GP10 Ultra Lite LED Projector User Manual
Table of contents Important safety instructions ................... 3 Introduction.................. 6 Projector features.....................................6 Shipping contents ......................................7 Projector exterior view...........................8 Controls and functions ............................9 Positioning your projector ..................... 14 Obtaining a preferred projected image size..............................................................14 Connection .................
Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions 1. Please read this manual before you operate your projector. Save it for future reference. 2. Do not look straight at the projector lens during operation.
Safety Instructions (Continued) 6. Never replace any electronic components unless the projector is unplugged. 9. 10. 4 7. Do not place this product on an unstable cart, stand, or table. The product may fall, sustaining serious damage. 8. Do not attempt to disassemble this projector. There are dangerous high voltages inside which may cause death if you should come into contact with live parts. Refer servicing only to suitably qualified professional service personnel.
Safety Instructions (Continued) - Locations near fire alarms 13. - Locations with an ambient temperature above 40°C / 104°F - Locations where the altitudes are higher than 3000 m (10000 feet). Do not stand the projector on end vertically. Doing so may cause the projector to fall over, causing injury or resulting in damage to the projector. 3000 m (10000 feet) 0m (0 feet) 11. 14. Do not step on the projector or place any objects upon it.
Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features. • • • • • • • 6 Advanced LED light source Long lasting LEDs provides a longer life span than traditional lamps. Optical engine with DLP technologies WXGA resolution and a bright picture.
Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. *The warranty card is only supplied in some specific regions. Please consult your dealer for detailed information.
Projector exterior view Front/upper side 1 2 7 3 3 1 4 8 2 5 8. 9. 10. 11. 12. 13. 14. 6 Rear/lower side 10 11 12 13 14 15 16 17 9 1. 2. 3. 4. 5. 6. 7. 18 19 15. 16. 17. 18. 19. 20. Vent (cold air intake) Internal Speakers Vent (heated air exhaust) Front IR remote sensor Projection lens Lens cover External control panel (See "Projector" on page 9 for details.
Controls and functions Projector 4. 8 1 9 10 2 3 4 5 6 11 12 7 5. 1. POWER indicator light Lights up or flashes when the projector is under operation. 2. Power Toggles the projector between standby mode and on. See "Starting up the projector" on page 26 and "Shutting down the projector" on page 65 for details. 6. Up/Volume up key When the On-Screen Display (OSD) 7. menu is on: - Navigate up to select the desired menu items. - Make adjustments. (e.g. manual keystone...
8. TEMPerature indicator light Lights up red if the projector's temperature becomes too high. 9. LED indicator light Indicates the status of the light source. Lights up or flashes when the light source has developed a problem. 10. Home Directly returns to home screen from lower level of OSD. Exits application/pop-up message and back to home screen directly. 11. Right key When the On-Screen Display (OSD) menu is on: - Navigate right to select the desired menu items. - Make adjustments. (e.g.
Remote control 4. 1 8 2 9 3 4 5 6 7 10 11 12 5. 1. 2. 3. POWER Toggles the projector between standby mode and on. See "Starting up the projector" on page 26 and "Shutting down the projector" on page 65 for details. Blank Toggles Blank on and off. See "Hiding the 6. image" on page 28 for details. Up/Volume up key When the On-Screen Display (OSD) menu is on: - Navigate up to select the desired menu 7. items. - Make adjustments. (e.g. manual keystone...) When the On-Screen Display (OSD) 8.
10. Right key When the On-Screen Display (OSD) menu is on: - Navigate right to select the desired menu items. - Make adjustments. (e.g. brightness, contrast...) When the On-Screen Display (OSD) menu is off: (Only applied to SD card, internal memory and USB Drive) - Play next video and audio file. - Press and hold to fast forward video and audio file. 11. OK Confirms a selected function when a menu is displayed. Plays or pauses a video, music, photo slideshow.
