® ® OWNER'S MANUAL Passionate about Music Better Music Builder is a leader in the Audio and Karaoke equipment industry. We are committed to offering you high quality audio products. Unlike any others brand, we deliver the best cost and value to you directly. We may update our manual on short notice, so we highly recommend downloading the latest update information including operation manuals, installation instructions, and other new technologies updates, etc. from our website www.BetterMusicBuilder.com.
CONTENTS INTRODUCTION............................................................................................................................................... 3 Intro Features SYSTEM FEATURES........................................................................................................................................... 3 SAFETY INSTRUCTIONS.............................................................................................................................
Intro INTRODUCTION Features Better Music Builder is excited to introduce the next generation of the Classic Series speaker, the G2 (Generation 2). The high performance speakers consist of three models: CS-600 G2, CS-612 G2 and CS-812 G2.
Safety ABNORMALITY SAFETY INSTRUCTIONS V" ! > & " & @ or if there is a sudden loss of sound during use of the device, or if any unusual smells or smoke should appear to be caused by it, immediately turn off the power switch, disconnect the electric plug from the outlet, and have the device inspected by qualified Better Music Builder service personnel.
P ! \ ! " L P & = L P ! $ $ $ > @ & ! 3 ! ! @ ! @ ! ] $ ! > " " & ! & L P ! $ > ! & ! " $ L ^! ! $ & ! $
Applications SYSTEM APPLICATIONS METHODS OF SPEAKER CONNECTION CONNECTING THE SPEAKERS 1. Insert Type (Standard Connection) HOW TO CONNECT THE SPEAKER TO AMPLIFIER We at Better Music Builder always provide you the technical support and relevant information to help you make the best use of your audio equipment. To avoid damages in connection mistakes please refer to the following three diagrams showing our recommended connections for the different speaker impedance.
CONNECTING THE SPEAKER WITH 3-D POSITIONAL AUDIO (PREMIUM FORMAT) Please refer to the diagram on the right for connecting the speakers to the 3-D Positional Audio system designed by the Better Music Builder engineering team.
CONNECTING THE SPEAKER WITH 5-D PRO AUDIO (SUPERIOR FORMAT) Please refer to the diagram on the right for connecting the speakers to the 5-D Pro Audio system designed by the Better Music Builder engineering team. The concept of 5-D Pro Audio technology is the same as that of the 3-D Positional Audio technology.
CONTROLS AND FUNCTIONS FRONT & REAR PANEL: features are available for 3-WAY FULL RANGE SPEAKER model CS-600 G2 Front View Top View Rear View 2 3 1 6 4 CS-600 G2 Speaker 5 1 3-INCH TWEETER: PAPER CONE HIGH FREQUENCY DRIVER 2 MOUNTABLE SCREW: TWO 8mm SCREW SIZE 3 10-INCH WOOFER: PAPER CONE LOW FREQUENCY DRIVER 4 3-INCH TWEETER: PAPER CONE MIDDLE FREQUENCY DRIVER 5 FRONT GRILL COVER 6 SPEAKER INPUT TERMINAL Front View Top View Rear View 3 1 4 8 5 2 6 7 1 3-INCH TWEETER: PAPER CON
Set Up SYSTEM SETUP GUIDELINES Adjusting the Ceiling Mount (NB-901) INSTALLATION SETUP Precise Angle 1. MOUNTING THE SPEAKER TO THE CEILING The Ceiling Mount allows swing adjustment, slightly loosen an screw to make an adjustment, then re-tighten. Once you have set up the right position, then you can use the screw to tight it up. STEP 1 : Place the wall mount panel on the top of the speaker cabinet and use two screws to fasten it.
2. MOUNTING THE SPEAKER TO THE WALL Adjusting the Wall Mount (NB-901) STEP 1 : Place the wall mount panel on the top of the speaker cabinet and use two screws to fasten it. Precise Angle The Wall Mount allows swing adjustment, slightly loosen an screw to make an adjustment, then re-tighten. Once you have set up the right position, then you can use the screw to tight it up. STEP 2 : Then, use four screws to hold the speaker firmly into the wall.
3. PLACING THE SPEAKER ON THE FLOOR TO MONITOR SINGING Speaker Stand External Adapter Mount Dimensions: This speaker can be placed on the floor to perform the vocal monitoring function for live singing experience. It can also be used for business conference, coffee shop and church, etc. 2 inches 5.2 cm 7.1 inches 18 cm 4.75 inches 12 cm 0.5 inches 1.3 cm Floor 4. PLACING THE SPEAKERS ON THE PORTABLE STAND The speakers can be mounted on to the optional portable stand (see figure below).
