AC 12V~24V
