GL2023A / GL2023 LCD Monitor User Manual
Copyright Copyright 2013 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.
BenQ ecoFACTS BenQ has been dedicated to the design and development of greener product as part of its aspiration to realize the ideal of the "Bringing Enjoyment 'N Quality to Life" corporate vision with the ultimate goal to achieve a low-carbon society.
Table of Contents Copyright ......................................................................................................................................2 Getting started .............................................................................................................................5 Getting to know your monitor ................................................................................................7 Front view ...................................................................
Getting started When unpacking please check you have the following items. If any are missing or damaged, please contact the place of purchase for a replacement. BenQ LCD Monitor Monitor Base Quick Start Guide CD-ROM Power Cord (Picture may differ from product supplied for your region.
• Available accessories and the pictures shown here may differ from the actual contents and the product supplied for your region. For cables that are not supplied with your product, you can purchase them separately. • Consider keeping the box and packaging in storage for use in the future when you may need to transport the monitor. The fitted foam packing is ideal for protecting the monitor during transport. Always keep the product and accessories out of reach of small children.
Getting to know your monitor Front view 1. Control buttons 2. Power button 1 2 Back view 3. Input and output ports (vary by model, see Input and output ports on page 8) 4. Kensington lock slot 3 4 • Above diagram may vary depending on the model. • Picture may differ from product supplied for your region.
Input and output ports Available input and output ports may vary depending on your purchased model. Check the Specification document on the provided CD for details. Models with dual inputs 1. AC power input jack 2. DVI-D socket 1 2 3 3.
How to assemble your monitor hardware • If the computer is turned on you must turn it off before continuing. Do not plug-in or turn-on the power to the monitor until instructed to do so. • The following illustrations are for your reference only. Available input and output jacks may vary depending on the purchased model. 1. Attach the monitor base. Please be careful to prevent damage to the monitor.
You should position the monitor and angle the screen to minimize unwanted reflections from other light sources. 2. Connect the video cable Either Do not use both DVI-D cable and D-Sub cable on the same PC. The only case in which both cables can be used is if they are connected to two different PCs with appropriate video systems. (Not available for analog-only models). To Connect the D-Sub Cable Connect the plug of the D-Sub cable (at the end without the ferrite filter) to the monitor video socket.
3. Connect the power cable to the monitor. Plug one end of the power cord into the socket labelled "POWER IN" on the rear of the monitor. Do not connect the other end to a power outlet just yet. 4. Route the cables via the cable clip. Release the cable retaining clip by squeezing the clip inwards as illustrated. Position the cables together and reinsert the clip over them to retain the cables neatly in place behind the monitor stand. 5. Connect-to and turn-on the power.
How to detach the base 1. Prepare the monitor and area. Turn off the monitor and the power before unplugging the power cable. Turn off the computer before unplugging the monitor signal cable. Protect the monitor and screen by clearing a flat open area on your desk and placing a soft item like a towel on the desk for padding, before laying the screen face down on a flat clean padded surface. Please be careful to prevent damage to the monitor.
Using the monitor wall mounting kit The back of your LCD monitor has a VESA standard mount with 100mm pattern, allowing the installation of a wall mount bracket. Before starting to install a monitor wall mounting kit, please read the precautions carefully. Precautions: • Install your monitor and monitor mounting kit on a wall with flat surface. • Ensure that the wall material is stable to support the weight of the monitor.
Getting the most from your BenQ monitor To gain the most benefit from your new BenQ LCD monitor, you should install the custom BenQ LCD Monitor driver software as provided on the BenQ LCD Monitor CD-ROM. The circumstances under which you connect and install your BenQ LCD Monitor will determine which process you need to follow to successfully install the BenQ LCD Monitor driver software.
How to install the monitor on a new computer This instruction details the procedure for selecting and installing the BenQ LCD Monitor driver software on a new computer which has never had a monitor driver installed before. This instruction is only suitable for a computer which has never been used before, and for which the BenQ LCD Monitor is the first ever monitor to be connected to it.
How to upgrade the monitor on an existing computer This instruction details the procedure for manually updating the existing monitor driver software on your Microsoft Windows computer. It is currently tested as compatible for Windows 8, Windows 7, and Windows Vista Operating System (OS).
How to install on Windows 8 system 1. Open Display Properties. Move the cursor to the lower-right of the screen or press the Windows + C buttons on the keyboard to bring up the Charm bar. Go to Settings, Control Panel, Devices and Printers and right-click the name of your monitor from the menu. Alternatively, right-click the desktop and select Personalize, Display, Devices and Printers, and right-click the name of your monitor from the menu. 2. Select Properties from the menu. 3. Click the Hardware tab. 4.
How to install on Windows 7 system 1. Open Display Properties. Go to Start, Control Panel, Hardware and Sound, Devices and Printers and right-click the name of your monitor from the menu. Alternatively, right-click the desktop and select Personalize, Display, Devices and Printers, and right-click the name of your monitor from the menu. 2. Select Properties from the menu. 3. Click the Hardware tab. 4. Click Generic PnP Monitor, and then the Properties button. 5.
How to install on Windows Vista systems 1. Open Display Settings. Right-click the desktop and select Personalize from the popup menu. Select Display Settings from the Personalize appearance and sounds window. The Display Settings window will display. 2. Click the Advanced Settings button. The Generic PnP Monitor Properties window will display. 3. Click the Monitor tab and the Properties button. 4. Click Continue in the prompted User Account Control window. 5.
Picture optimization The easiest way to obtain an optimal display from an analog (D-Sub) input is to use the AUTO key function. Press the AUTO key to optimize the currently displayed image to the screen. When you connect a digital input signal using a digital (DVI) cable to your monitor, the AUTO key and the Auto Adjustment function will be disabled, because the monitor will automatically display the best image.
