Specification Sheet

2
Product Overview continued
X32
32-Channel, 16-Bus, 40-Bit Digital Mixing Console with Programmable MIDAS-Designed Preamps,
Motorized Faders, 32-Channel Audio Interface and iPad* Remote Control
Product Overview
TheX32isthefully-integratedcenterpieceofBEHRINGER's
digitalmixing,audionetworkingandprocessing
ecosystem.Itcombinesacontrolsurfacewithstreamlined
workow,extensiveI/Oandsignalprocessingintoa
compactdesktopformfactor.Employingmotorizedfaders
androtaryencodersalongwithadaylight-viewableTFT
screen,thecontrolsurfaceisdesignedtoallowimmediate
accesstocriticalfunctionswithtotalandautomaticrecall
ofsettings.Extensiveon-boardI/Oincludes40A/Dand
24D/ACirrusLogicconverters,96bidirectionalchannels
overSuperMACAES50,stereoAES/EBUout,16channels
ofBEHRINGER'sUltranetpersonalmonitoringand32×32
channelsforrecordingoverFirewireorUSB.
Abundantanalogconnectivityisprovidedvia32digitally
controllablemicrophonepreampsdesignedbyMIDAS,
6line-levelauxiliaryinputsandoutputs,16XLRoutputs,
stereomonitoringoutsonXLR/TRSanddualphones
outputs.Eachofthe32microphoneinputscanaccept
balancedorunbalancedmicorline-levellevelsignalsand
includeswitchablephantompower,72dBgainrangeand
max+23dBulevelbeforeclip.Aseparateexternalmic
inputandtheinternaltalkbackmicallowcommunication
tovariousdestinations.
DualAES50EthernetjacksthatemployKLARKTEKNIK
SuperMACtechnologycontribute96×96signalstothe
totalcountof168×168accessiblesourcesanddestinations.
Motorizedfaders,recallablemicpreamps,programmable
routingandtheabilitytosaveandrecallentirescenes
makesetorprogramchangesquickandsimple.Atop
panelUSBconnectorenablessystemdatatobestored
oraboardmixtoberecordeddirectlytoexternalashor
harddrives.
TheInputsectionishomefor16high-resolution100mm
motorizedfaders,providingcontroloverchannels1-16,
17-32,Auxinputs/USBplayback/FXreturns.Aseparate
sectionof8motorizedfaderscontrolsDCAgroups1-8,bus
masters1-8and9-16aswellasmatrices1-6.Themaster
“X-channel”sectionallowsinstanteditingofthecurrently
selectedchannel'sgain,dynamics,EQandotherfunctions.
Acustomassignablesectionallowscertaincontrol
functionstobemappeddirectlytoasetofdedicated
knobsandbuttons.
Amain7"-wide,high-contrastcolordisplayprovides
informationforeditingpertinentparametersofthe
activefunctionoreect.Relevantparametersare
quicklyrecalledtothedisplayforeditingvia“view”
buttonsineachsub-section.Eachchannelalsofeatures
asmall,customizableLCDscreenfortrackname,
number,colorandsourcegraphic.
AvirtualFXrackoers8true-stereo(16mono)multi-
eectsprocessors,with37FXmodelsthateliminate
theneedforanyadditionaloutboardgear.4high-
qualityeectssuchasdelay,chorusandreverb
canrunconcurrentlywith8channelsof31-band
graphicequalization.
Thebuilt-inXUFUSB2.0/FireWire400interfacecard
enablesstreamingofupto32trackstoandfroma
computerforrecording,mixingandmasteringpurposes.
TheX32integratesseamlesslywithotherX32consoles,
theS16digitalstageboxandtheP-16personalmonitoring
systemforcompletelive,studioandinstalledsound
solutions.Controlthemixerfromadistancewiththefree
iPadapporwitheditingandremotecontrolsoftware
connectedviaEthernet.TheX32'seaseofuse,
intuitiveworkow,diversefeaturesetandintegration
withotherequipmentmakeitanidealcenterpiecefor
installedandproductionsoundinanysetting.
