SEQUEL® 20 6112 RETURN INSTRUCTION MANUAL LET’S GET STARTED.
Congratulations on the purchase of your Sequel 20 Return 6112 from BDI. Your return has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your return. Please save it for future reference. Your Sequel 20 Return has been engineered for simple assembly. Please follow these directions carefully to prevent any damage.
HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for assembly of this product. For all other concerns, please contact your BDI retailer. PART # DESCRIPTION T1 Hex Wrench QUANTITY 1 PART # DESCRIPTION H2 M6 x 10mm Flathead Screw QUANTITY 4 | BDIUSA.
HARDWARE AND COMPONENTS PART # DESCRIPTION C1 Leg Frame PART # DESCRIPTION C2 Top Frame QUANTITY 1 QUANTITY 1 PART # C3 PART # C4 DESCRIPTION QUANTITY Connector Plate 1 NEED ASSISTANCE? customerservice@bdiusa.com DESCRIPTION QUANTITY Top Panel 1 BDIUSA.
ASSEMBLY STEP 1. INSTALL LEVELERS Install (H4) Levelers into the bottom of (C1) Leg Frame. H4 H4 PART/DESCRIPTION QTY H4-LEVELER 2 H4 ASSEMBLY C1 STEP 2. INSTALL TOP FRAME Connect (C1) Leg Frame to (C2) Top Frame using 4 (H1) Screws and tighten with (T1) Hex Wrench. PART/DESCRIPTION C1 QTY H1 H1 T1-HEX WRENCH 1 H1-SCREW 4 C2 6 | BDIUSA.
STEP 3. INSTALL CONNECTOR PLATE ASSEMBLY The return may be attached to either a desk or a cabinet. IF ATTACHING TO A DESK— COMPATIBLE WITH 6101, 6102: Connect the (C3) Connector Plate to the underside of (C2) Top Frame using 2 (H2) Flathead Screws and (T1) Hex Wrench. Make sure notch is facing outward. Go to step 4.
ASSEMBLY STEP 4. INSTALL SCREW FOR CONNECTOR PLATE The return may be attached either to the left or right of the center drawer (right side shown below). Partially thread 1 (H3) Screw into the middle insert leaving it extended out 1/4" (6mm) to allow (C3) Connector Plate to slide into the space between the screw head and bottom of the desk. PART/DESCRIPTION QTY H3-SCREW 1 1/4" (6mm) gap H3 H3 8 | BDIUSA.
STEP 5. ATTACH THE RETURN Slide the notch on (C3) Connector Plate onto the partially threaded middle screw. Tighten the screw with (T1) Hex Wrench. ASSEMBLY PART/DESCRIPTION QTY T1-HEX WRENCH 1 PART/DESCRIPTION QTY T1-HEX WRENCH 1 H2-FLATHEAD SCREW 2 C3 Insert (H2) Flathead Screws into the left and right holes on the (C3) Connector Plate and tighten with (T1) Hex Wrench. C3 H2 H2 NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.
ASSEMBLY STEP 6. INSTALL TOP PANEL Attach (C4) Top Panel by placing it on top of the return and fastening with (H3) Screws going through the metal tabs in the corners and into the inserts on the underside of the (C4) Top Panel. Make sure the gap between desk glass and return glass is even, then tighten with (T1) Hex Wrench. PART/DESCRIPTION QTY T1-HEX WRENCH 1 H3-SCREW 4 C4 H3 H3 H3 10 | BDIUSA.
STEP 7. INSTALL TOP PANEL ASSEMBLY The return may be attached to the left or right side of the following cabinets: n n n PART/DESCRIPTION QTY T1-HEX WRENCH 1 H2-FLATHEAD SCREW 2 6114 3 Drawer File Pedestal 6116 Lateral File 6117 Multi-Function Cabinet—shown below First, remove the glass top from the cabinet. Attach the (C3) Connector Plate to the cabinet using (H2) Flathead Screws going through the (C3) Connector Plate and into the 2 threaded holes on the top of the cabinet.
ASSEMBLY STEP 8. ATTACH TOP PANEL Attach (C4) Top Panel by placing it on top of the return and fastening with (H3) Screws going through the metal tabs in the corners and into the inserts on the underside of the (C4) Top Panel. Make sure the gap between desk glass and return glass is even, then tighten with (T1) Hex Wrench. PART/DESCRIPTION QTY T1-HEX WRENCH 1 H3-SCREW 4 C4 H3 H3 H3 H3 12 | BDIUSA.
CARE & MAINTENANCE GLASS Glass surface is maintained using household glass cleaner and a paper towel or cloth. SATIN-ETCHED GLASS This uniquely smooth-to-the-touch glass surface can be regularly maintained using household glass cleaner and a paper towel or cloth. Minor scratches or scuffs not eliminated using paper towel or cloth can usually be removed by using a ‘Magic Eraser’. Magic Eraser is a melamine foam product available at any grocery store or home improvement center.
WARRANTY BDI warrants to the original purchaser that for the below stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty which fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component. The decision to repair or replace will be at BDI’s sole discretion.
NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.