Remote control effective range Infra-Red (IR) remote control sensor is located on the front of the projector. The remote control must be held at an angle within 15 degrees perpendicular to the projector's IR remote control sensor to function correctly. The distance between the remote control and the sensor should not exceed 7 meters (~ 23 feet). Appr ox. 1 5° Make sure that there are no obstacles between the remote control and the IR sensor on the projector that might obstruct the infra-red beam.
Positioning your projector Obtaining a preferred projected image size The distance from the projector lens to the screen, the zoom setting (if available), and the video format each factors in the projected image size. 16:10 is the native aspect ratio of this projector. 16:10 aspect image scaled to a 4:3 aspect display area The projector should always be placed horizontally level (like flat on a table), and positioned directly perpendicular (90° right-angle square) to the horizontal center of the screen.
Projection dimensions Refer to "Dimensions" on page 70 for the center of lens dimensions of this projector before calculating the appropriate position.
Connection In the connections shown below, some cables may not be included with the projector (see "Shipping contents" on page 7). They are commercially available from electronics stores. Connecting the power 1. 2. Insert one end of the provided power cord into the AC IN terminal. Insert the plug on the power cord into a wall outlet. Check that the Power LED indicator on the projector lights orange when using the AC adapter. Connecting the DVD player 1. 2. 3. 4. 5.
Connecting a computer The projector provides a VGA input socket that allows you to connect it to both IBM® compatibles and Macintosh® computers. A Mac adapter is needed if you are connecting legacy version Macintosh computers. To connect the projector to a notebook or desktop computer: • Using a VGA cable 1. Take the supplied VGA cable and connect one end to the D-Sub output socket of the computer. 2. Connect the other end of the VGA cable to the COMPUTER socket on the projector. 3.
• Using an HDMI cable 1. Take an HDMI cable and connect one end to the HDMI output jack of the computer. 2. Connect the other end of the HDMI cable to the HDMI jack on the projector. • Using a USB cable 1. Take a USB cable and connect the type A end to the USB output jack of the computer. 2. Connect the mini-B type end of the USB cable to the mini-B USB jack on the projector.
iii. Disconnect the USB cable only when the message says that it is safe to remove the hardware. • Do not disconnect the USB cable while the files are being copied, as this could result in loss of data or damage to the projector. • The connection will not end if you have projector files open on the computer. Close all projector files and try again. • Other versions of Windows operate similarly. Follow the correct procedure for removing a USB device from your computer safely for your version of Windows.
Connecting an HDMI source device The projector provides a HDMI input jack that allows you to connect it to an HDMI source device like a Blu-Ray player, a DTV tuner or a display. HDMI (High-Definition Multimedia Interface) supports uncompressed video data transmission between compatible devices like DTV tuners, Blu-Ray player and displays over a single cable. It provides pure digital viewing and listening experience.
Connecting a Component Video source device Examine your Video source device to determine if it has a set of unused Component Video output sockets available: • • If so, you can continue with this procedure. If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a Component Video source device: 1. 2. 3.
Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: • • If so, you can continue with this procedure. If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a composite Video source device: 1. 2. 3. Take a Video cable and connect one end to the composite Video output socket of the Video source device.
Connecting an external speaker You can hear sound through an external speaker instead of the internal speakers built into the projector. To connect the projector to an external speaker source device: 1. Connect an appropriate stereo cable to the external speaker and the audio output jack on the projector. When the audio cable is connected to the audio output jack, the speaker output is muted.
Connecting to an external memory device Connecting an SD card To connect the projector to an SD card: 1. Connect an SD card to the SD card slot on the projector. • The maximum memory capacity supported for an SD(HC) card is 32 GB. (The maximum capacity supported for external memory is based on our factory test. Your experience may differ depending on the manufacturer of the memory device.) • The projector may not be compatible with some SD cards.
• A USB storage device that uses only a designated driver might not be recognized. • Recognition speed for USB storage device may vary by device. • Do not turn off the product or pull a connected USB storage device out while the USB storage device is in use. Doing so may result in damage to the USB storage device or stored file. • Use a USB storage device which contains normal files. Abnormal files can cause a malfunction or the files may not play.
