Model EB6 Model EB9 For use with compatible Best by Broan range hoods. See hood manual for suitability. BEST BY BROAN, P.O.
READ AND SAVE THESE INSTRUCTIONS WARNING WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: 1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address or telephone number listed in the warranty. 2. Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to prevent power from being switched on accidentally.
PREPARE THE INSTALLATION LOCATION PREPARE THE INSTALLATION LOCATION ROOF INSTALLATIONS WALL INSTALLATIONS 1. Locate the blower on the rear slope of the roof. Place it in a location to minimize duct run. The location should be free of obstacles (T.V. leads, electrical lines, etc.). Bear in mind, if the blower top is level with the roof peak, it will not be seen from the street. Keep this approximate location in mind as you work from within the attic. 1. Choose a position on the outside wall.
INSTALL THE BLOWER INSTALL THE BLOWER ROOF INSTALLATIONS WALL INSTALLATIONS 1. Remove roofing nails from the upper 2/3 of the shingles around the cutout area and carefully lift the shingles to allow the back flashing sheet on the blower housing to fit under them. 2. Center the blower ring in the 11" diameter hole, making sure that the 1-1/4" diameter electrical wiring hole aligns with the hole in the wiring box. 3. Attach the blower to the roof with the six screws provided.
WARRANTY BROAN ONE YEAR LIMITED WARRANTY Broan warrants to the original consumer purchaser of its products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
SERVICE PARTS MODELS EB6 & EB9 4 5 16 1 3 13 5 8 4 15 11 17 10 12 6 18 19 7 2 18 14 KEY NO. 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 PART NO. 97011795 98008507 93260454 99100484 99260477 98008511 99100379 99080396 99080397 98008509 98008588 98008510 99020263 99020264 99140145 99400055 99100517 99150471 99150535 99271110 DESCRIPTION Airbox Assembly Damper Sheet Metal Nut, #8-18 U-Type (7 req.)* Isolator (3 req.) Whiz Nut, 1/4" - 20 (3 req.)* Grille Heyco Damper (2 req.
99042680D
