F5U218-MOB

Hi-Speed USB 2.0 Thumb Hub

User Manual

Add 4 additional Hi-Speed USB 2.0 ports to your notebook

Summary of content (9 pages)

PAGE 1
Hi-Speed USB 2.0 Thumb Hub Add 4 additional Hi-Speed USB 2.
PAGE 2
TABLE OF CONTENTS Introduction . . . . . . . . . Features . . . . . . . . . . Package Contents . . . . Technical Specifications Installation . . . . . . . . . Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 .2 .2 .3 .4 .
PAGE 3
INTRODUCTION Congratulations and thank you for purchasing the Belkin Hi-Speed USB 2.0 Thumb Hub (the Hub). The Hub provides four downstream USB ports that are compatible with both USB 1.1 (low- and full-speed) devices, as well as with Hi-Speed USB 2.0 (high-speed) devices. This means that the Hub is backward-compatible with all of your current USB 1.1 devices as well as with the new generation of Hi-Speed USB 2.0 devices.
PAGE 4
INTRODUCTION Features • Compliant with Universal Serial Bus specification 2.0 (data rate 1.5/12/480Mbps) • Backward-compatible with Universal Serial Bus specification 1.1 (data rate 1.5/12Mbps) • Compatible with Windows® 98 SE, Me, 2000, and XP • Approved by USB Implementers Forum (USB-IF) • Plug-and-Play technology • Hot-swappable with USB devices • Over-current detection and protection • Four 480Mbps downstream ports • Fully compatible with USB 1.1 and USB 2.
PAGE 5
INTRODUCTION Technical Specifications Upstream Ports Downstream Ports Per-Port Voltage Per-Port Current Power Mode Operating Temperature Storage Temperature Enclosure Power Supply 1 4 DC +5V 500mA (max) (Self-Powered mode) 100mA (max) (Bus-Powered mode) Self-Powered/Bus-Powered 5º C ~ 40º C -2º C ~ 60º C Plastic Output: DC 5V 2.1A Plug Size: 3.5mm (outer) 1.
PAGE 6
INSTALLATION 1. Plug the AC adapter into a wall outlet or surge suppressor. Plug the DC connector into the DC power jack found on the side of the Hub (see Fig. 1). A red light on the Hub should come on indicating that the Hub is getting power from the power supply, or from the USB port (if the Hub is being operated without the power supply). Note: The Hub may be used without the power supply when connecting low-power devices such as standard keyboards and mice. 2.
PAGE 7
INSTALLATION Important Note: Hi-Speed USB 2.0 hub drivers are included with most USB 2.0 PCI upgrade cards, and are pre-installed along with the PCI card drivers. If you purchased an upgrade card prior to the release of Hi-Speed USB 2.0 hub support, please check with your PCI card vendor for an updated USB 2.0 driver. The Belkin Hi-Speed USB 2.0 driver supports all competitive cards based on the NEC host controller with the exception of Adaptec. The most recent Belkin driver is available at www.belkin.com.
PAGE 8
INFORMATION FCC Statement DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our sole responsibility that the product: F5U218-MOB to which this declaration relates: Complies with Part 15 of the FCC Rules.
PAGE 9
Belkin Corporation 501 West Walnut Street Compton • CA • 90220 • USA Tel: 310.898.1100 Fax: 310.898.1111 Belkin Components, Ltd. Express Business Park • Shipton Way Rushden • NN10 6GL • United Kingdom Tel: +44 (0) 1933 35 2000 Fax: +44 (0) 1933 31 2000 Belkin Components B.V. Starparc Building • Boeing Avenue 333 1119 PH Schiphol-Rijk • The Netherlands Tel: +31 (0) 20 654 7300 Fax: +31 (0) 20 654 7349 Belkin, Ltd.