Operation Starting up the projector 1. Connect the power using the power cord. The Power indicator turns into orange. 2. Press II Power on the projector or remote control to start the projector. The Power indicator lights green when the projector is on. The start up procedure takes several seconds. In the later stage of start up, a startup logo is projected. (If necessary) Rotate the focus ring to adjust the image clearness.
Adjusting the projected image Adjusting the image height The projector is equipped with 2 adjuster feet. This adjusters change the image height. To adjust the projector: 1. Screw the adjuster feet to adjust the image height. To retract the feet, screw the adjuster feet in a reverse direction. If the projector is not placed on a flat surface or the screen and the projector are not perpendicular to each other, the projected image becomes trapezoidal.
Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. Correcting keystone when an image is displayed on the screen. To correct this, besides adjusting the height of the projector, you will need to manually correct it following one of these steps. 1. 2. Press and then press to highlight Keystone. The Keystone pop-up menu displays.
Securing the projector Utilizing the password function For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the Settings menu. You will be inconvenienced if you activate the power-on lock functionality and subsequently forget the password. Print out this manual (if necessary) and write the password you used in this manual, and keep the manual in a safe place for later recall.
Entering the password recall procedure 1. 2. 3. Press and hold on the remote control for 3 seconds. The projector will display a coded number on the screen. Write down the number and turn off your projector. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector. Changing the password 1. 2. 3. 4. Go to the Settings > Advanced > Security Settings > Change password menu.
Though the password function is disabled, you need to keep the old password in hand should you ever need to re-activate the password function by entering the old password. Firmware upgrade Follow below procedures to upgrade firmware version. • Only an SD Card is supported for a firmware update. • Do not remove the SD Card while an update is in progress. • Do not operate any buttons during the update. • Do not turn the projector off during the update.
Optimizing the image Selecting a picture mode The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type. To select an operation mode that suits your need, you can follow one of the following steps. • • • Make sure the input source is on computer, DVD player, composite video, component and HDMI mode and the projection screen is displayed.
Using Wall Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s color to prevent possible color difference between the source and projected pictures. To use this function, press to open the pop-up menu in one of the computer, iPhone/ iPod, composite video, component and HDMI modes.
Operating in a high altitude environment We recommend you use the High Altitude Mode when your environment is between 1500 m –3000 m above sea level, and ambient temperature is between 0°C–30°C. Do not use the High Altitude Mode if your altitude is between 0 m and 1499 m and ambient temperature is between 0°C and 35°C. The projector will be over cooled, if you turn the mode on under such a condition. To activate the High Altitude Mode: 1. 2. 3. 4. Hightlight Settings and press OK to enter.
1. 2. 3. 4. 5. Hightlight Settings and press OK to enter. Go to Advanced > Audio Settings and press OK to enter. Highlight Mute and press OK to open the pop-up menu. Highlight On and press OK to confirm. To leave the OSD, press until the projector returns to the home screen, or press to go back to the home screen directly. Adjusting the sound level To adjust the sound level, press + or - on the remote control. Turning off Power on/off ring tone To turn off the Power on/off ring tone: 1. 2. 3.
Displaying images with PC and Video source devices You can connect your projector to a PC and various Video source devices. (e.g. HDMI, composite video, component video) However, you need only connect the projector to an input source device. To display images: 1. 2. 3. 4. 36 Connect the projector to one of the above signal source. Turn on the power of the projector and your source device. The projector displays the home screen.
Using PC/ Video pop-up menus The projector has a multilingual OSD that allows you to make image adjustments and change a variety of settings. This menu is for the settings to be used in computer, DVD player, composite video, component and HDMI modes. Using the menu 1. 2. 3. To open the OSD menu, press on the projector or remote control when the projection screen is displayed. When the OSD is displayed, press / to select the desired item and adjust the settings by using / . To leave the OSD, press again.
Description of each menu FUNCTION DESCRIPTION Wall Color Auto Keystone Corrects the projected picture’s color when the projection surface is not white. See "Using Wall Color" on page 33 for details. There are four options to set the image's aspect ratio depending on your input signal source. See "Selecting the aspect ratio" on page 31 for details. Auto corrects any keystoning of the image. Keystone Corrects any keystoning of the image. See "Correcting keystone" on page 28 for details.