How to adjust your monitor The control panel 1 2 3 4 5 6 1. AUTO: Adjusts vertical position, phase, horizontal position and pixel clock automatically. 2. MENU key: Activates OSD main menu and return to the previous menu or exit OSD. 3. 4. /Mode key: For Left/Decrease adjustment. The key is the hot key for Mode. /Contrast/Brightness key: For Right/Increase adjustment. The key is the hot key for Brightness and Contrast. 5. ENTER key: Enters sub menus and select items.
Hot key mode The monitor keys perform as hot keys to provide direct access to particular functions whenever the menu isn't currently displaying on-screen. Brightness and Contrast hot keys Press the key to display the Brightness and Contrast indicators. Further press the or keys, then the ENTER key to select Brightness or Contrast. The key will increase the level, while the level. key will decrease the To exit, press the MENU key.
Main menu mode You can use the OSD (On Screen Display) menu to adjust all the settings on your monitor. Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. Press the MENU key to display the following main OSD menu. 1 2 3 Depending on your purchased model, different OSD menus are available. 4 1. Display 2. Picture 3. Picture Advanced 4. System Auto Adjustment H. Position 10 V.
Display menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. 1. Press the MENU key to display the main menu. 2. Press the or keys to select DISPLAY and then press the ENTER key to enter the menu. Auto Adjustment H. Position 10 V. Position 12 Pixel Clock 1 12 Phase 3. Press the or keys to move the highlight to a menu item and then press the ENTER key to select that item. 4.
Item Phase Function Adjusts the pixel clock phase timing to synchronize with the analog input video signal. Not applicable to a digital input signal. Operation Range Press the or keys to adjust the value. 0 to 63 See also: Picture optimization on page 20.
Picture menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. 1. Press the MENU key to display the main menu. 2. Press the PICTURE MODE: Standard Brightness 12 Contrast 10 3. Press the or keys to move the highlight to a menu item and then press the ENTER key to select that item. 3 Gamma Color Move Item 26 ENTER Select keys to select key to enter the menu.
Item Function Operation Range Color - Press ENTER to enter the Color menu. Color Temperature Normal: Allows video and Press the or still photographs to be select this option. viewed with natural coloring. This is the factory default color. keys to Bluish: Applies a cool tint to the image and is factory pre-set to the PC industry standard white color. Reddish: Applies a warm tint to the image and is factory pre-set to the news print standard white color.
Picture Advanced menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. 1. Press the MENU key to display the main menu. 2. Press the or keys to select PICTURE ADVANCED and then press PICTURE ADVANCED MODE: Standard Picture Mode OFF 3. Press the or keys to move the highlight to a menu item and then press the ENTER key to select that item. YUV 4. Press the or keys to make adjustments or selections.
Item Function Operation Range Senseye Demo Displays the preview of Press the or keys to • ON screen images under the change the settings. • OFF selected mode from Picture Mode. The screen will be divided into two windows; the left window demonstrates images of Standard mode, while the right window presents the images under the specified mode. Dynamic Contrast The function is to automatically detect the distribution of an input visual signal, and then to create the optimal contrast.
Item Display Mode Function Range This feature is provided to Press the or keys to • Overscan allow aspect ratios other than change the settings. • Full 16:9 or 16:10 (depending on • Aspect the purchased model) to be displayed without geometric distortion. • Overscan - Slightly enlarges the input image. Use this feature to hide annoying edge noise if present around your image. • Full - Scales the input image to fill the screen. Ideal for 16:9 or 16:10 (depending on the purchased model) aspect images.
Item Color Format Function Determines the color space (RGB or YUV) based on the following detected video signal: Operation Range Press the ENTER key to • RGB select this option. Press the • YUV or keys to change the settings. • D-Sub (VGA) from PC: The default Color Format is RGB. • D-Sub (Component) from a video device: The default Color Format is YUV. You might need to manually set the Color Format if colors shown on the monitor screen do not display properly.
System menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. 1. Press the MENU key to display the main menu. 2. Press the SYSTEM MODE: Standard Input D-sub DDC/CI Auto Power off Information Reset All Item Input ENTER Select MENU key to enter the menu. Exit 4. Press the or keys to make adjustments or selections. 5. To return to the previous menu, press the MENU button.
Item Language Function Operation Range Sets the OSD menu language. Press the or keys to change the settings. • English • French • German • Italian • Spanish • Polish The language options displayed on your OSD may differ from those shown on the right, depending on the product supplied in your region. • Japanese • Czech • Traditional Chinese • Hungarian • Simplified Chinese • Serbo-Croatian • Romanian • Dutch • Russian • Swedish • Portuguese H.
Item OSD Lock Function Operation Prevents all the monitor settings from being accidentally changed. When this function is activated, the OSD controls and hotkey operations will be disabled. Press the or keys to change the settings. Range • YES • NO To unlock the OSD controls when the OSD is preset to be locked, press and hold the MENU key for 15 seconds to enter the OSD Lock option and make changes.
Troubleshooting Frequently asked questions (FAQ) The image is blurred: Read the instructions on the link "Adjusting the Screen Resolution" on the CD, and then select the correct resolution, refresh rate and make adjustments based on these instructions. How do you use a VGA extension cable? Remove the extension cable for the test. Is the image now in focus? If not, optimize the image by working through the instructions in the "Adjusting the refresh rate" section on the link "Adjusting the Screen Resolution".
Faint shadow from the static image displayed is visible on the screen: • Activate the power management function to let your computer and monitor go into a low power "sleep" mode when not actively in use. • Use a screensaver to prevent the occurrence of image retention. Is the prompt on the display illuminated in orange? If the LED is illuminated in orange, the power management mode is active. Press any button on the computer keyboard or move the mouse.