RECOMMENDED TOOLS NUTS AND SCREWS The recommended tools in this page are not included in the package. You may purchase the recommended tools and other accessories from a hardware store. Allen Screw We at Better Music Builder always provide our customers with useful information on audio equipment installation to make your installation safe and easy. 8 mm 30 mm Turn this way to loosen the screw. Turn this way to tighten the screw.
CS-600 G2 (10-inch Woofer) FRONT VIEW 4 inch/10 cm 11.4 inch 29 cm REAR VIEW 4 inch/10 cm 12.4 inch 31.5 cm 19.7 inch/50 cm SIDE VIEW 12.4 inch 31.5 cm 19.7 inch/50 cm SEE-THROUGH TOP VIEW 12.4 inch 31.5 cm 11.4 inch/29 cm SEE-THROUGH SIDE VIEW PERSPECTIVE 11.4 inch 29 cm 19.7 inch/50 cm CS-612 G2 (12-inch Woofer) FRONT VIEW 4 inch/10 cm 13.6 inch 34.5 cm REAR VIEW 4 inch/10 cm 13.8 inch 35 cm 24.1 inch/61.2 cm SIDE VIEW 13.8 inch 35 cm 24.1 inch/61.2 cm SEE-THROUGH TOP VIEW 13.
Dimensions PHYSICAL DIMENSIONS 3-WAY FULL RANGE LOUDSPEAKER MODEL CS-600 G2 CS-612 G2 CS-812 G2 NET WEIGHT 23.8 lbs / 10.8 kg (each) 36 lbs / 16.3 kg (each) 38 lbs / 17.2 kg (each) SHIPPING WEIGHT 54 lbs / 24.5 kg (pair) 40.6 lbs / 18.4 kg (each) 42.6 lbs / 19.3 kg (each) DIMENSIONS (WXHXD) 19.7 x 12.4 x 11.4 in 50 x 31.5 x 29 cm (each) 24.1 x 13.8 x 13.6 in 61.2 x 35 x 34.5 cm 24.1 x 13.8 x 13.6 in 61.2 x 35 x 34.5 cm PACKING DIMENSIONS (WXHXD) 27 x 24 x 15.7 in 68.
Troubleshooting TROUBLESHOOTING 1. SYMPTOM: NO SOUNDS COMING OUT FROM THE SPEAKERS 3. SYMPTOM: NOISES FROM THE SPEAKER. Probable cause: Probable causes: The A/C power cord of the speaker is not grounded. 1. The A/C power of the speaker is not turned on. Remedy: 2. Chose the wrong A/C power selection (i.e. 110V~ 220V). Change a new magnet cord of the A/C power cord. Remedy: 4. SYMPTOM: MICROPHONE VOLUME IS TOO LOW. A. Turn on the A/C power of the speaker. Probable causes: B.
Final Words 7. SYMPTOM: TOO MUCH MICROPHONE FEEDBACK FROM THE SPEAKER. FINAL WORDS TO USER The engineering team of Better Music Builder has many years of experience in audio equipment design. The team constantly develops new audio technologies, designs innovative audio and karaoke equipment to suit your specific needs and provides you great ideas for home entertainment. Probable cause: Incorrect tremble and bass adjustments on the speaker.
Warranty WARRANTY ONE-YEAR LIMITED WARRANTY FOR HOME USE EQUIPMENT ADDITIONAL NOTES: 1. Limited warranty for home use equipment is only valid in North America. Our one-year warranty covers both parts and labors. The warranty becomes effective from the date of your purchase for one year. 2. Limited warranty is valid only if you purchase our products from our authorized dealers (including both regular retailers and online retailers) in North America.
Notices AGENCY REGULATORY NOTICES Federal Communications Commission Notice your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
Contact Us CONTACT INFORMATION MAILING ADDRESS B E T TER M USI C BU I L D ER 2930 0 Kohoutek Way #150 Union Cit y, CA 94587 U.S.A. TELEPHONE NUMBERS USA Region USA Toll Fre e: 1-80 0 -318-2218 S ale s & M arketing: 510 - 477-9 955 Customer S er vice: 510 - 477-9955 FAX NUMBERS USA Region S ale s & M arketing: 510 - 477-9 922 Customer S er vice: 510 - 477-9922 WORLD WIDE WEB E-mail: sales@bettermusicbuilder.com Website: www.bettermusicbuilder.
® ® Unlike any others ... that’s cost & value for you Passionate about Music w w w. B e t t e rM us i c B u i l d e r.c o m Thank you for purchasing this unit. To make full and effective use of this unit, please read this Owner's Manual carefully before operating it. Please retain this manual for future reference. 361110615000 Printed on 100% Recycled Paper Code: 20110810 Comments E-mail to sales@bettermusicbuilder.com Copyright © 2011 Better Music Builder. All rights reserved. Legal trademark.