Displaying files with internal memory, USB Drive and SD card The projector can display files saved in internal memory or external storage like an SD card or a USB Drive when you have connected to projector. To display files: 1. 2. 3. Turn on the power of the projector and the projector displays the home screen. Connect the projector to one of the above external memory devices. Press / to select SD card, USB Drive/Wireless Display or internal memory. 4.
When playing videos NAME OK / DESCRIPTION Play/Pause Volume Prev Next Menu Back Home Plays or pauses a video. Volume up/down. • Plays the previous video. • Press and hold to rewind the video. - The rewind speed increases to x2, x4, x8 and x16 at 2second intervals. • Plays the next video. • Press and hold to fast forward the video. - The fast-forward speed increases to x2, x4, x8 and x16 at 2-second intervals. Open/close video pop-up settings menu. • Return to upper level of OSD.
• See the table for supported subtitle file types. Refer to "Supported file formats" on page 50.
Description of each menu FUNCTION DESCRIPTION Wall Color Corrects the projected picture’s color when the projection surface is not white. See "Using Wall Color" on page 33 for details. Screen Settings Auto Keystone Auto corrects any keystoning of the image. Keystone Corrects any keystoning of the image. See "Correcting keystone" on page 28 for details. Picture Mode Pre-defined picture modes are provided so you can optimize your projector image set-up to suit your program type.
When playing music NAME OK / DESCRIPTION Play/Pause Volume Prev Next Menu Back Home Plays or pauses a music. Volume up/down. • Plays the previous music. • Press and hold to rewind the music. • Plays the next music. • Press and hold to fast forward the music. Open/close music pop-up settings menu. • Return to upper level of OSD. • Close video pop-up setting menu. • Leave current music player and back to music file browser. Exit music player and go back to home screen.
Menu system Menu Item Options Play Mode All in folder/One music Play Order Normal / Shuffle Repeat On/Off Description of each menu 44 FUNCTION DESCRIPTION Play Mode Lets you choose to play one music or all music in a folder. Play Order Lets you select the playback order of music files. Repeat Lets you select whether to repeat music playback.
When viewing photos NAME OK DESCRIPTION Play/Pause Prev Next Menu Back Home Plays or pauses a slideshow. Previous photo. Next photo. Open/close photo pop-up settings menu. • Return to upper level of OSD. • Close photo pop-up setting menu. • Leave current photo player and back to photo file browser. Exit photo player and go back to home screen. Photo viewer pop-up settings menu The photo view pop-up menu provides an on-screen display (OSD) for adjustments when viewing photos. Using the menu 1. 2. 3.
Menu system Menu Item Sub-menu Options Wall Color Off/Light Yellow/Pink/Light Green/ Blue/Blackboard Screen Settings Auto Keystone On/Off Keystone Picture Mode Bright/Standard/Cinema/Game/User Reference Mode Bright/Standard/Cinema/Game Brightness Picture Mode Settings Contrast Color Tint Sharpness Color Temperature Warm/Normal/Cool Save Settings Slideshow Speed Play Settings Fast/ Normal/ Slow Slideshow Mode All in folder / One photo Slideshow Order Normal / Shuffle Repeat On/Off Des
Picture Mode Pre-defined picture modes are provided so you can optimize your projector image set-up to suit your program type. Reference Mode Selects a picture mode that best suits your need for the image quality and further fine-tune the image based on the selections listed on the same page below. This function is only available when User is selected. Brightness Adjusts the brightness of the image. Contrast Picture Mode Settings Adjusts the degree of difference between dark and light in the image.
When viewing documents NAME OK Enter Up Down Left Right Menu Back Home 48 DESCRIPTION Enlarge the current page. Magnify the page with a further press. 1. When the page is not enlarged: / : Move to the previous page. / : Move to the next page. 2. When the page is enlarged: / / / : Move to the top/down/left/right portion of the page. Bring out the pop-up menu. Leave current document viewer and back to document file browser. Exit document viewer and go back to home screen.
