User's Manual

NOTE: Full Kit will service one axle
Half Kit will service one S-camshaft
137
UHB800-CAM
S-CAMSHAFT OVERHAUL KITS
Spicer Drive Axle Brake
Full Kit Number: 43-7081
Half Kit Number: 43-7081-1
Item Spicer Description Full Kit Half Kit
No. No. Qty. Qty.
1 28-1266 Camshaft Bushing 4 2
2 29-1287 Camshaft Seal 4 2
General Information
• 16
1
/
2
x 5", 6" and 7" “XL” and “XLII” Brakes
• 1
1
/
2
" Diameter at Spider
Intraax Trailer Axle Brake
Full Kit Number: 43-7090
Half Kit Number: 43-7090-1
Item Spicer Description Full Kit Half Kit
No. No. Qty. Qty.
1 29-1310 Camshaft Washer 2 1
2 29-1311 Camshaft Washer 2 1
3 28-1231 Camshaft Spider Bushing 2 1
4 35-1580 Anchor Pin Washer 2 1
5 30-1358 Cam Support Housing 2 1
6 29-1269 Spider Seal 4 2
7 29-1306 Camshaft Lockring 2 1
8 34-1563 Anchor Pin Retainer 2 1
9 29-1309 Camshaft Washer 2 1
General Information
• 16
1
/
2
" Brake
• 1
1
/
2
" Diameter at Spider
• Bronze Spider Bushings
• Hendrickson Intraax Suspension System
