Specifications

Napco’s crystal-control Gemini wireless
products have been proven by an
independent testing laboratory to
outperform competitive products, with
long-range RF reliability, as much as 50%
higher than other top brands.
Gemini Transmitters range from keyfobs
and panic buttons, to recessed door
and surface-mount window/door
contacts, to wireless PIR, PIR/pet and
dual sensors, and from wireless smokes
and glass breaks to heat detectors.
Simply put, Gemini’s uncommon crystal-
control precision and omnidirectional
circuitry, ensures the wireless/hardwire
systems you provide your customers
will dependably deliver the security and
trouble-free, peace-of-mind they deserve
for many years to come.
Advanced
performance
Gemini RF
receivers
GEM-RECV-XP8 8 Points
For Express, P801/800/
P400 panels, only
GEM-RECV-32 32 Points
GEM-RECV-96 96 Points
GEM-RECV-X255 255 Points
 Dual diversity antennas minimize nulls &
enhance reliability
 Tamper- and RF-jamming supervision
 Separate programmable supervisory
times by device type
 Audible fault-find mode in walk test
Also, fixed English language keypad
GEM-K4RF with buiit in 32 pt receiver
(see keypads section).
Gemini Wireless: Proven to outperform the competition
28
Recessed wireless window/door transmitter
GEM-RTRANS (not shown)
 For recessed use in both windows and doors
 Powerful wireless transmitter
 White housing, magnet & hole cover
 Field-replaceable 5 year battery. Long-life 3V type DL123A lithium battery
supplied.
Low profile wireless
window/door transmitter
GEM-TRANSLP
 Ultra compact design, 2.5 x 1 x 0.4
(H x W x D inches)
 Tamper supervised
 Replaceable lithium PL2032 coin cell
battery (supplied
 5-year battery life, typical
 Magnet and Internal reed switch
 External lead (24” mini connector pigtail)
for wiring external devices (jumper-
selectable)
 Magnet mounts with either supplied
double-face tape or screws (screwtabs
easily removable from mounting plate,
at score)
GEM-TRANSLP virtually disappears even in
slimline window frames
Now in Brown, too,
GEM-TRANSLP-BRN