Document viewer pop-up settings menu The document view pop-up menu provides an on-screen display (OSD) for adjustments when viewing photos. Using the menu 1. 2. 3. To open the OSD menu, press on the projector or remote control when the projection screen is displayed. When the OSD is displayed, press / to select the desired item and adjust the settings by using / . To exit the OSD, press on the projector or remote control again..
Supported file formats • Document, Photo, Music ITEM FILE EXTENSION Adobe PDF 1.0~1.4 (PDF) MS PowerPoint 97~2010 (ppt, pptx) MS Excel 95~2010, Office XP (xls, xlsx) MS Word 95~2010, Office XP (doc, docx) JPG (.jpg, .jpeg) , BMP (.bmp) MP3, MP2, MP1, OGG, AAC, WAV Document Photo Music • Video, Subtitles ITEM FILE EXTENSION Video AVI (Xvid, MJPEG), MKV (XVID), DVIX (MJPEG, XVID), DAT (MPEG1), MPG(MPEG1), MPEG(MPEG1) DESCRIPTION • • Subtitles SRT (.
Using USB streaming The projector supports USB streaming for USB display and USB file transfer. BenQ EZ USB display The projector can project computer screen via a USB cable instead of a VGA cable. To use USB display: 1. 2. 3. 4. 5. 6. 7. Connect the projector to a computer using a USB cable. Turn on the power of the projector and your source device. The projector displays the home screen. Press / to select USB Streaming. Press / to select USB Display and then press OK to enter.
2. Turn on the power of the projector and your source device. The projector displays the home screen. 3. Press / to select USB Streaming. 4. Press / to select USB File Transfer and then press OK to enter. 5. If the connection is sucessful, you will see “It is in USB file transfer mode.” message on the screen. 6. Look for a new “removable disk” icon. This “removable disk” is actually the internal memory in your projector. 7. Copy & Paste or Drag-N-Drop files from your computer to the removable disk. 8.
Using wireless streaming Display PC screen to projector wirelessly BenQ EZ QPresenter is a power program to project your PC/NB screen to projector wirelessly. It also brings you extension display function so that you can show different content in the secondary display. Follow the steps below to get it all set up in just a few minutes. 1. Connect the wireless dongle to the USB jack of the projector. 2. Select “USB Drive/Wireless Streaming” by pressing and press “OK” on your projector.
3. 4. You will be prompted to the “To install BenQ EZ QPresenter” page and follow the steps as instructed. 5. Select “BenQ GP10” as your WLAN connection on your computer (make sure your computer is equipped with wireless network card). 54 Operation Start a web browser and key in IP address 192.168.100.10 into the address bar and press “Enter”.
6. Select OS version and start downloading and installing BenQ EZ QPresenter by following the on-screen instructions on you PC. 7. Open BenQ EZ QPresenter to start wireless projection i. Select “BenQ GP10” from wireless access point menu of your PC/NB. ii. Open BenQ EZ QPresenter to start projection in mirror mode (default). Tips: • If you have installed BenQ EZ QPrensenter prior to step i., it will be connected to GP10 automatically.
• • Q: Why does my display frame rate slow down? A: BenQ EZ QPresenter needs to encode display content while sending massive realtime data to the projector. i. PC: A dual core PC (excluding Atom processors) or Mac is required to encode the screen images at 30FPS (Frame Per Second) speed. However, if you would like to increase the FPS speed, you can: a. Use better media players, such as GOM player b. Close all unused apps c. Use a faster PC with Windows Experience Score higher than 4 (4+ recommended) ii.
Display iPhone/iPAD content to projector wirelessly BenQ GP10 QPresenter is an easy-to-use app which enables your mobile devices to project the display to BenQ GP10 Ultra Lite LED projector. You can display your photos/ documents including PDF, MS-Office and iWorks. Follow the steps below to get it all set up in just a few minutes. 1. 2. Connect the wireless dongle to the USB jack of the projector. Select “USB Drive/Wireless Streaming” by pressing and press “OK” on your projector. Choose “Mobile Display”.
