Instructions / Assembly

TECH. DEPT.

TECHNICAL SPECIFICATIONS

Date:

N°:

Pg.:

30/03/2015

ST00882

1/2

Issued:

Mazzoleni C.

mod. Q/104 rev.0

450

Reference Item: C19

Reference Standard:

Description: Three-section cantilever tool box , made from sheet metal

Rev.: Description:

200

160

PAGE 1
TECHNICAL SPECIFICATIONS TECH. DEPT. Reference Item: Date: N°: Pg.: 30/03/2015 ST00882 1/2 Issued: Mazzoleni C. C19 Reference Standard: Description: Description: 160 200 Rev.: Three-section cantilever tool box , made from sheet metal 450 mod. Q/104 rev.
PAGE 2
TECHNICAL SPECIFICATIONS TECH. DEPT. Date: N°: Pg.: 30/03/2015 ST00882 2/2 Issued: Mazzoleni C. Sheet metal Material: Chemical Composition C Si Mn P S Cr Mo Ni Heat Treatment: Hardness: Finishing: Varnished color Beta orange Marking: Deep drawn Beta logo Manufactured: Bend + machining Technical features : Weight :  3,4 k-g mod. Q/104 rev.