4. Connect your iPhone or iPad to NB/PC. Open iTunes and sync the documents from NB/PC to your iPhone or iPad. After it’s done, you can disconnect your iPhone/iPad. 5. Turn on your iPhone/iPad WiFi , find BenQ GP10 or the projector SSID you defined to projector and connect with it directly. After WiFi connection is established, you can execute BenQ GP10 QPresenter app on your iPhone/iPad, and you will be able to see the device’s IP address now.
Wi-Fi Dongle Specifications Model Name Wireless Standard Interface Data Transfer Rate Frequency Band Security Supported OS Minimum PC System Requirement WDRT8192 IEEE 802.11 b/g/n USB 2.0 up to 300Mbps 2.
Using settings menu This menu is to set the projector’s operating environment. Using the menu 1. 2. 3. 4. 5. 6. 7. 60 To open the OSD menu, press / to select Settings icon in home screen. When the OSD is displayed, press / to select any item in the main menu. After selecting the desired main menu item, press OK to enter the feature settings submenu. Press / to select the desired item and press OK to open the pop-up menu. Select the settings using / / / and press OK to confirm.
Menu system Main menu Sub-menu Options Language 1. Basic LED Mode Normal/Eco Wall Color Off/Light Yellow/Pink/Light Green/ Blue/Blackboard Auto Keystone On/Off Eye Protection On/Off Auto Power Off Disable/5 min/10 min/15 min/20 min/25 min/30 min Splash Screen BenQ/ Black/Blue High Altitude Mode On/Off Audio Settings SRS HD On/Off Mute On/Off Volume Power on/off ring tone Menu Display Time 2.
Description of each menu FUNCTION Language LED Mode Wall Color 1. Basic menu Auto Keystone Eye Protection Auto Power Off DESCRIPTION Sets the language for the On-Screen Display (OSD) menus. Choose Eco to dim the projector LED which will lower power consumption, extend the LED life and reduce noise. Choose Normal to return normal mode. Corrects the projected picture’s color when the projection surface is not white. Auto corrects any keystoning of the image.
FUNCTION DESCRIPTION High Altitude A mode for operation in high altitude areas. See "Operating in a high altitude environment" on page 34for details. Mode Audio Settings See "Adjusting the sound" on page 34 for details. Menu Display Sets the length of time the OSD will remain active after your last key press. The range is from 5 to 30 seconds in 5-second increments. Time Security Settings See "Securing the projector" on page 29 for details. 2.
FUNCTION Source DESCRIPTION Shows the current signal source. Picture Mode Shows the selected mode. Color System Shows input system format: RGB or YUV. 3. Information menu 64 Resolution Shows the native resolution of the input signal. Memory / Internal Memory Shows the memory capacity status: Internal Memory. DLP 3D Shows the DLP 3D status. LED Lamp Life Displays the number of hours the lamp has been used. Firmware Version Shows firmware version.
Shutting down the projector 1. Press II Power and a confirmation message displays prompting you. If you don't respond in a few seconds, the message will disappear. 2. 3. Press II Power a second time. The Power LED indicator flashes orange slowly and fans stop. Disconnect the power cord from the wall socket if the projector will not be used in an extended period of time. 4.
Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector. Contact your dealer if other parts need replacing. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface. • • Use a canister of compressed air to remove dust. If there is dirt or smears, use lens-cleaning paper or moisten a soft cloth with lens cleaner and gently wipe the lens surface.
LED Indicators Status / Problems LED indicators LED Behavior Power Fan Temp Standby Orange solid on Off Off Power LED slow flash Power warm up Green blanking Power on Green Off Off Light solid on sequence: Power->Key->Ring & OK Cooling Orange blanking Off Off Power LED slow flash Fan1 error Off On Off Ring & OK LED flash first and then key LED flash (1.5 seconds interval) Temp error Off Off On Ring & OK LED and Key LED flash at the same time (1.
Troubleshooting The projector does not turn on. Cause Remedy Plug the AC adapter into the DC IN socket on the projector, plug the power cord into the AC inlet There is no power from the power cable. on the AC adapter, plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on. Attempting to turn the projector on again Wait until the cooling down process has during the cooling process. completed.
Specifications Projector specifications All specifications are subject to change without notice. General Product name Model name Ultra Lite LED Projector GP10 Optical Resolution Display system Lens F/Number Lamp Throw Ratio 1280 x 800 WXGA 1-CHIP DMD F = 1.65 3LED 1.2:1 (40"@1m) Electrical Power supply Power consumption Keystone Adjustment AC100–240V, 50-60 Hz (Automatic) 125 W (Max.); < 0.5 W (Standby) 1D, Vertical +/- 30 degrees Mechanical Dimensions Weight 220 mm (W) x 61.8 mm (H) x 177 mm (D) 1.
Operating relative humidity Operating altitude 10%-90% (without condensation) 0–1499 m at 0°C–35°C 1500–3000 m at 0°C–30°C (with High Altitude Mode on) Dimensions • • Without DVD player: 220 mm (W) x 61.8 mm (H) x 177 mm (D) With DVD player: 220 mm (W) x 95.0 mm (H) x 177 mm (D) 220 61.8 220 177 81 29 81 62.2 95.
Timing chart Supported timing for PC input Resolution 640 x 480 720 x 400 800 x 600 1024 x 768 1152 x 864 1024 x 576 1024 x 600 1280 x 720 1280 x 768 1280 x 800 1280 x 1024 1280 x 960 1360 x 768 1440 x 900 1400 x 1050 1680 x 1050 640 x 480 @67Hz 832 x 624@75Hz 1024 x 768@75Hz 1152 x 870@75Hz Mode VGA_60 VGA_72 VGA_75 VGA_85 720 x 400_70 SVGA_60 SVGA_72 SVGA_75 SVGA_85 SVGA_120* XGA_60 XGA_70 XGA_75 XGA_85 XGA_120* (Reduce Blanking) 1152 x 864_75 BenQ Notebook Timing BenQ Notebook Timing 1280 x 720_60 12
Supported timing for HDMI input PC timings: Resolution 640 x 480 720 x 400 800 x 600 1024 x 768 1152 x 864 1024 x 576 1024 x 600 1280 x 720 1280 x 768 1280 x 800 1280 x 1024 1280 x 960 1360 x 768 1440 x 900 1400 x 1050 1680 x 1050 640 x 480@67Hz 832 x 624@75Hz 1024 x 768@75Hz 1152 x 870@75Hz Mode Vertical Frequency (Hz) VGA_60 VGA_72 VGA_75 VGA_85 720 x 400_70 SVGA_60 SVGA_72 SVGA_75 SVGA_85 SVGA_120* XGA_60 XGA_70 XGA_75 XGA_85 XGA_120* (Reduce Blanking) 1152 x 864_75 BenQ Notebook Timing BenQ Notebo
Video timings: Timing 480i 480p 576i 576p 720/50p 720/60p 1080/24P 1080/25P 1080/30P 1080/50i 1080/60i 1080/50P 1080/60P Resolution Vertical Frequency (Hz) 720 (1440) x 480 720 x 480 720 (1440) x 576 720 x 576 1280 x 720 1280 x 720 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 Horizontal Frequency (kHz) 59.94 59.94 50 50 50 60 24 25 30 50 60 50 60 15.73 31.47 15.63 31.25 37.5 45.00 27 28.13 33.75 28.13 33.75 56.25 67.
Warranty and Copyright information Patents This BenQ projector is covered by the following patents: U.S. patents 6,837,608; 7,275,834; 7,181,318; TW patents 202690; 205470; I228635; I259932; China Patents ( 中国发明专利 ) ZL01143168.7; ZL03119907.0; ZL200510051609.2 Limited warranty BenQ warrants this product against any defects in material and workmanship, under normal usage and storage. Proof of purchase date will be required with any warranty claim.
